Table of Contents
NO.
Name
Mirror
1
2
V2
3
M
4
5
S
6
V1
7
MIC
8
Touch Screen
9
SD Card Slot
10
Video Input (1)
11
Video Input (2)
12
Bracket Chassis
13
Car Camera Input
14
Battery (yellow)
15
ACC (Red)
16
Gnd(black)
17
Camera Trigger Line(Green)
18
Fuse
Description
Standard Mirror or Auto Dimming Mirror
Video Input#2
Switch from Video mode to GPS mode
Press and hold to turn on/off the device
Mute or Turns On/Off Auto dimming Functions
Video Input #1
Bluetooth Microphone
4.3 inch touch screen
Supports up to 8GB SD card
Video Input (v1 button selected)
Video Input (v2 button selected)
Attach Vehicle Specific Bracket Here
Rear Camera Input Port
12V+ Constant power supply
12V+ ACC power supply
Chassis ground
Trigger for backup camera signal switching
Serviceable fuse
