Connecting to a USB Hub (using with other USB devices):
1.
Connect the USB hub (purchased separately) to your computer's USB port.
2.
Then connect the USB connector of the USB XpressSCSI to a port on the USB hub.
Make sure the connectors are secured firmly.
Enlarged view
Attach the USB connector from
the USB XpressSCSI to the USB
port on the USB hub
Using the USB XpressSCSI
The USB XpressSCSI cable by itself is "hot-pluggable," that is it can be safely attached to and
detached from a live system. It is important to note however - SCSI devices are not hot-plug-
gable (based on industry standards). When SCSI devices are attached to the USB XpressSCSI,
you should not attempt to hot-plug the USB XpressSCSI to or from your computer.
Instead, when making changes to your hardware setup while SCSI devices are connected to the
USB XpressSCSI, (for example adding or removing SCSI) you should restart your computer.
17
?
HELP
CONTENTS
USB XpressSCSI
Enlarged view
Attach the USB connector from the USB hub
to the USB port on your computer
