Icom FP-561 Service Manual page 19

[MAIN UNIT]
REF ORDER
NO. NO.
R99 7310003580 S.TRIMMER
R100 7030003400 S.RESISTOR
R101 7030003600 S.RESISTOR
R102 7030003600 S.RESISTOR
R103 7030003680 S.RESISTOR
R104 7030003680 S.RESISTOR
R105 7030003390 S.RESISTOR
R106 7030003390 S.RESISTOR
R107 7070000641 RESISTOR
R108 7030003600 S.RESISTOR
R109 7030003680 S.RESISTOR
R110 7030003680 S.RESISTOR
R111 7030003680 S.RESISTOR
R112 7030003680 S.RESISTOR
R113 7030003680 S.RESISTOR
R115 7030003370 S.RESISTOR
R116 7030003540 S.RESISTOR
R117 7030003440 S.RESISTOR
R118 7030003480 S.RESISTOR
R119 7030003440 S.RESISTOR
R120 7030003440 S.RESISTOR
R122 7030001090 S.RESISTOR
R124 7030001090 S.RESISTOR
R125 7030003440 S.RESISTOR
R127 7030001090 S.RESISTOR
R128 7030003440 S.RESISTOR
R130 7030001090 S.RESISTOR
R131 7030003280 S.RESISTOR
C1 4030011600 S.CERAMIC
C3 4030007130 S.CERAMIC
C4 4030007130 S.CERAMIC
C5 4030011600 S.CERAMIC
C7 4030006860 S.CERAMIC
C8 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C10 4030011600 S.CERAMIC
C11 4030009990 S.CERAMIC
C12 4030009990 S.CERAMIC
C13 4030009990 S.CERAMIC
C14 4030009990 S.CERAMIC
C16 4030011600 S.CERAMIC
C17 4550006250 S.TANTALUM
C18 4030006860 S.CERAMIC
C19 4030006900 S.CERAMIC
C20 4030006860 S.CERAMIC
C21 4030006900 S.CERAMIC
C22 4030006900 S.CERAMIC
C23 4030006900 S.CERAMIC
C24 4030011600 S.CERAMIC
C25 4030011600 S.CERAMIC
C28 4510007030 ELECTROLYTIC
C40 4510005310 S.ELECTROLYTIC ECEV1CA220SR
C41 4030006900 S.CERAMIC
C42 4030006860 S.CERAMIC
C43 4030006900 S.CERAMIC
C44 4510007020 ELECTROLYTIC
C45 4030004740 S.CERAMIC
C46 4030004740 S.CERAMIC
C47 4510007020 ELECTROLYTIC
C48 4030004740 S.CERAMIC
C49 4030004740 S.CERAMIC
C50 4310000360 MYLAR
C52 4510006880 ELECTROLYTIC
C53 4510007010 ELECTROLYTIC
C54 4510006640 ELECTROLYTIC
C59 4510004940 ELECTROLYTIC
C60 4510004940 ELECTROLYTIC
C61 4030006880 S.CERAMIC
C62 4030011600 S.CERAMIC
C63 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C64 4030008920 S.CERAMIC
C69 4510007000 ELECTROLYTIC
C70 4030006900 S.CERAMIC
C71 4030006900 S.CERAMIC
C72 4510005940 ELECTROLYTIC
C73 4030006900 S.CERAMIC
C74 4030006900 S.CERAMIC
C75 4510005750 S.ELECTROLYTIC ECEV1EA220SP
C76 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C77 4310000570 MYLAR
C79 4510004640 S.ELECTROLYTIC ECEV1CA470SP
DESCRIPTION
EVM-1XSX50 B15 (104)
ERJ3GEYJ 471 V (470 )
ERJ3GEYJ 223 V (22 k )
ERJ3GEYJ 223 V (22 k )
ERJ3GEYJ 104 V (100 k )
ERJ3GEYJ 104 V (100 k )
ERJ3GEYJ 391 V (390 )
ERJ3GEYJ 391 V (390 )
ERG2SJ 471 (470 )
ERJ3GEYJ 223 V (22 k )
ERJ3GEYJ 104 V (100 k )
ERJ3GEYJ 104 V (100 k )
ERJ3GEYJ 104 V (100 k )
ERJ3GEYJ 104 V (100 k )
ERJ3GEYJ 104 V (100 k )
ERJ3GEYJ 271 V (270 )
ERJ3GEYJ 682 V (6.8 k )
ERJ3GEYJ 102 V (1 k )
ERJ3GEYJ 222 V (2.2 k )
ERJ3GEYJ 102 V (1 k )
ERJ3GEYJ 102 V (1 k )
MCR50JZHJ 47 (470)
MCR50JZHJ 47 (470)
ERJ3GEYJ 102 V (1 k )
MCR50JZHJ 47 (470)
ERJ3GEYJ 102 V (1 k )
MCR50JZHJ 47 (470)
ERJ3GEYJ 470 V (47 )
C1608 JB 1C 104KT-N
C1608 CH 1H 101J-T-A
C1608 CH 1H 101J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 200J-T-A
C1608 CH 1H 200J-T-A
C1608 CH 1H 200J-T-A
C1608 CH 1H 200J-T-A
C1608 JB 1C 104KT-N
TEMSVA 1A 106M-8L
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
63 MV 1000CZ
C1608 JB 1E 103K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
35 MV 1000GX
C2012 JB 1H 472K-T-A
C2012 JB 1H 472K-T-A
35 MV 1000GX
C2012 JB 1H 472K-T-A
C2012 JB 1H 472K-T-A
50 F2D 103J
100 MV 33 CZ
16 MV 1000GX
16 MV 1000 CZ
50 MV 33 NPDW
50 MV 33 NPDW
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 473K-T-A
10 MV 1000GX
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
10 MV 470 HC
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
50 F2D 222J
[MAIN UNIT]
REF ORDER
NO. NO.
C80 4510004560 ELECTROLYTIC
C81 4030011600 S.CERAMIC
C83 4030006860 S.CERAMIC
C85 4030006880 S.CERAMIC
C86 4510004910 ELECTROLYTIC
C88 4030011600 S.CERAMIC
C89 4030006860 S.CERAMIC
C90 4030006900 S.CERAMIC
C91 4010008470 CERAMIC
C92 4010008470 CERAMIC
C93 4030010240 S.CERAMIC
C94 4010008470 CERAMIC
C95 4010008470 CERAMIC
C96 4030008470 S.CERAMIC
C97 4030011600 S.CERAMIC
C98 4030011600 S.CERAMIC
C99 4030011600 S.CERAMIC
C100 4030011600 S.CERAMIC
C101 4030011600 S.CERAMIC
C102 4550003080 S.TANTALUM
C103 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C104 4030006860 S.CERAMIC
C105 4030011600 S.CERAMIC
C106 4030011600 S.CERAMIC
C107 4030011600 S.CERAMIC
C108 4030011600 S.CERAMIC
C109 4030011600 S.CERAMIC
C110 4550006250 S.TANTALUM
C111 4030006480 S.CERAMIC
C113 4030006480 S.CERAMIC
C115 4030007040 S.CERAMIC
C116 4030011280 S.CERAMIC
C117 4030011280 S.CERAMIC
C118 4030011600 S.CERAMIC
C119 4030007070 S.CERAMIC
C120 4030007070 S.CERAMIC
C121 4030011330 S.CERAMIC
C122 4030011330 S.CERAMIC
J1 6510021040 CONNECTOR
J2 6510021220 CONNECTOR
J3 6510021190 CONNECTOR
J4 6510021200 CONNECTOR
J5 6510021210 CONNECTOR
F1 5210000060 FUSE
F2 5220000020 HOLDER
F3 5220000020 HOLDER
T1 5920000730 TRANSFORMER
T2 5920000690 TRANSFORMER
EP1 0910051392 PCB
EP2 0850000120 UNIT BOARD
5 - 2
DESCRIPTION
50 MV 10 NPDW
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1H 472K-T-A
16 MV 10 SWN
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
DE0905 B 222K 1KV
DE0905 B 222K 1KV
C1608 JB 1H 391K-T-A
DE0905 B 222K 1KV
DE0905 B 222K 1KV
C1608 JB 1H 272K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
TEMSVA 1A 335M-8L
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
TEMSVA 1A 106M-8L
GRM42-6 B 104K 50PT
GRM42-6 B 104K 50PT
C1608 CH 1H 180J-T-A
C1608 CH 1H 271J-T-A
C1608 CH 1H 271J-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 330J-T-A
C1608 CH 1H 330J-T-A
C1608 CH 1H 391J-T-A
C1608 CH 1H 391J-T-A
52806-3010
8S-S-E-SS
2S-S-E-SS
4S-S-E-SS
7S-S-E-SS
FGB 5A
S-N5051
S-N5051
TO-46
TO-43
B 5305B
IA023-5B03S
S.=Surface mount
