Icom FP-561 Service Manual page 26

SECTION 6
6-1 FP-561
[CHASSIS PARTS]
REF. NO. ODER NO.
MP1 8210016290 2142 front panel (A) assembly [GEN]
8210016410 2142 front panel (B) assembly [EUR]
MP2 8210016300 2142 rear panel assembly [GEN]
8210016420 2142 rear panel (A) assembly [EUR]
MP3 8930049451 2142 screen (A) -1
MP4 8410002300 2272 heatsink
MP5 8930049030 2142 keyboard (A)
MP6 8930047480 2142 F-packing
MP7 8930047510 2142 R-packing
MP8 8110006530 2142 cover
MP9 8010017530 2142 chassis
MP10 8510011851 2142 shield plate-1
MP11 8930042330 Sealing washer (M)
MP13 8930039000 1757 sheet
MP14 8810004540 Screw BiH M3x8 SUS
MP16 8810004540 Screw BiH M3x8 SUS
MP18 8810008200 Screw PH BT M2.6x6 NI-ZU
MP19 8810008660 Screw PH BT M3x8 NI-ZU
MP20 8810008660 Screw PH BT M3x8 NI-ZU
MP21 8810008660 Screw PH BT M3x8 NI-ZU
MP24 8830000370 Wing nut M5 SUS
MP25 8810008230 Bolt hex head M5x20 SUS
MP26 8850000500 Spring washer M5 SUS
MP27 8850000180 Flat washer M5 SUS
MP28 8830000250 Nut M5 SUS
MP31 8930047640 2142 handle
MP32 8010017500 T-bracket
MP33 8010017510 U-bracket
MP34 8930047540 2142 shaft plate
MP35 8930047530 2142 shaft
MP36 8850001740 Spring washer 8L SUS
MP37 8810009300 Set screw (J)
MP38 8850000210 Flat washer M8 SUS
MP39 8820001030 2142 knob bolt
MP40 8310025310 Label Circle seal (L)
6-2 RD-200
[CHASSIS PARTS]
REF. NO. ODER NO.
W1 8900008970 Cable OPC-873
MP1 8510012340 2273 L-Case
MP2 8510012350 2273 U-Case
MP3 8930049000 2273 L-plate
MP4 8930048990 2273 U-plate
MP5 8110006770 2273 cover
MP6 8930049390 2273 main seal
MP7 8810006050 Icom screw E7
MP8 8850000690 Flat washer M3 (3x7x0.5) SUS
MP9 8930049990 O-ring (Y)
MP10 8810008660 Screw PH BT M3x8 NI-ZU
MP11 8810008660 Screw PH BT M3x8 NI-ZU
MP12 8810007130 Set screw H M3x6
MP13 8810007130 Set screw H M3x6
MP15 8930000190 Stud bolt (O)
MP16 8930050000 Spacer BS-315
MP18 8930049320 2288 Vent. sheet
MP20 8810008660 Screw PH BT M3x8 NI-ZU
Screw abbreviations A, B0, BT: Self-tapping
FH: Flat head
NI: Nickel
ZK: Black
MECHANICAL PARTS AND DISASSEMBLY
DESCRIPTION QTY.
DESCRIPTION QTY.
[MAIN UNIT]
REF. NO. ODER NO.
1
F1 5210000060 Fuse FGB 5A
1
1
EP2 0850000120 IA023-5B03S (GPS module set)
1
1
MP1 8510012360 2272 GPS case
1
MP3 8930018520 TR clip (A)
1
MP4 8810008660 Screw PH BT M3x8 NI-ZU
1
MP5 8810000120 Screw PH M2.6x3
1
1
[LOGIC UNIT]
1
1
REF. NO. ODER NO.
4
W1 8900009030 Cable OPC-902
1
W2 8900008740 Cable OPC-867 [GEN]
4
8900009380 Cable OPC-906 [EUR]
4
4
MP1 8810009830 Set screw (C) M2x12
4
MP2 8930001850 Sponge (AD)
4
7
1
[SW UNIT]
1
REF. NO. ODER NO.
1
3
SP1 2520000110 Piezo buzzer PS1740P02
1
W1 8900008340 Cable OPC-816
1
1
[ACCESSORIES]
1
1
REF. NO. ODER NO.
1
W1 8900008040 Cable OPC-786
2
1
MP1 8930010000 Conector cover
2
MP2 8810001500 Screw PH AO M6x3 SUS
2
MP3 8850000510 Spring washer M6 SUS
2
MP4 8850000190 Flat washer M6 (6x13x1.0) SUS
MP5 8930049400 2273 pipe
MP6 8930049740 House band HAS-40
[MAIN UNIT]
REF. NO. ODER NO.
1 MP1 8510012330 2273 shield case
MP2 8510005330 Coil case
1 MP3 8510000470 Mix shield case
1
1
[ANT UNIT]
1
1
REF. NO. ODER NO.
1
EP3 3310002220 OH-3
4
EP4 3310002220 OH-3
4
4
MP1 8950000180 M.other Cable-tie-80
4
4
[ACCESSORIES]
4
4
REF. NO. ODER NO.
1
3
MP1 8930049400 2273 pipe
1
MP2 8930049740 House band HAS-40
1
PH: Pan head
BiH: Bind head
SUS: Stainless
6 - 1
