Daewoo KOR-1A1G0A Service Manual page 16

4. Method to reduce the gap between the door seal and the oven front surface.
1) To reduce gap located on part ' A'
Loosen two screws on stopper hinge top, and then
push the door to contact the door seal to oven front surface.
Tighten two screws.
2) To reduce gap located on part ' B'
Loosen two screws on stopper hinge under, and then
push the door to contact the door seal to oven front surface.
Tighten two screws.
3) To reduce gap located on part ' C'
Loosen a screw on interlock switch assembly located top of oven body.
Draw the interlock switch assembly inward as possible to engage with hook on the door bottom.
Tighten a screw.
4) To reduce gap located on part ' D'
Loosen a screw on interlock switch asembly located bottom of oven body.
and (4) are same as step (3).
NOTE
A small gap may be acceptable if the microwave leakage does not exceed 4mW/
DISASSEMBLY AND ASSEMBLY
2
cm
15
