S/M No. : R1A1G0A005
Service Manual

Microwave Oven

Model: KOR-1A0A0A
KOR-1A1G0A
KOR-1A1H0A
KOR-1A1G9A27
KOR-1A1H9A27
KOR-1A1H9A37
KOR-1A4G0A
KOR-1A4H0A
KOR-1A4H9A27
KOR-1A7G9A27
KOR-1A8Q0A
KOR-1A9H9A
KOR-1A9H9A27
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
Dec. 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOR-1A0A0A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo KOR-1A0A0A

Summary of Contents for Daewoo KOR-1A0A0A

  • Page 1: Microwave Oven

    S/M No. : R1A1G0A005 Service Manual Microwave Oven Model: KOR-1A0A0A KOR-1A1G0A KOR-1A1H0A KOR-1A1G9A27 KOR-1A1H9A27 KOR-1A1H9A37 KOR-1A4G0A KOR-1A4H0A KOR-1A4H9A27 KOR-1A7G9A27 KOR-1A8Q0A KOR-1A9H9A KOR-1A9H9A27 Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be operated with the door open. (b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other microwave source, and make repairs as necessary: (1) Interlock operation, (2) Proper door closing, (3) Seal and sealing surfaces (arcing, wear, and other damage), (4) Damage to or loosening of hinges and latches, (5) Evidence of dropping or abuse.

  • Page 3: Safety And Precautions

    1. SAFETY AND PRECAUTIONS 1. FOR SAFE OPERATION Damage that allows the microwave energy (that cooks or heats the food) to escape will result in poor cooking and may cause serious bodily injury to the operator. IF ANY OF THE FOLLOWING CONDITIONS EXIST, OPERATOR MUST NOT USE THE APPLIANCE. (Only a trained service personnel should make repairs.) 1) A broken door hinge.

  • Page 4: Specifications

    2. SPECIFICATIONS 1)KOR-1A0A, 1A1G(H) MODEL KOR-1A0A, 1A1G, 1A1H POWER SUPPLY 120V~60Hz, SINGLE PHASE WITH GROUNDING MICROWAVE 1400W POWER GRILL CONSUMPTION COMBINATION MICROWAVE ENERGY OUTPUT 1000W MICROWAVE FREQUENCY 2450MHz OUTSIDE DIMENSIONS (W X H X D) 539 x 300 x 406 mm (21.2 x 11.8 x 16.0 in.) CAVITY DIMENSIONS (W X H X D) 354 x 228 x 373 mm (13.9 x 9.0 x 14.7 in.) NET WEIGHT...
  • Page 5 3)KOR-1A7G MODEL KOR-1A7G POWER SUPPLY 120V~60Hz, SINGLE PHASE WITH GROUNDING MICROWAVE 1400W POWER GRILL CONSUMPTION COMBINATION MICROWAVE ENERGY OUTPUT 1000W MICROWAVE FREQUENCY 2450MHz OUTSIDE DIMENSIONS (W X H X D) 539 x 300 x 431 mm (21.2 x 11.8 x 16.9 in.) CAVITY DIMENSIONS (W X H X D) 354 x 228 x 373 mm (13.9 x 9.0 x 14.7 in.) NET WEIGHT...
  • Page 6 5) KOR-1A9H MODEL KOR-1A9H POWER SUPPLY 120V~60Hz, SINGLE PHASE WITH GROUNDING MICROWAVE 1400W POWER GRILL CONSUMPTION COMBINATION MICROWAVE ENERGY OUTPUT 1000W MICROWAVE FREQUENCY 2450MHz OUTSIDE DIMENSIONS (W X H X D) 539 x 300 x 409 mm (21.2 x 11.8 x 16.1 in.) CAVITY DIMENSIONS (W X H X D) 354 x 228 x 373 mm (13.9 x 9.0 x 14.7 in.) NET WEIGHT...

  • Page 7: External View

    3. EXTERNAL VIEW 1. OUTER DIMENSION 1)KOR-1A0A, 1A1G(H) 2) KOR-1A4G(H)
  • Page 8 3)KOR-1A7G 4)KOR-1A8Q...
  • Page 9 5)KOR-1A9H...

  • Page 10: Feature Diagram

    2. FEATURE DIAGRAM 1)KOR-1A0A, 1A1G(H), 1A8Q, 1A9H 1. DOOR SEAL Door seal surfaces prevent microwave escaping from the oven cavity. 2. DOOR HOOK When the door is closed, it will automatically lock shut. If the door is opened while oven operating, the magnetron tube will immediately stop operating.
  • Page 11 2)KOR-1A4G(H), 1A7G 1. DOOR SEAL Door seal maintains the microwave within the oven cavity and prevents microwave leakae. 2. DOOR HOOK When the door is closed, it will automatically lock shut. If the door is opened while oven operating, magnetron tube will immediately stop operating.

  • Page 12: Control Panel

    3. CONTROL PANEL 1)KOR-1A0A TIMER LOCK 1. Bread FROZEN 2. Soup POPCORN PIZZZA 3. Bread Potato 4. Fresh Vegetable 5. Frozen vegetable DINNER BEVERAGE AUTO PLATE COOK MORE LESS POWER DEFROST AUTO DEFROST MEAT POULTRY FISH KITCHEN CLOCK TIMER START/ STOP/CLEAR SPEEDY COOK 1 Time set pad - Used to set the cooking time and the present time.
  • Page 13 2)KOR-1A1G, 1A4G, 1A7G 1 Time set pad - Used to set the cooking time and the present time. 2 Display - Cooking time, power level, indicators and present time are displayed. 3 One touch - Used to cook or reheat specific quantities of food. 4 Auto cook - Used to cook or reheat.
  • Page 14 3)KOR-1A1H, 1A4H, 1A9H 1 Time set pad - Used to set the cooking time and the present time. 2 Display - Cooking time, power level, indicators and present time are displayed. 3 One touch - Used to cook or reheat specific quantities of food. 4 More - Used to add time to cooking.
  • Page 15 4)KOR-1A8Q 1 Time set pad - Used to set the cooking time and the present time. 2 Display - Cooking time, power level, indicators and present time are displayed. 3 One touch - Used to cook or reheat specific quantities of food. 4 Quick cook - Used to cook or reheat.

  • Page 16: Installation

    4. INSTALLATION 1. Steady, flat location. This microwave oven should be set on a steady, flat surface. 2. Leave space behind and side. All air vents should be kept a clearance. If all vents are covered during operation, the oven may be overheated and, eventually, cause oven failure.

  • Page 17: Control Panel

    5. OPERATIONS AND FUNCTIONS 1. Connect the main lead to an electrical outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray must always be in place during cooking. 3.

  • Page 18: Disassembly And Assembly

    6. DISASSEMBLY AND ASSEMBLY Cautions to be observed when troubleshooting. Unlike many other appliances, the microwave oven is high-voltage, high-current equipment. It is completely safe during normal operation. However, carelessness in servicing the oven can result in an electric shock or possible danger from a short circuit. You are asked to observe the following precautions carefully.
  • Page 19 1. To remove cabinet 1) Remove three screws on cabinet back. 2) Pull the cabinet backward. 2. To remove door assembly 1) Remove two screws which secure the stopper hinge top. 2) Remove the door assembly from top plate of cavity. 3) Reverse the above for reassembly.
  • Page 20 3. To remove door parts. 1)KOR-1A0A, 1A1G(H), 1A8Q, 1A9H REF NO. PART CODE PART NAME DESCRIPTION Q’TY REMARK 3517005900 BARRIER SCREEN *O 3512204330 ABS XR-401 KOR-1A0A0A KOR-1A1G(H)0A 3512204300 ABS XR-401 1A1G(H)9A27 FRAME DOOR 3512206070 ABS XR-401 SPRAY KOR-1A1H9A37 ONLY 3512204310 ABS XR-401 KOR-1A8Q0A...
  • Page 21 2) KOR-1A4G(H) REF NO. PART CODE PART NAME DESCRIPTION Q’TY REMARK 3511711300 DOOR PAINTING AS KOR-1A1G0A 3513100730 HOOK POM BLACK 3515101900 SPRING HOOK 3517005910 BARRIER-SCREEN * O GLASS T3.2 3512204321 FRAME DOOR ABS SG-175 3515202900 STOPPER HINGE * T AS KOR-121M0A 3512603301 HANDLE DOOR *U...
  • Page 22 3) KOR-1A7G REF NO. PART CODE PART NAME DESCRIPTION Q’TY REMARK 3511711300 DOOR PAINTING AS KOR-1A1G0A 3513100730 HOOK 3515101900 SPRING HOOK 3517005930 BARRIER-SCREEN * O GLASS T3.2 3512204370 FRAME DOOR ABS XR-401 SR-0320G 3515202900 STOPPER HINGE * T AS KOR-121M0A 3512602700 HANDLE DOOR * U ABS XR-401 H-2938...
  • Page 23 4. Method to reduce the gap between the door seal and the oven front surface. (1) To reduce gap located on part ‘A’ Loosen two screws on stopper hinge top, and then push the door to contact the door seal to oven front surface.
  • Page 24 5. To remove control panel parts. 1)KOR-1A0A, 1A1G(H), 1A8Q, 1A9H REF NO. PART CODE PART NAME DESCRIPTION Q’TY REMARK 3518522150 KOR-1A0A0A KOR-1A0A0A 3518522100 KOR-1A1G0A KOR-1A1G0A 3518522110 SWITCH MEMBRANE KOR-1A1H0A KOR-1A1H0A 3518570980 KOR-1A8Q0A KOR-1A8Q0A 3518523740 KOR-1A9H9A KOR-1A9H9A 3516722330 ABS AF-345 KOR-1A0A0A...
  • Page 25 2) KOR-1A4G(H) REF NO. PART CODE PART NAME DESCRIPTION Q’TY REMARK 3518522130 KOR-1A4G0A SWITCH MEMBRANE 3518522140 KOR-1A4H0A/1A 3516722320 CONTROL-PANEL ABS AF-315/345 HFA-700HT PKMPMSXN00 PCB AS KOR-1A1G0A 7122401211 SCREW TAPPING T2S TRS 4* 12 MFZN 3)KOR-1A7G REF NO. PART CODE PART NAME DESCRIPTION Q’TY REMARK...
  • Page 26 6. To remove high voltage capacitor. 1) Remove the screw which secure the grounding ring terminal of the H.V. diode and the capacitor holder. 2) Remove the H.V. diode from the capacitor holder. 3) Reverse the above steps for reassembly. High voltage circuit wiring 7.
  • Page 27 8. To remove wind guide assembly. 1) Remove a screw for earthing. (KOR-1A1G1A, KOR-1A7Q9D only) 2) Remove a screw which secure the wind guide assembly. 3) Draw forward the wind guide assembly. 4) Pull the fan from the motor shaft. 5) Remove two screws which secure the motor shaded pole.

  • Page 28: Interlock Mechanism And Adjustment

    7. INTERLOCK MECHANISM AND ADJUSTMENT The door lock mechanism is a device which has been specially designed to completely eliminate microwave radiation when the door is opened during operation, and thus to perfectly prevent the danger resulting from the leakage of microwave. 1)KOR-1A0A, 1A1G(H), 1A8Q, 1A9H 2)KOR-1A4G(H), 1A7G (1) Primary interlock switch...

  • Page 29: Troubleshooting Guide

    8. TROUBLESHOOTING GUIDE Following the procedure below to check if the oven is defective or not. 1. Check grounding before trouble checking. 2. Be careful of the high voltage circuit. 3. Discharge the high voltage capacitor. 4. When checking the continuity of the switches, fuse or high voltage transformer, disconnect one lead wire from these parts and check continuity with the AC plug removed.
  • Page 30 CONDITION CHECK RESULT CAUSE REMEDY Replace Defective Outlet has Check continuity of magnetron Continuity magnetron proper voltage Fuse does not Replace blow. Open power Check continuity of Continuity supply cord power supply cord Replace Normal Defective touch control circuit Replace Display do not shown Malfunction of countdown...
  • Page 31 (TROUBLE 3) No microwave oscillation even though fan motor rotates. CONDITION CHECK RESULT CAUSE REMEDY Continuity Replace Check continuity of high Defective high microwave voltage capacitor terminals voltage oscillation with wires removed transformer Continuity in Replace Check continuity of high voltage Defective high backward rectifier in forward and backward...
  • Page 32 (TROUBLE 4) The following visual conditions indicate a probable defective touch control circuit or membrane switch assembly. 1. Incomplete segments (1) Segments missing (2) Partical segments missing (3) Digit flickering other than normal display slight flickering (4) “ :0” does not display when power is on. 2.

  • Page 33: Mesurement And Test

    9. MEASUREMENT AND TEST 1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT Microwave output power can be checked by indirectly measuring the temperature rise of a certain amount of water exposed to the microwave as directed below. PROCEDURE 1. Microwave power output measurement is made with the microwave oven supplied at rated voltage and operated at its maximum microwave power setting with a load of 1000±5cc of potable water.

  • Page 34: Microwave Radiation Test

    2. MICROWAVE RADIATION TEST @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ?

  • Page 35: Component Test Procedure

    3. COMPONENT TEST PROCEDURE • High voltage is present at the high voltage terminal of the high voltage transformer during any cooking cycle. • It is neither necessary nor advisable to attempt measurement of the high voltage. • Before touching any oven components or wiring, always unplug the oven from its power source and discharge the capacitor.

  • Page 36: Wiring Diagram

    10. WIRING DIAGRAM 1)KOR-1A1G(H)9A27, 1A7G9A27, 1A9H9A27, 1A1H9A37, 1A4H9A27...
  • Page 37 2)KOR-1A0A0A, 1A1G(H)0A, 1A4G(H)0A, 1A8Q0A, 1A9H9A...

  • Page 38: Printed Circuit Board

    11. PRINTED CIRCUIT BOARD KOR-1A0A, 1A1G(H), 1A4G(H), 1A7G, 1A9H 1. CIRCUIT CHECK PROCEDURE 1. Low Voltage Transformer check • The low voltage transformer is located on the P.C.B. • Measuring condition: input voltage : 120V/Frequency : 60Hz Terminal Voltage LOAD NO LOAD AC 12.6 V AC 14.7 V...
  • Page 39 Measure Point...
  • Page 40 3. When there is no microwave oscillation 1) When touching START pad, oven lamp does not turn on. Fan motor do not rotate, but cook indicator in display comes on. * Cause : RELAY 2 does not operate. refer to Circuit Diagram (Point 3) - Check method POINT STATE...
  • Page 41 2. PCB CIRCUIT DIAGRAM...
  • Page 42 3. PCB LOCATION NO. NAME SYMBOL SPECIFICATION PART CODE Q’TY BUZZER BM-20K 3515600100 C ARRAY 7P(6) 102M 50V CN4XB-102M CAPACITOR ELEC 16V RSS 100UF CEXF1C101V CAPACITOR ELEC 25V RSS 1000UF CEXF1E102V CONNECTOR WAFER YW396-02AV 3519150520 CONNECTOR WAFER YW396-05AV 3519150510 CONNECTOR WAFER FCZ254-11 441M367160 DIODE RECTIFY...
  • Page 43 KOR-1A8Q 1. CIRCUIT CHECK PROCEDURE 1. Low Voltage Transformer check • The low voltage transformer is located on the P.C.B. • Measuring condition: input voltage : 120V/Frequency : 60Hz Terminal Voltage LOAD NO LOAD AC 12.6 V AC 14.7 V @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @...
  • Page 44 Measure Point...
  • Page 45 3. When there is no microwave oscillation 1) When touching START pad, oven lamp does not turn on. Fan motor do not rotate, but cook indicator in display comes on. * Cause : RELAY 2 does not operate. refer to Circuit Diagram (Point 3) - Check method POINT STATE...
  • Page 46 2. PCB CIRCUIT DIAGRAM...
  • Page 47 3. PCB LOCATION NO. NAME SYMBOL SPECIFICATION PART CODE Q’TY BUZZER BM-20K 3515600100 C ARRAY 7P(6) 1000PF M 50V CN6XB-102M CAPACITOR CERA 50V F 0.047MF Z CCZF1H473Z CAPACITOR CERA C2~6 50V HIKF 0.1MF Z CCZF1H104Z CAPACITOR ELEC 16V RSS 100MF CEXF1C101V CAPACITOR ELEC 25V RSS 1000MF...

  • Page 48: Exploded View And Parts List

    12. EXPLODED VIEW AND PARTS LIST 1. DOOR ASSEMBLY Refer to Disassembly and assembly. 2. CONTROL PANEL ASSEMBLY Refer to Disassembly and assembly. 3. TOTAL ASSEMBLY...
  • Page 49 KOR-1A1G(H) 3511726610 KOR-1A1H9A37 SPRAY KOR-1A1H9A37 3511711210 DOOR AS KOR-1A8Q KOR-1A8Q 3511711290 KOR-1A9H KOR-1A9H 3511711220 KOR-1A4G KOR-1A4G(H) 3511711270 KOR-1A7G KOR-1A7G PKCPSWXS00 KOR-1A0A0A KOR-1A0A PKCPSWXN00 KOR-1A1G0A KOR-1A1G PKCPSWXP00 KOR-1A1H0A KOR-1A1H PKCPSWXP10 KOR-1A1H9A37 KOR-1A1H9A37 PKCPSWX900 CONTROL-PANEL AS KOR-1A8Q0A KOR-1A8Q PKCPSWFZ00 KOR-1A9H9A KOR-1A9H PKCPSWXQ00...
  • Page 50 T1 TRS 4X10 MFZN 3512100900 FOOT PP DASF-130 7272400811 SCREW TAPTITE TT3 TRS 4X8 MFZN 3515202800 STOPPER HINGE*U AS KOR-121M0A KOR-1A0A0A,1A1G(H)0A, 3512718090 KOR-1A0A0A N/F 1A4G(H)0A,1A9H9A HARNESS MAIN KOR-1A1G(H)9A27,1A7G9A27, 3512716800 KOR-1A1G9A27 1A9H9A27,1A1H9A37, 1A4H9A27 4415A17352 SW MICRO VP-533A-OF SPNO#187 4415A66910 SW MICRO...
  • Page 51 DAEWOO ELECTRONICS CORP. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : PRINTED DATE: Dec. 2005...
