Icom FP-561 Service Manual page 18

SECTION 5 PARTS LIST
5-1 FP-561
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1130005720 S.IC
IC2 1130006370 S.IC
IC3 1130007990 S.IC
IC4 1130007990 S.IC
IC5 1110003490 S.IC
IC6 1110003340 S.IC
IC7 1130007420 S.IC
IC8 1170000280 S.IC
IC9 1110003070 S.IC
IC10 1170000280 S.IC
IC11 1110002700 S.IC
IC13 1180001840 IC
IC14 1130003920 S.IC
IC15 1170000280 S.IC
IC16 1130006220 S.IC
IC17 1130009480 S.IC
Q1 1530002550 S.TRANSISTOR
Q2 1530001950 S.TRANSISTOR
Q3 1530001950 S.TRANSISTOR
Q4 1510000500 S.TRANSISTOR
Q5 1510000500 S.TRANSISTOR
Q6 1590002670 FET
Q7 1590002670 FET
Q12 1510000800 S.TRANSISTOR
Q13 1530001950 S.TRANSISTOR
Q14 1590002670 FET
Q16 1510000500 S.TRANSISTOR
Q22 1590000430 S.TRANSISTOR
Q23 1530002550 S.TRANSISTOR
Q24 1530002550 S.TRANSISTOR
Q25 1530002550 S.TRANSISTOR
Q26 1530001950 S.TRANSISTOR
Q27 1540000550 S.TRANSISTOR
Q28 1530002060 S.TRANSISTOR
Q29 1510000510 S.TRANSISTOR
Q30 1530002060 S.TRANSISTOR
Q31 1510000510 S.TRANSISTOR
Q32 1530002060 S.TRANSISTOR
Q33 1510000510 S.TRANSISTOR
Q34 1530002060 S.TRANSISTOR
Q35 1510000510 S.TRANSISTOR
D1 1750000550 S.DIODE
D2 1750000550 S.DIODE
D3 1710000350 DIODE
D4 1710000350 DIODE
D9 1710000350 DIODE
D10 1790000700 DIODE
D11 1710000350 DIODE
D12 1790000760 DIODE
D13 1790001630 DIODE
D14 1750000550 S.DIODE
D17 1710000350 DIODE
D18 1730000880 S.ZENER
D21 1750000550 S.DIODE
D22 1790001630 DIODE
D23 1750000550 S.DIODE
D24 1750000550 S.DIODE
D27 1750000130 S.DIODE
D28 1750000550 S.DIODE
D30 1710000350 DIODE
D31 1710000350 DIODE
D32 1710000350 DIODE
D33 1730000010 S.ZENER
D34 1730000010 S.ZENER
D35 1710000350 DIODE
D36 1710000350 DIODE
D37 1730000770 S.ZENER
FI1 2020001640 CERAMIC
DESCRIPTION
TC7W04F (TE12L)
TC4093BF
TC3W03FU (TE12L)
TC3W03FU (TE12L)
TA31136FN (D,EL)
µPC358GR-T1
TC7W14FU (TE12L)
TLP121 (GB-TPL)
µPC494GS
TLP121 (GB-TPL)
NJM2904M-T1
PQ05RF21
TC4S69F (TE85R)
TLP121 (GB-TPL)
TC4W53FU (TE12L)
TC4049BF (N)
2SC3326-B (TE85R)
2SC2712-GR (TE85R)
2SC2712-GR (TE85R)
2SA1162-GR (TE85R)
2SA1162-GR (TE85R)
FS30KMJ-3
FS30KMJ-3
2SA1213-Y (TE12R,C)
2SC2712-GR (TE85R)
FS30KMJ-3
2SA1162-GR (TE85R)
DTC144EUA T106
2SC3326-B (TE85R)
2SC3326-B (TE85R)
2SC3326-B (TE85R)
2SC2712-GR (TE85R)
2SD1664 T100Q
2SC4081 T107 R
2SA1576A T106R
2SC4081 T107 R
2SA1576A T106R
2SC4081 T107 R
2SA1576A T106R
2SC4081 T107 R
2SA1576A T106R
1SS355 TE-17
1SS355 TE-17
1N4002
1N4002
1N4002
DSA3A1
1N4002
RG-2A
SB30-09J
1SS355 TE-17
1N4002
RD11M-T2B2
1SS355 TE-17
SB30-09J
1SS355 TE-17
1SS355 TE-17
DA204U T107
1SS355 TE-17
1N4002
1N4002
1N4002
RD4.7M-T2B3
RD4.7M-T2B3
1N4002
1N4002
RD7.5M-T1B1
CFWS455GY
[MAIN UNIT]
REF ORDER
NO. NO.
X1 6050009190 XTAL
X2 6050009180 XTAL
L1 6150003680 COIL
L2 5920000450 COIL
L3 6200009060 S.COIL
L5 6170000150 COIL
L6 6150003670 COIL
L7 6200003240 S.COIL
L8 6200008670 S.COIL
R2 7030003560 S.RESISTOR
R3 7030003560 S.RESISTOR
R5 7070001040 RESISTOR
R6 7070001040 RESISTOR
R7 7070000641 RESISTOR
R8 7030003280 S.RESISTOR
R9 7030003630 S.RESISTOR
R10 7030003580 S.RESISTOR
R12 7030003800 S.RESISTOR
R13 7030003800 S.RESISTOR
R15 7030003280 S.RESISTOR
R16 7030003440 S.RESISTOR
R17 7030003640 S.RESISTOR
R18 7030003640 S.RESISTOR
R19 7030003720 S.RESISTOR
R22 7030003440 S.RESISTOR
R23 7030003440 S.RESISTOR
R24 7030003320 S.RESISTOR
R25 7030003320 S.RESISTOR
R26 7030003440 S.RESISTOR
R27 7030003440 S.RESISTOR
R28 7030000190 S.RESISTOR
R29 7030000190 S.RESISTOR
R35 7030000340 S.RESISTOR
R36 7030003560 S.RESISTOR
R44 7030006520 S.RESISTOR
R45 7030003320 S.RESISTOR
R46 7540000060 ABSORBER
R47 7030000470 S.RESISTOR
R48 7030001430 S.RESISTOR
R55 7030003400 S.RESISTOR
R56 7030003440 S.RESISTOR
R60 7030000980 S.RESISTOR
R61 7030000310 S.RESISTOR
R62 7030003480 S.RESISTOR
R63 7030003520 S.RESISTOR
R64 7030003580 S.RESISTOR
R65 7030003560 S.RESISTOR
R66 7030000500 S.RESISTOR
R67 7030003620 S.RESISTOR
R68 7030003600 S.RESISTOR
R69 7030003530 S.RESISTOR
R70 7030003530 S.RESISTOR
R71 7030003600 S.RESISTOR
R72 7030003530 S.RESISTOR
R74 7030003560 S.RESISTOR
R75 7030003500 S.RESISTOR
R76 7030003560 S.RESISTOR
R77 7030003600 S.RESISTOR
R78 7030000410 S.RESISTOR
R79 7030000170 S.RESISTOR
R82 7030003460 S.RESISTOR
R84 7030003560 S.RESISTOR
R85 7070000641 RESISTOR
R91 7030003440 S.RESISTOR
R92 7030003400 S.RESISTOR
R93 7030003440 S.RESISTOR
R94 7030003560 S.RESISTOR
R96 7030003680 S.RESISTOR
R97 7030003650 S.RESISTOR
R98 7030003600 S.RESISTOR
5 - 1
DESCRIPTION
CR-497 (5.24 MHz)
CR-496 (4.04 MHz)
LS-415
FK-080E-1020
LQH 3C 101K 34
LW-16
LS-414
NL 322522T-221J
D10F-A814AY-152K
ERJ3GEYJ 103 V (10 k )
ERJ3GEYJ 103 V (10 k )
ERG1SJ 472 (4.7 k )
ERG1SJ 472 (4.7 k )
ERG2SJ 471 (470 )
ERJ3GEYJ 470 V (47 )
ERJ3GEYJ 393 V (39 k )
ERJ3GEYJ 153 V (15 k )
ERJ3GEYJ 105 V (1 M )
ERJ3GEYJ 105 V (1 M )
ERJ3GEYJ 470 V (47 )
ERJ3GEYJ 102 V (1 k )
ERJ3GEYJ 473 V (47 k )
ERJ3GEYJ 473 V (47 k )
ERJ3GEYJ 224 V (220 k )
ERJ3GEYJ 102 V (1 k )
ERJ3GEYJ 102 V (1 k )
ERJ3GEYJ 101 V (100 )
ERJ3GEYJ 101 V (100 )
ERJ3GEYJ 102 V (1 k )
ERJ3GEYJ 102 V (1 k )
MCR10EZHJ 27 (270)
MCR10EZHJ 27 (270)
MCR10EZHJ 470 (471)
ERJ3GEYJ 103 V (10 k )
RR0816P-561-D (560 )
ERJ3GEYJ 101 V (100 )
ERZ-C05DK 560
MCR10EZHJ 5.6 k
MCR50JZHJ 27 k
ERJ3GEYJ 471 V (470 )
ERJ3GEYJ 102 V (1 k )
MCR50JZHJ 5.6 (5R6)
MCR10EZHJ 270 (271)
ERJ3GEYJ 222 V (2.2 k )
ERJ3GEYJ 472 V (4.7 k )
ERJ3GEYJ 153 V (15 k )
ERJ3GEYJ 103 V (10 k )
MCR10EZHJ 10 k
ERJ3GEYJ 333 V (33 k )
ERJ3GEYJ 223 V (22 k )
ERJ3GEYJ 562 V (5.6 k )
ERJ3GEYJ 562 V (5.6 k )
ERJ3GEYJ 223 V (22 k )
ERJ3GEYJ 562 V (5.6 k )
ERJ3GEYJ 103 V (10 k )
ERJ3GEYJ 332 V (3.3 k )
ERJ3GEYJ 103 V (10 k )
ERJ3GEYJ 223 V (22 k )
MCR10EZHJ 1.8 k
MCR10EZHJ 18 (180)
ERJ3GEYJ 152 V (1.5 k )
ERJ3GEYJ 103 V (10 k )
ERG2SJ 471 (470 )
ERJ3GEYJ 102 V (1 k )
ERJ3GEYJ 471 V (470 )
ERJ3GEYJ 102 V (1 k )
ERJ3GEYJ 103 V (10 k )
ERJ3GEYJ 104 V (100 k )
ERJ3GEYJ 563 V (56 k )
ERJ3GEYJ 223 V (22 k )
S.=Surface mount
