- Page 1 MICROWA VE OVEN KOR-1A0AM OPERATING INSTRUCTIONS Before operating this oven, please read these instructions completely.
-
Page 2: Table Of Contents
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. -
Page 3: Earthing Instructions
EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug. The plug must be plugged into an outlet that is properly installed and earthed. -
Page 4: Specifications
SPECIFICATIONS POWER SUPPLY 220V~60Hz SINGLE PHASE WITH EARTHING POWER CONSUMPTION 1400 W MICROWAVE OUTPUT POWER 1000 W FREQUENCY 2450 MHz OUTSIDE DIMENSIONS (W X H X D) 539 x 300 x 406 mm (21.2 x 11.8 x 16.0 in.) CAVITY DIMENSIONS (W X H X D) 354 x 228 x 370 mm (13.9 x 9.0 x 14.6 in.) NET WEIGHT APPROX. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven: 1. -
Page 6: Features Diagram
FEATURES DIAGRAM 1. Door latch - When the door is closed it will 6. Door release button - Pushing this button automatically lock shut. If the door is opened stops oven operation and opens the door. while the oven is operating, the magnetron will automatically shut off. - Page 7 FEATURES DIAGRAM (continued) TIMER LOCK 1. Bread 2. Soup AUTO 3. Baked Potato COOK 4. Fresh Vegetable 5. Frozen Vegetable One Touch Dish Warmer Frozen Pizza Beverage Pasta Auto Defrost Fish Poultry Meat Kitchen Power Defrost Clock Timer Stop/Clear Start/Speedy Cook 10.
-
Page 8: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into 220V AC 60Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking. -
Page 9: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash ":0" and a tone will sound. If the AC power ever goes off, the display shows ":0" when the power comes back on. 1. Touch CLOCK pad. NOTE: This oven has multiple clock This is a 12 hour clock system. -
Page 10: Weight Defrosting
WEIGHT DEFROSTING WEIGHT DEFROSTING lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. 1. Touch MEAT pad. The DEFROST & g indicator light and "500" is displayed. MEAT The display will show what you touched. 2. -
Page 11: Cooking In One Stage
COOKING IN ONE STAGE 1. Touch POWER pad. The M/W indicator lights. (Select desired power level.) The display will show what you touched. POWER NOTE: If steps 1nd 2 are omitted, the oven will cook at full power. 2. Touch the number pads for the cooking time. This example shows power level 5. -
Page 12: Kitchen Timer Mode
KITCHEN TIMER MODE Timer operates as a minute timer, can be set to delay cooking and used as a hold setting after cooking.However delay cooking can not be programmed for defrost. Timer operates without microwave energy. HOW TO USE AS A MINUTE TIMER 1. -
Page 13: Speedy Cook
SPEEDY COOK SPEEDY COOK allows you to reheat for 30 seconds at 100% (full power) by simply touching the SPEEDY COOK pad. By repeatedly touching the SPEEDY COOK pad, you can also extend reheating time to 5 minutes by 30 second increments. 1. - Page 14 ONE TOUCH COOKING (CONTINUED) 1. Pour beverage in microwave mug. When you touch BEVERAGE pad once, "1" Place it on the turntable. is displayed. BEVERAGE Do not cover. Stir before serving. After 1.5 seconds, the display changes into 2. Touch BEVERAGE pad once cooking time of quantity and the oven starts for 1 cup, twice for 2 cups or cooking.
-
Page 15: Less, More
LESS, MORE To alter one touch cooking or cooking time whilst oven is in operation, use LESS or MORE.(except for defrosting) Press LESS/MORE to decrease/increase the one touch cooking time in multiples of 10 seconds. The overall one touch cooking time can be increased to a maximum of 99 minutes 50 seconds. Press LESS/MORE to decrease/increase the cooking time in multiples of 1 minute. -
Page 16: Utensil Test
UTENSIL TEST Dishes that do not absorb microwave energy are best for microwave cooking. Lock on the label to verify that particular cups, glasses, plates are indeed suitable, especially paper goods. If you are not sure, try this utensil test to check. •... -
Page 17: Care Of Your Microwave Oven
CARE OF YOUR MICROWAVE OVEN Turn the oven off before cleaning. This may occur when the microwave oven is operated under high humidity conditions and in In a method to clean the door seal area, you no way indicates malfunction of the unit. can use the mild detergent with a damp cloth in case that the food or something like that It is occasionally necessary to remove the... -
Page 18: Use Your Microwave Oven Safely
USE YOUR MICROWAVE OVEN SAFELY GENERAL USE Do not attempt to defeat or tamper with safety interlocks. Do not place any object between the oven front frame and the door or allow residue to build up on sealing surfaces. Wipe with a mild detergent, rinse and dry. Never use abrasive powders or pads. Do not subject the oven door strain or weight such as a child hanging on an open door. -
Page 19: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn't work; 1. Check that the power cord is securely plugged in. 2. Check that the door is firmly closed. 3. Check that the cooking time is set. 4. -
Page 20: Questions And Answers
QUESTIONS AND ANSWERS * Q : I accidentally ran my microwave oven without any food in it. Is it damaged? A : Running the oven empty for a short time will not damage the oven. However, it is not recommended. * Q : Can the oven be used with the glass tray or roller guide removed? A : No.
