USER'S

MANUAL

Click Here to Begin

For models:

USB-SCSI-DB25

USB-SCSI-HD50

Connect up to seven SCSI devices

to your USB compatible Mac or PC.

Works great with existing SCSI

devices.

XpressSCSI

USB to SCSI

CONTENTS

Version 1.0

Converter Cable

HELP

CONTACT

BACK

Table of Contents

Need help?

Do you have a question about the USB XpressSCSI and is the answer not in the manual?

Questions and answers

Summary of Contents for Microtech USB XpressSCSI

Page 1 USER'S USER'S MANUAL MANUAL XpressSCSI Click Here to Begin USB to SCSI Converter Cable For models: USB-SCSI-DB25 USB-SCSI-HD50 Connect up to seven SCSI devices to your USB compatible Mac or PC. Works great with existing SCSI devices. HELP BACK NEXT CONTENTS CONTACT Version 1.0...
Page 2 USER'S USER'S MANUAL MANUAL USB XpressSCSI CONTENTS Home How to use this Online Guide Getting Started Connecting to a Macintosh Connecting to a PC Compatible Troubleshooting and Obtaining Technical Support Contacting Microtech HELP BACK NEXT CONTENTS CONTACT...
Page 3: How To Use
USER'S USER'S MANUAL MANUAL USB XpressSCSI HOW TO USE This Online Guide Controls in this Online Guide Controls within Adobe ® Acrobat ® Reader HELP BACK NEXT CONTENTS CONTACT...
Page 4 Go to the Table of Contents. CONTENTS Go to this page ("How to Use This Online Guide"). HELP How to contact Microtech via e-mail, telephone, fax, or standard mail. CONTACT Go to next page. NEXT Go back to previous page.
Page 5: What's The Difference Between
USB XpressSCSI GETTING STARTED Introduction What's the difference between part# USB-SCSI-DB25 and part# USB SCSI-HD50? What's included with Register your USB XpressSCSI for the USB XpressSCSI a chance to win an Apple iMac. Click here more info... Registering the USB XpressSCSI...
Page 6 Thank you for purchasing the USB XpressSCSI from Microtech International, Inc. The USB XpressSCSI is a USB to SCSI converter for new Apple iMac, Apple G3, and PC Compatible owners who wish to use their existing SCSI peripherals such as hard drives, Zip drives, and CD- ROM drives on a USB enabled system.
Page 7: System Requirements
USER'S USER'S USB XpressSCSI MANUAL MANUAL What's included with the USB XpressSCSI: The USB XpressSCSI includes the following: USB XpressSCSI Converter Cable Microtech Installer CD Quick-Start Guide Warranty Registration Card System Requirements: PC Compatible: Desktop or laptop PC Compatible with a USB port...
Page 8 MANUAL Registering the USB XpressSCSI Thank you again for purchasing the Microtech USB XpressSCSI. In order for us to better serve you, we encourage you to register your USB XpressSCSI as soon as possible. There are several benefits to registering the USB XpressSCSI: Registering your USB XpressSCSI entitles you to free periodic driver software updates when available.
Page 9 Installation Overview Connecting a SCSI Device Connecting and using more than one SCSI Device SCSI Addressing SCSI Termination Installing the Driver Software Connecting to the USB Port Connecting to a USB Hub Using the USB XpressSCSI HELP BACK NEXT CONTENTS CONTACT...
Page 10: Installation Overview
Microtech includes accessories to help make setup as convenient and hassle free as possible. The SCSI connector on your USB XpressSCSI model may or may not be the appropriate SCSI connector to use in your system configuration (depending on the type of connectors on your SCSI device(s) and the type of USB XpressSCSI you purchased).
Page 11 In most cases - you will plug a male DB25 cable (most likely included with your existing SCSI device) directly to the DB25 female connector of the USB XpressSCSI. In some instances a gender changer may be required to properly connect to your cable or device.
Page 12 SCSI chain. Please note, the SCSI connector on your USB XpressSCSI model may or may not be the appropriate SCSI connector to use in your system configuration (depending on the SCSI connec- tion required for your hardware setup and the USB XpressSCSI model you purchased).
Page 13 USER'S USER'S USB XpressSCSI MANUAL MANUAL The order of the SCSI devices to be connected can be changed. Be sure to assign a unique SCSI ID address to each device on your SCSI chain. The last device in the SCSI chain must be terminated.
Page 14: Scsi Termination
USER'S USER'S USB XpressSCSI MANUAL MANUAL SCSI Addressing The SCSI standard supports connection from one computer to up to seven SCSI devices. When more than one SCSI device is connected to your computer it is referred to as a SCSI chain.
Page 15: Installing The Driver Software
USB Hub"(page 17). Installation note: If you attempt to attach the USB connector to the USB port of your Macintosh or hub prior to installing the USB XpressSCSI drivers you may receive the following (or a similar) message: If this occurs, click "OK", install the driver software, and then attach the USB connector. For more information on attaching USB devices proceed to the section "Connecting to the USB Port"...
Page 16: Connecting To The Usb Port
MANUAL Connecting to the USB Port: Connect the USB connector of the USB XpressSCSI to the USB port on your Macintosh. In the case of the Apple iMac, USB ports are located both on the side of the iMac as well as on the keyboard.
Page 17 USB hub Using the USB XpressSCSI The USB XpressSCSI cable by itself is "hot-pluggable," that is it can be safely attached to and detached from a live system. It is important to note however - SCSI devices are not hot-plug- gable (based on industry standards).
Page 18 Installation Overview Connecting a SCSI device Connecting and using more than one SCSI Device SCSI Addressing SCSI Termination Connecting to the USB Port Connecting to a USB Hub Installing the Driver Software Using the USB XpressSCSI HELP BACK NEXT CONTENTS CONTACT...
Page 19 Microtech includes accessories to help make setup as convenient and hassle free as possible. The SCSI connector on your USB XpressSCSI model may or may not be the appropriate SCSI connector to use in your system configuration (depending on the type of connectors on your SCSI device(s) and the type of USB XpressSCSI you purchased).
Page 20 In most cases - you will plug a male DB25 cable (most likely included with your existing SCSI device) directly to the DB25 female connector of the USB XpressSCSI. In some instances a gender changer may be required to properly connect to your cable or device.
Page 21 SCSI chain. Please note, the SCSI connector on your USB XpressSCSI model may or may not be the appropriate SCSI connector to use in your system configuration (depending on the SCSI connec- tion required for your hardware set up and the USB XpressSCSI model you purchased).
Page 22 USER'S USER'S USB XpressSCSI MANUAL MANUAL Securely plug each cable end into each connector and then fasten with the built-in clamps or screws. The order of the SCSI devices to be connected can be changed. Be sure to assign a unique SCSI ID address to each device on your SCSI chain.
Page 23 USER'S USER'S USB XpressSCSI MANUAL MANUAL SCSI Addressing The SCSI standard supports connection from one computer to up to seven SCSI devices. When more than one SCSI device is connected to your computer it is referred to as a SCSI chain.
Page 24 USB XpressSCSI MANUAL MANUAL Connecting to the USB Port: Connect the USB connector of the USB XpressSCSI to the USB port located at the back of the computer. Enlarged view Attach the USB connector from the USB XpressSCSI to the USB port on your computer Make sure the cable ends are firmly connected.
Page 25 Connecting to a USB Hub (using with other USB devices): Connect the USB hub (purchased separately) to your computer's USB port. Then connect the USB connector of the USB XpressSCSI to a port on the USB hub. Make sure the connectors are secured firmly.
Page 26 USER'S USER'S USB XpressSCSI MANUAL MANUAL Installing the Driver Software PC Compatible Installation (Windows 98 or above): Follow the hardware installation instructions as described previously in this chapter. After connecting to your USB port, you should see a notification on your computer advising "New Hardware Found"...
Page 27 USER'S USB XpressSCSI MANUAL MANUAL Set the "New Hardware Wizard" to search your CD drive for drivers. Insert the Microtech Installer CD. Click next. Click Next. Click "Next" to install the driver. Click Next. Click "Finish". Installation is now complete.
Page 28 USB XpressSCSI MANUAL MANUAL Using the USB XpressSCSI The USB Xpress SCSI is hot-pluggable on the Windows 98 operating environment, meaning that you can connect and disconnect the cable from your computer without having to shutdown. However, you must be sure that none of the devices are being accessed before you remove the cable from the PC.
Page 29: Troubleshooting
USER'S USER'S MANUAL MANUAL USB XpressSCSI TROUBLESHOOTING and Obtaining Technical Support Solutions to Common Problems Contacting Technical Support Returning Products for Service Technical Specifications Microtech Limited Warranty HELP BACK NEXT CONTENTS CONTACT...
Page 30: Solutions To Common Problems
A: The USB XpressSCSI Adapter is a connectivity solution that allows for a SCSI-based peripheral to be connected to a USB port on a host or hub. The USB XpressSCSI Adapter does not permit the use of USB devices on an older SCSI-based Macintosh.
Page 31 How many SCSI devices can I connect to the USB XpressSCSI Adapter? A: You can connect up to 7 SCSI devices to the USB XpressSCSI. The SCSI connector on my USB XpressSCSI does not appear to be the same as on my SCSI device(s) — how do I connect them? A.
Page 32: Returning Products For Service
Any package that does not carry an RMA number will be refused by Microtech’s Receiving Department. Pack the USB XpressSCSI in its original box. Be certain that it fits snugly and is surrounded with the original packing material.
Page 33: Technical Specifications
MANUAL Technical Specifications The Microtech USB XpressSCSI - USB to SCSI adapter is an intelligent cable that complies with the Universal Serial Bus Specification version 1.1. The Adapter comprises an intelligent 4 wire shielded USB High Speed cable with a USB Series A Connector molded into an embedded circuit board which has a SCSI Connector as output..
Page 34 USER'S USER'S USB XpressSCSI MANUAL MANUAL Reliability 10,000 SCSI attachments and disconnections. Connectors HD50 Connector-SCSI Side 1.27Mm pitch 50 pin Micro-D plug. DB25 Connector IEEE 1284-A Receptacle. USB Side. High Speed compliant Series A. Compatibility Any USB Specification 1.1 compliant host.
Page 35 Microtech within ninety (90) days after the date of purchase. If you discover a defect, Microtech will, at its option, repair or replace this product with a new or reconditioned product at no charge to you, provided you return it during the warranty period, with transportation charges prepaid, to Microtech.
Page 36 1985. Since then we have grown to include offices in California and Japan. Microtech is well known throughout the world for its innovative products and exceptional customer service, and boasts the largest installed base of satisfied storage and memory customers in the Macintosh arena.
Page 37 Copyright Information The contents of this manual are copyrighted by Microtech International, Inc. and may not be reproduced in whole or in part without written permission of Microtech International, Inc. The same proprietary and copyright notices must be affixed to any permitted copies as were affixed to the original.
