USER'S
USER'S
MANUAL
MANUAL
USB-SCSI-DB25 model
1.
In most cases - you will plug a male DB25 cable (most likely included with your existing
SCSI device) directly to the DB25 female connector of the USB XpressSCSI. In some
instances a gender changer may be required to properly connect to your cable or device.
2.
Be sure the cable is firmly attached to your SCSI device. Built-in hex nuts are provided for
secure attachment.
Plug a male DB25 cable directly to
the female DB25 connector on the
USB XpressSCSI.
20
SCSI terminator.
?
