Double Chef
Smoker
Tools needed for
Adjustable Wrench
WARNING
CALIFORNIA PROPOSITION 65
1. Combustion by-products produced when using
this product contains chemicals known to the
State of California to cause cancer, birth defects,
or other reproductive harm.
2. This product contains chemicals, including lead
and lead compounds, known to the State of
California to cause cancer, birth defects or other
reproductive harm.
Wash your hands after handling this product.
WARNING
All surfaces can be hot during use. Use protection
as required to prevent burning.
Do not use this unit on or near combustible surfaces
or structures such as wood decks, dry leaves or
grass, vinyl or wood siding, etc.
SEE OWNERS MANUAL FOR IMPORTANT SAFETY
INFORMATION.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your grill online at www.grillregistration.com
P/N 42804401 (02/15/08)
assembly:
Screwdriver
Smoker, BBQ and Grill
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off
carbon monoxide, which has no odor. NEVER burn
charcoal inside homes, vehicles or tents.
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers
can fly out in breezy conditions. Adequate fire
extinguishing material should be readily available.
CAUTION
Some parts may contain sharp edges. Wear
protective gloves if necessary.
Read and follow all safety statements, warnings,
assembly instructions and use & care directions
before attempting to assemble and cook.
CAUTION
THIS UNIT IS HEAVY!
DO NOT assemble without a helper.
07701384
04201101
1-800-241-7548
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Double Chef Smoker and is the answer not in the manual?

Questions and answers

Related Manuals for Char-Broil Double Chef Smoker

Summary of Contents for Char-Broil Double Chef Smoker

  • Page 1 07701384 04201101 Smoker, BBQ and Grill Double Chef Smoker Tools needed for assembly: Adjustable Wrench Screwdriver WARNING WARNING CALIFORNIA PROPOSITION 65 CARBON MONOXIDE HAZARD Burning charcoal inside can kill you. It gives off 1. Combustion by-products produced when using carbon monoxide, which has no odor. NEVER burn this product contains chemicals known to the charcoal inside homes, vehicles or tents.

  • Page 2: Parts List

    If you accessories please visit us on the web at need parts, whether they are missing or www.charbroil. com or call damaged, call the Customer Service toll 1-800-241-7548 and one of our friendly and free Help Line.
  • Page 3 • Unpack all parts and check against parts list on page 2 to be sure you have everything necessary to assemble your grill. • Assemble the four legs, one leg at a time, using four 1/4-20x1/2” screws and four 1/4-20 nuts as shown Fig A, inserting the screw through holes in Leg Connector, then through holes in legs.
  • Page 4 • Attach three upper grid brackets to upper body, using one 1/4-20x1/2” screw and one 1/4-20 nut for each bracket as shown, inserting screw through hole in body then through bracket from inside body and attaching nut to screw. Make sure grid brackets are aligned properly before fully tightening.
  • Page 5 • Assemble your grill by placing the fire grate into the lower body assembly. Second the water pan rests on top of the lower grid brackets. Next the lower grid on top of the water pan. • Complete assembly by placing the upper body onto the lower body assembly. Place the upper grid on top of the upper grid brackets.

  • Page 6: Grill Maintenance

    PREPARING TO USE YOUR GRILL Before you begin . . . Before cooking with your grill, the following steps should be closely followed to both cure the finish and season the interior steel. Failure to Familairize yourself with the major components and controls of properly follow these steps may damage the finish and/or impart the unit.

  • Page 7: Disclaimer Of Implied Warranties; Limitation Of Remedies

    Defective or missing parts subject to this limited warranty will not be replaced without registration and proof of purchase. Register online at http://www.charbroil.com or complete and return via mail the Product Registration Card located on the last page of the Use &...

  • Page 8: Hardware List

    HARDWARE LIST Hardware is shown actual size. You may have spare hardware after assembly is complete. #10-24 #10-24x5/16” 1/4-20x1/2” 1/4-20 Acorn Nut Machine Screw Machine Screw Hex Nut Qty. 1 Qty. 1 Qty. 18 Qty. 24 WARNING MOST SURFACES ON THIS UNIT ARE HOT WHEN IN USE. USE EXTREME CAUTION.
