Icom MR-1010RII Operating Manual

Refer to the Instruction Manual for details about the ARPA, the AIS receiver, and DSC functions,
■ Display information
Screen range readout
Reference indicator
Vector indicator
Trail indicator
Rain control icon
SEA icon
Long pulse icon
North mark
Alarm zone
Cross-line cursor
Fixed range rings
AIS icon* 2
EBL/ VRM1
readouts
Own ship
information* 3, * 4
1
* North-up and Course-up screens can be used only when a bearing input (NMEA, N+1 or AUX) is connected.
2
* AIS data is required.
3
* Your position data is required.
4
* GPS data is required.
COG (Course Over Ground), SOG (Speed Over Ground)
5
* Bearing data and position data are required.
6
* R: Relative bearing, T:True bearing, M: Magnetic bearing
7
* T: True bearing, M: Magnetic bearing
8
Course Over Ground
* COG (
When using COG instead of HDG, the heading indicator may differ from the vessel's actual bow direction.
MR-1010R
Fixed ring range readout
Mode indicator*
Target Information box*
) is displayed when the "Bearing Input" item in the Initial menu is set to "GPS" or "GPS-L."
Heading indicator*
1
5, * 6
OPERATING GUIDE
7, * 8
Tuning mode
indicator
Alarm icons
IR icon
Echo Stretch icon
Zoom icon
Heading line
Waypoint marker
Own ship vector
indicator
VRM2 marker
VRM1 marker
EBL2 line
EBL1 line
4,5
ARPA icon*
EBL/ VRM2
readouts
Cursor
information* 5, * 6
© 2017 Icom Inc. A7361-5EX
