Daewoo KOR-1A1G0A Service Manual page 39

EXPLODED VIEW AND PARTS LIST
(1) KOR-1A1G/H
REF.NO. PART CODE
A00 3511711200
B00 PKCPSWXN00 CONTROL-PANEL AS
PKCPSWXP00 CONTROL-PANEL AS
PKCPSWXY00 CONTROL-PANEL AS
PKCPSWXZ00 CONTROL-PANEL AS
F01 3510802500
F02 7S312X10A1 SPECIAL TAPPING
F03 3516110400
3516110410
F04 7122401211
F05 7122401211
F06 7112401011
F07 35113TANOH CORD POWER AS
35113YCNS5 CORD POWER AS
35113UANT5 CORD POWER AS
35113UHWT5 CORD POWER AS
F08 4413A90012
F09 7122401211
F10 7121403011
F11 3518605800
F12 7121403011
F13 3963821600
F14 3512517000
F15 3511800300
F16 3518002900
3518002800
F17 3516004000
F18 7272100811
F19 3513003200
F20 3518302200
F21 3518400400
F22
F23 3518113800
3518116900
F24 3516003700
F25 3510312400
F26 7112401011
F27 3512100900
F28 7272400811
F29 3515202800
PART NAME
DOOR AS
CABINET
CAVITY AS
CAVITY AS
SCREW TAPPING
SCREW TAPPING
SCREW TAPPING
CLAMP POWER CORD
SCREW TAPPING
FUSE
HOLDER FUSE
SCREW TAPPING
MOTOR SHADED POLE
GUIDE WIND
FAN
MAGNETRON
MAGNETRON
SPECIAL SCREW
SCREW TAPTITE
HOLDER HV CAPACITOR SECC T0.6
CAPACITOR HV
DIODE HV
HARNESS B
TRANS HV
TRANS HV
SPECIAL SCREW
BASE
SCREW TAPPING
FOOT
SCREW TAPTITE
STOPPER HINGE *U AS
DESCRIPTION
KOR-1A1G0A
KOR-1A1G0A
KOR-1A1H0A
KOR-1A1G2A
KOR-1A1H2A
PCM T0.6
T1 TRS 4*10 MFZN
KOR-1A1G0A
KOR-1A1G2A
T2S TRS 4*12 MFZN
T2S TRS 4*12 MFZN
T1 TRS 4*10 MFZN
3X16AWG 40X40 120-RTMI
3X0.75 40X40 120-RTMI
3X14AWG 60X60 120-RTMI
3X14AWG 80X80 120-RTMI
NYLON66
T2S TRS 4*12 MFZN
65TS 125V 20A
NYLON66
T2S TRS 4*30 MFZN
120V 21W OEM-10DWX1-A07
PP
PP+30%GLASS
2M218J(MF) P
2M248J(DW)-N
T2 BOLD FLANGE 5X12 DACRO
TT3 TRS 4X8 MFZN
2100VAC 0.98uF #187
HR-1X-3AB 12KV #187
DY-N95A0-16T
DY-N11A0-1AT
TT3 HEX 4X8 FLG MFZN
SBHG T0.8
T1 TRS 4X10 MFZN
PP DASF-130
TT3 TRS 4X8 MFZN
KOR -121M0A
38
Q' TY REMARK
1
1 1A1G0A / -1A
1 1A1H0A / -1A
1 1A1G2A / -4A
1 1A1H2A / -4A
1
3
1 1A1G(H)0A / -1A
1 1A1G(H)2A / -4A
1
1
1
1 1A1G(H)0A
1 1A1G(H)1A
1 1A1G(H)2A
1 1A1G(H)4A
1
1
1 1A1G(H)0A / -2A
1 (ONLY UL MODEL)
2
1
1
1
1 1A1G(H)0A / -1A
1 1A1G(H)2A / -4A
1
1
1
1
1
1
1 1A1G(H)0A / -1A
1 1A1G(H)2A / -4A
4
1
5
2
1
1
