Page 2: Table Of Contents
TS-x53DU User Guide Contents 1. Preface About This Guide............................3 Audience...............................3 Document Conventions..........................3 2. Product Overview About the TS-x53DU.............................4 Hardware Specifications..........................4 Package Contents............................6 Components..............................7 Front Panel............................... 7 Rear Panel..............................8 System Board............................11 Drive Numbering.............................11 Safety Information............................12 Installation Requirements........................... - Page 3 myQNAPcloud ID............................51 Qfinder Pro..............................51 QTS................................51 7. Notices Limited Warranty............................52 Disclaimer..............................52 GNU Public License............................52 CE Notice..............................60 FCC Notice..............................60 VCCI Notice..............................60 BSMI Notice..............................61 SJ/T 11364-2006............................61...
-
Page 4: Preface
TS-x53DU User Guide 1. Preface About This Guide This guide provides information about the device and step-by-step instructions on installing the hardware. It also provides instructions on basic operations and troubleshooting information. Audience This document is intended for consumers and storage administrators. This guide assumes that the user has a basic understanding of storage and backup concepts. -
Page 5: Product Overview
TS-x53DU User Guide 2. Product Overview This chapter provides basic information about the QNAP TS-x53DU NAS. About the TS-x53DU ® ® Powered by an Intel Celeron J4125 quad-core 2.0 GHz processor, the TS-x53DU supports various disk storage configurations to better meet your virtualization and data storage needs. It supports up to 8 GB of DDR4 memory, and a SATA 6 Gbps hard drive interface. - Page 6 External I/O Ports & Expansion Slots PCIe slots 1 x PCIe 2.0 x2 For the list of compatible expansion cards, go to https:// www.qnap.com/compatibility. USB ports • 2 x USB 2.0 Type-A • 2 x USB 3.2 Gen 1 Type-A HDMI ports 1 x HDMI v1.4b (up to 3840 x 2160 @ 30Hz resolution)
-
Page 7: Package Contents
TS-x53DU User Guide Component TS-453DU TS-853DU-RP TS-1253DU-RP TS-453DU-RP Net weight • TS-453DU: 6.66 kg 8.89 kg 9.43 kg (14.55 lbs) (19.60 lbs) (20.79 lbs) • TS-453DU-RP: 8.12 kg (17.90 lbs) Others Rail compatibility RAIL-B02 Power supply unit • TS-453DU:1 x 250W, 2 x 300W, 100-240V 2 x 300W, 100-240V AC, 100-240V AC, 50-60Hz... -
Page 8: Components
TS-x53DU User Guide Item Quantity Ethernet cables 1 x CAT5e cable Screws for 3.5-inch drives • TS-453DU, TS-453DU-RP: 16 • TS-853DU-RP: 32 • TS-1253DU-RP: 48 Screws for 2.5-inch drives • TS-453DU, TS-453DU-RP: 12 • TS-853DU-RP: 24 • TS-1253DU-RP: 36 Handle kit TS-453DU,TS-453DU-RP: •... -
Page 9: Rear Panel
TS-x53DU User Guide TS-453DU, TS-453DU-RP Component Component Status LED LAN LED Drive LEDs Power button Rear Panel TS-453DU Component Component 2.5 Gigabit Ethernet HDMI v1.4b port activity LED Product Overview... - Page 10 TS-x53DU User Guide Component Component 2.5 Gigabit Ethernet ports USB 3.2 Gen 1 Type-A (RJ45) ports Note These ports support Wake-on- configurations. 2.5 Gigabit Ethernet USB 2.0 Type-A ports speed LED PCIe low-profile cover Reset button Power input TS-453DU-RP Component Component 2.5 Gigabit Ethernet PCIe low-profile cover...
- Page 11 TS-x53DU User Guide TS-853DU-RP, TS-1253DU-RP Component Component 2.5 Gigabit Ethernet PCIe low-profile cover activity LED 2.5 Gigabit Ethernet ports HDMI v1.4b port Note These ports support Wake-on- configurations. 2.5 Gigabit Ethernet USB 3.2 Gen 1 Type-A speed LED ports Power supply unit USB 2.0 Type-A ports Power input Reset button...
-
Page 12: System Board
TS-x53DU User Guide System Board Note The image does not include the case cover. Component Component PCIe 2.0 x2 slot Memory slot 2 Memory slot 1 Drive Numbering TS-453DU, TS-453DU-RP Product Overview... -
Page 13: Safety Information
TS-x53DU User Guide TS-853DU-RP TS-1253DU-RP Safety Information The following instructions help ensure personal safety and environmental safety. Read these instructions carefully before performing any operations. General Instructions • The device should be stored in a secure location with restricted access, controlled through the use of a tool, lock and key, or any means of security. -
Page 14: Installation Requirements
• Flat, anti-static surface without exposure to direct sunlight, liquids, or chemicals Hardware and peripherals • Storage drives For the list of compatible drive models, go to https:// www.qnap.com/compatibility. • Network cable Tools • Phillips #1 or #2 screwdriver • Anti-static wrist strap Setting Up the NAS 1. - Page 15 TS-x53DU User Guide • Installing 2.5-inch Hard Drives or Solid State Drives on 3.5-inch Trays For the list of compatible drive models, go to https://www.qnap.com/compatibility. 4. Optional: Install expansion cards. For details, see Installing Expansion Cards. 5. Connect the NAS to the network.
-
Page 16: Installation And Configuration
TS-x53DU User Guide 3. Installation and Configuration This chapter provides specific hardware and firmware installation and configuration steps. Hardware Installation This section provides information on installing drives, memory modules, and expansion cards. Removing the Case Cover Warning • Moving fan blades: Keep your hands and other body parts away from moving fan blades. - Page 17 TS-x53DU User Guide 2. Slide the cover back. 3. Lift the cover off the NAS. • TS-853DU-RP, TS-1253DU-RP 1. Loosen the screws. Installation and Configuration...
-
Page 18: Attaching The Case Cover
TS-x53DU User Guide 2. Slide the cover back. 3. Lift the cover off the NAS. Attaching the Case Cover Warning • Moving fan blades: Keep your hands and other body parts away from moving fan blades. Installation and Configuration... - Page 19 TS-x53DU User Guide • Other moving components: Keep your hands and other body parts away from other moving components. 1. Attach the case cover. • TS-453DU, TS-453DU-RP 1. Place the cover on the NAS. 2. Slide the cover forward. 3. Attach the screws that connect the case cover to the chassis. Installation and Configuration...
- Page 20 TS-x53DU User Guide • TS-853DU-RP, TS-1253DU-RP 1. Place the cover on the NAS. 2. Slide the cover forward. 3. Tighten the screws. Installation and Configuration...
-
Page 21: Drive Installation
The TS-x53DU is compatible with 3.5-inch and 2.5-inch hard drives, and 2.5-inch solid state drives. Installing 3.5-inch Hard Drives on 3.5-inch Trays For the list of compatible drive models, go to https://www.qnap.com/compatibility. Warning • Installing a drive deletes all data on the drive. - Page 22 TS-x53DU User Guide 1. Power off the NAS. 2. Remove the drive tray. a. Pull the tray handle outward. b. Pull the tray out. 3. Install a drive on the tray. a. Place the tray on the drive so that the holes on the tray are aligned with those on the drive. b.
- Page 23 TS-x53DU User Guide 4. Load the tray into the bay. a. Insert the tray into the bay. b. Slide the tray into the bay. c. Push the handle. d. Lock the tray. Installation and Configuration...
- Page 24 TS-x53DU User Guide 5. Power on the NAS. Installing 2.5-inch Hard Drives or Solid State Drives on 3.5-inch Trays For the list of compatible drive models, go to https://www.qnap.com/compatibility. Warning • Installing a drive deletes all data on the drive.
- Page 25 TS-x53DU User Guide 3. Install a drive on the tray. a. Place the tray on the drive so that the holes on the tray are aligned with those on the drive. b. Attach the screws. 4. Load the tray into the bay. Installation and Configuration...
-
Page 26: Installing Expansion Cards
5. Power on the NAS. Installing Expansion Cards The TS-x53DU supports selected expansion cards, some of which require QNAP PCIe brackets. QNAP- branded expansion cards purchased from the company website are shipped with the brackets necessary to fit the TS-x53DU. - Page 27 TS-x53DU User Guide 1. Remove the case cover. For details, see Removing the Case Cover. 2. Remove the PCIe cover. • TS-453DU, TS-453DU-RP 1. Remove the screw that secures the cover to the bracket. 2. Pull the bracket away from the slot. 3.
- Page 28 3. Optional: Attach the QNAP bracket to the expansion card. a. Remove all screws of the existing bracket. b. Carefully pull the bracket away from the card. c. Attach the QNAP bracket to the card using the same screws. Installation and Configuration...
- Page 29 TS-x53DU User Guide d. Verify that the bracket does not move. 4. Install the expansion card. • TS-453DU, TS-453DU-RP 1. Hold the card by the edges. 2. Insert the card into the riser card slot. 3. Attach the screw. 4. Insert the riser card into the slot. 5.
-
Page 30: Replacing Memory Modules
TS-x53DU User Guide • TS-853DU-RP, TS-1253DU-RP 1. Hold the card by the edges. 2. Insert the card into the slot. 3. Attach the screw. 5. Attach the case cover. For details, see Attaching the Case Cover. Replacing Memory Modules The TS-x53DU has two memory slots. You can increase the memory capacity of the NAS by upgrading the memory modules. - Page 31 TS-x53DU User Guide Use only QNAP modules of the same type and capacity to maintain system performance and stability. You can purchase QNAP memory modules from authorized resellers. Important Ensure that both memory modules are identical. Warning • Observe electrostatic discharge (ESD) procedures to avoid damage to components.
- Page 32 TS-x53DU User Guide b. Verify that the module has tilted upward and is completely released from the slot. Warning Attempting to remove a module that is not completely released may damage the module and the motherboard. c. Hold the module by the edges. 6.
-
Page 33: Hot-Swapping Redundant Power Supply Units
TS-x53DU User Guide 7. Attach the case cover. For details, see Attaching the Case Cover. 8. Connect all cables and external attachments. 9. Connect all cables and external attachments. 10. Power on the NAS. 11. Verify that the module is recognized by the NAS. a. - Page 34 TS-x53DU User Guide 4. Insert the new PSU. • TS-453DU-RP • TS-853DU-RP, TS-1253DU-RP Installation and Configuration...
-
Page 35: Expansion Unit Installation
Expansion Unit Installation The TS-x53DU is compatible with both SATA expansion units and USB expansion units. For details, please see table below. You can purchase storage expansion accessories from QNAP or an authorized reseller. For details, go to https://shop.qnap.com/. Expansion Unit Model... - Page 36 TS-x53DU User Guide Expansion Unit Model Description Required Accessories TL-D800C • Uses a USB 3.2 Gen 2 Type-C • USB 3.2 Gen 2 Type-A to interface Type-C cable • Supports SATA drives • USB 3.2 Gen 2 Type-C to Type-C cable TL-D400S •...
- Page 37 2. Install a host bus adapter on the PCIe slot. Important The QNAP QXP host bus adapter is required for connecting the SATA JBOD enclosure to a host device. Third-party host bus adapters are not compatible with QNAP JBOD enclosures.
-
Page 38: Installing Handles
TS-x53DU User Guide 4. Power on the SATA JBOD expansion units. 5. Power on the NAS. 6. Verify that the expansion units are recognized by the NAS. a. Log on to QTS as administrator. b. Go to Main Menu > Storage & Snapshots > Overview > Storage > System . c. - Page 39 TS-x53DU User Guide 3. Install the angle bracket on the NAS. a. Align the holes on the angle bracket with the holes on the chassis. Note Ensure that the handle faces the same direction as the front panel. b. Attach the screws. 4.
-
Page 40: Rail Kits
Rail kits are not included with the NAS and must be purchased separately. For details, contact an authorized reseller or go to http://shop.qnap.com. You can find installation information in the rail kit package. QTS Installation The TS-x53DU uses the QNAP QTS operating system. You can install QTS using any of the following methods. Method Description... -
Page 41: Installing Qts Using Qfinder Pro
ASCII characters. 7. Click Next. 8. Specify the time zone, date, and time. QNAP recommends connecting to an NTP server to ensure that the NAS follows the Coordinated Universal Time (UTC) standard. 9. Click Next. 10. Select Obtain an IP address automatically (DHCP). -
Page 42: Installing Qts Using The Cloud Key
1. Power on the NAS. 2. Connect the NAS to the internet. 3. Go to the QNAP Cloud Installation page using one of the following methods: • On your computer, go to http://install.qnap.com/. • Scan the QR code on the NAS using a mobile device. -
Page 43: Installing Qts Using An Hdmi Connection
Installing QTS deletes all data on the drives. Back up your data before proceeding. 1. Connect an HDMI display to the NAS. 2. Connect a USB keyboard to the NAS or prepare the QNAP IR remote control (not available on all models). - Page 44 TS-x53DU User Guide Warning Clicking Next deletes all data on the drive before installing QTS. 11. Click Next. QTS is installed. Installation and Configuration...
-
Page 45: Basic Operations
TS-x53DU User Guide 4. Basic Operations This chapter describes basic NAS operations. Power Button Operation User Action Result Power on Press the button once. The NAS powers on. Power off Press and hold the button for 1.5 The NAS powers off. seconds. -
Page 46: Leds
TS-x53DU User Guide LEDs LEDs indicate the system status and related information when the device is powered on. The following LED information applies only when the drive is correctly installed and when the device is connected to the network or to a host. For details on the location of the LEDs, see Components Basic Operations... - Page 47 TS-x53DU User Guide Status Description System Status Flashes green and red alternately • The drive is being formatted. every 0.5 seconds • The device is being initialized. • The operating system is being updated. • RAID rebuilding is in progress. •...
- Page 48 • The drive can be accessed. • The device is powered on. No drive is detected. Expansion Unit Blue A QNAP USB or SATA external storage device is connected. • TS-853DU-RP No USB or SATA external storage devices connected. • TS-1253DU-RP...
-
Page 49: Audio Alert
TS-x53DU User Guide Audio Alert Duration Frequency Description Short beep (0.5 seconds) 1 • The NAS is starting up. • The NAS is shutting down (software shutdown). • The user pressed the Reset button. • The operating system was updated. The user tried to copy the NAS data to the external storage device from the front USB port, but the data cannot be copied. -
Page 50: Troubleshooting
TS-x53DU User Guide 5. Troubleshooting This chapter describes basic troubleshooting information. Forcing Qfinder Pro or myQNAPcloud to Locate the NAS If Qfinder Pro or myQNAPcloud is unable to locate the NAS during QTS installation, the drives or data may be faulty. 1. -
Page 51: Recovering Unintentionally Removed Healthy Drives
RAID Recovery Support Maximum Number of Removed Drives Single JBOD RAID 0 RAID 1 RAID 5 RAID 6 RAID 10 Support and Other Resources QNAP provides the following resources: Resource Documentation https://docs.qnap.com Service Portal https://service.qnap.com Downloads https://download.qnap.com Community Forum https://forum.qnap.com... -
Page 52: Glossary
Provides various remote access services such as DDNS and myQNAPcloud Link myQNAPcloud ID Email address that was used to register for a myQNAPcloud account Qfinder Pro QNAP utility that lets you locate and access QNAP NAS devices in your local area network QNAP NAS operating system Glossary... -
Page 53: Notices
No license, express or implied, by estoppels or otherwise, to any intellectual property rights is granted by this document. Except as provided in QNAP's terms and conditions of sale for such products, QNAP assumes no liability whatsoever, and QNAP disclaims any express or implied warranty, relating to sale and/or use of QNAP products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. - Page 54 TS-x53DU User Guide Free Software Foundation, use the GNU General Public License for most of our software; it applies also to any other work released this way by its authors. You can apply it to your programs, too. When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for them if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new free programs, and that you know you can do these things.
- Page 55 TS-x53DU User Guide tells the user that there is no warranty for the work (except to the extent that warranties are provided), that licensees may convey the work under this License, and how to view a copy of this License. If the interface presents a list of user commands or options, such as a menu, a prominent item in the list meets this criterion.
- Page 56 TS-x53DU User Guide You may convey verbatim copies of the Program's source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice; keep intact all notices stating that this License and any non-permissive terms added in accord with section 7 apply to the code;...
- Page 57 TS-x53DU User Guide the object code. If the place to copy the object code is a network server, the Corresponding Source may be on a different server (operated by you or a third party) that supports equivalent copying facilities, provided you maintain clear directions next to the object code saying where to find the Corresponding Source.
- Page 58 TS-x53DU User Guide a. Disclaiming warranty or limiting liability differently from the terms of sections 15 and 16 of this License; or b. Requiring preservation of specified reasonable legal notices or author attributions in that material or in the Appropriate Legal Notices displayed by works containing it; or c.
- Page 59 TS-x53DU User Guide An “entity transaction” is a transaction transferring control of an organization, or substantially all assets of one, or subdividing an organization, or merging organizations. If propagation of a covered work results from an entity transaction, each party to that transaction who receives a copy of the work also receives whatever licenses to the work the party's predecessor in interest had or could give under the previous paragraph, plus a right to possession of the Corresponding Source of the work from the predecessor in interest, if the predecessor has it or can get it with reasonable efforts.
- Page 60 TS-x53DU User Guide If conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot convey a covered work so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not convey it at all.
-
Page 61: Ce Notice
Important Any modifications made to this device that are not approved by QNAP Systems, Inc. may void the authority granted to the user by the FCC to operate this equipment. VCCI Notice この装置は、クラス... -
Page 62: Bsmi Notice
TS-x53DU User Guide BSMI Notice 警告使用者：這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，在 這種情況下，使用者會被要求採取某些適當的對策。 SJ/T 11364-2006 本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的年限。本产品 可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 0 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出...
