Chapter 3
When TS-401T is turned on, the server name, IP address, date, and time will be
shown.
Power
Error
Network
Hard disk
Check System Information
1. Press Down button to view disk information, i.e. number of disks and disk
size. Note that the disk size displayed is the total size of all installed disks
but may not be the actual disk size you can use. If you configure the disks
as RAID 1 disk volume, your actual disk size you can use is smaller than the
displayed disk size on the panel.
DISK NUMBER: 4
SIZE: 233632.50 MB
2. Press Down button again to view system temperature and system fan speed.
SYS TEMP: 40
SYS FAN: 3515 RPM
3. Press Down button again to view CPU temperature and CPU fan speed.
CPU TEMP: 56
CPU FAN: 7258 RPM
Use LCD Panel
Server name
TS-401T
10.8.10.49
IP address
o
C
o
C
Date
09/08
02:22
Time
- 16 -
Enter button
Down button
