PRINTED CIRCUIT BOARD
3. P.C.B. LOCATION NO
NO. NAME
1 BUZZER
2 C ARRAY
3 CAPACITOR ELEC
4 CAPACITOR ELEC
5 CONNECTOR WAFER
6 CONNECTOR WAFER
7 CONNECTOR WAFER
8 DIODE RECTIFY
9 DIODE RECTIFY
10 DIODE ZENER
11 DIODE ZENER
12 LED DISPLAY
13 PCB MAIN
14 R ARRAY
15 RESISTOR
16 RESISTOR
17 RESISTOR
18 RESISTOR
19 RESISTOR
20 RESISTOR
21 RESISTOR
22 REGULATOR
23 TRANSISTOR
24 TRANSISTOR
25 TRANS POWER
26 WIRE COPPER
27 WIRE COPPER
28 IC MICOM
29 RESONATOR CERA
30 SW RELAY
31 SW RELAY
32 CAPACITOR CERA
33 CAPACITOR CERA
SYMBOL
BZ1
CA1
EC1
EC2
CN1
CN2
CN3
D1~5, 7~10
D13, 14
ZD1
ZD2
DP1
M158
RA1
R1 ~ R5
R8, 10, 12, 14, 22
R11, 20, 21
R13
R15, 17
R18
R19
VL1
Q1 ~ 5, 9 ~ 11
Q6
LVT1
J1 - J21
SJ2, 3, 5
IC1
CR1
RY1
RY2
C6
C1 ~ 5, C7
SPECIFICATION
BM-20K
7P(6) 102M 50V
16V RSS 100uF
25V RSS 1000uF
YW396-02AV
YW396-05AV
FCZ254-11
1N4148
1N4002A
MTZ 5.1VB 1/2W
MTZ 3.9VB 1/2W
DDG-631H
81.5 X 139.9
7P(6) 1/8 100K J
1/6W 330 5%
1/6W 1K 5%
1/6W 100K 5%
1/6W 100 5%
1/6W 10K 5%
1/6W 1M 5%
1/4W 51 5%
MC7905C
KRA-102M
KTA-1270Y
DMR-631P
1/0.52 TIN COATING
1/0.52 TIN COATING
TMP47C440BN
KBR-4.0MSTF
G5G-1A DC12V
G5B-1 DC12V
102 50V Z AXIAL
104 50V Z AXIAL
36
PART CODE Q' TY
3515600100 1
CN4XB-102M 1
CEXF1C101V 1
CEXF1E102V 1
3519150520 1
3519150510 1
441M367160 1
DZN4148--- 10
DZN4002A-- 2
DZTZ5R1B-- 1
DZTZ3R9B-- 1
DDDG631H-- 1
3514315410 1
RA-87X104J 1
RD-AZ331J- 7
RD-AZ102J- 5
RD-AZ104J- 3
RD-AZ101J- 1
RD-AZ103J- 3
RD-AZ105J- 1
RD-4Z510J- 1
1MC7905C-- 1
TZRA102M-- 8
TZTA1270Y- 1
5EPU035302 1
85801052GY 21
85801052GY 3
13GS1A1GH0 1
5PKBR40MKS 1
5SC0101121 1
5SC0101110 1
CCZB1H102K 1
CCZF1H104Z 6
