Main Unit - Icom FP-561 Service Manual

FP-561
[SW UNIT]
REF ORDER
NO. NO.
S10 2260001680 S.SWITCH
S11 2260001680 S.SWITCH
S12 2260001680 S.SWITCH
S13 2260001680 S.SWITCH
S14 2260001680 S.SWITCH
S15 2260001680 S.SWITCH
S16 2260001680 S.SWITCH
S17 2260001680 S.SWITCH
S18 2260001680 S.SWITCH
SP1 2520000110 PIEZO BUZZER
W1 8900008340 CABLE
EP1 0910051410 PCB
[DISP UNIT]
REF ORDER
NO. NO.
DS1 5030001720 LCD
DESCRIPTION
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
PS1740P02
OPC-816
B 5307
DESCRIPTION
LQ6AN102
5-2 RD-200

[MAIN UNIT]

REF ORDER
NO. NO.
IC1 1110001971 S.IC
IC2 1790000050 IC
IC3 1110003490 S.IC
IC4 1110002700 S.IC
IC5 1130003830 S.IC
IC6 1140004550 S.IC
IC7 1130007990 S.IC
IC8 1180001250 S.IC
IC9 1180001070 S.IC
IC10 1130003830 S.IC
IC11 1110004860 S.IC
IC12 1140008220 S.IC
IC13 1140005880 S.IC
IC14 1130003830 S.IC
IC15 1130006370 S.IC
IC16 1130006680 S.IC
IC17 1130009480 S.IC
IC18 1170000280 S.IC
IC19 1110002750 S.IC
Q1 1580000390 S.FET
Q2 1530002060 S.TRANSISTOR
Q3 1540000550 S.TRANSISTOR
Q4 1530002060 S.TRANSISTOR
Q5 1530002060 S.TRANSISTOR
Q6 1530002060 S.TRANSISTOR
Q7 1510000500 S.TRANSISTOR
Q8 1530001950 S.TRANSISTOR
Q9 1530002060 S.TRANSISTOR
Q10 1510000510 S.TRANSISTOR
Q11 1530002060 S.TRANSISTOR
Q12 1510000510 S.TRANSISTOR
D1 1710000840 S.DIODE
D2 1790001520 S.ZENER
D3 1750000550 S.DIODE
D4 1750000550 S.DIODE
D5 1730000910 S.ZENER
D6 1750000550 S.DIODE
FI1 2020001320 CERAMIC
X1 6050010760 S.XTAL
L1 6200003950 S.COIL
L2 6200003120 S.COIL
L3 6200006380 S.COIL
L4 6200008610 S.COIL
L5 6200003260 S.COIL
L6 6200003140 S.COIL
L7 6200006430 S.COIL
L8 6140001500 COIL
L9 6140001500 COIL
L10 6200008600 S.COIL
L11 6200002090 S.COIL
L12 6200005550 S.COIL
L13 6200005550 S.COIL
L14 6200005550 S.COIL
L15 6200002970 S.COIL
L16 6200003240 S.COIL
L17 6200008640 S.COIL
L18 6200003110 S.COIL
L19 6200005550 S.COIL
L20 6200003950 S.COIL
L21 6200005550 S.COIL
L22 6200008600 S.COIL
L23 6200003200 S.COIL
L24 6200000780 S.COIL
L25 6200008600 S.COIL
R1 7030003370 S.RESISTOR
R2 7030003230 S.RESISTOR
R3 7030003370 S.RESISTOR
R4 7030003320 S.RESISTOR
5 - 5
DESCRIPTION
µPC1676G-T1
ND487C1-3R
TA31136FN (D,EL)
NJM2904M-T1
TC7S04F (TE85R)
M65343FP/SC1287
TC3W03FU (TE12L)
TA7808F (TE16L)
TA7805F (TE16L)
TC7S04F (TE85R)
S-80842ALUP-EA6-T2
HD64F3644H
X25320S8I-2.7T6
TC7S04F (TE85R)
TC4093BF
TC7S02F (TE85R)
TC4049BF (N)
TLP121 (GB-TPL)
TA75S01F (TE85R)
3SK131K-T1
2SC4081 T107 R
2SD1664 T100Q
2SC4081 T107 R
2SC4081 T107 R
2SC4081 T107 R
2SA1162-GR (TE85R)
2SC2712-GR (TE85R)
2SC4081 T107 R
2SA1576A T106R
2SC4081 T107 R
2SA1576A T106R
1SR154-400 TE25
MA8075-L (TX)
1SS355 TE-17
1SS355 TE-17
RD12M-T2B2
1SS355 TE-17
CFJ455K8
DSX751S (14.5984 MHz)
HF50ACC 322513-T
NL 322522T-8R2J
ELJFC 150K 15U
ELJFC 390K-F 39U
NL 322522T-101J
NL 322522T-150J
ELJFC 180K-F
LR-171
LR-171
ELJFC 560K-F 56U
ELJFB 681K-F
ELJFC 100K-F
ELJFC 100K-F
ELJFC 100K-F
NL 322522T-121J
NL 322522T-221J
NL 322522T-391J
NL 322522T-6R8J
ELJFC 100K-F
HF50ACC 322513-T
ELJFC 100K-F
ELJFC 560K-F 56U
NL 322522T-560J
LQH 3N 100K 14
ELJFC 560K-F 56U
ERJ3GEYJ 271 V (270 )
ERJ3GEYJ 180 V (18 )
ERJ3GEYJ 271 V (270 )
ERJ3GEYJ 101 V (100 )
S.=Surface mount
