[LOGIC UNIT]
REF ORDER
NO. NO.
R178 7030003460 S.RESISTOR
R179 7030003580 S.RESISTOR
R180 7030003680 S.RESISTOR
C1 4030012600 S.CERAMIC
C2 4030006860 S.CERAMIC
C3 4030008630 S.CERAMIC
C4 4030008630 S.CERAMIC
C5 4510004650 S.ELECTROLYTIC ECEV1EA4R7SR
C6 4030008630 S.CERAMIC
C7 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C10 4510005310 S.ELECTROLYTIC ECEV1CA220SR
C11 4030008630 S.CERAMIC
C12 4030008630 S.CERAMIC
C13 4030008630 S.CERAMIC
C14 4030008630 S.CERAMIC
C15 4030008630 S.CERAMIC
C16 4030008630 S.CERAMIC
C17 4030008630 S.CERAMIC
C18 4030008630 S.CERAMIC
C19 4030008630 S.CERAMIC
C20 4030008630 S.CERAMIC
C21 4030008630 S.CERAMIC
C22 4030008630 S.CERAMIC
C23 4030008630 S.CERAMIC
C24 4030008630 S.CERAMIC
C25 4030008630 S.CERAMIC
C26 4030008630 S.CERAMIC
C27 4030008630 S.CERAMIC
C42 4030008630 S.CERAMIC
C43 4030008630 S.CERAMIC
C44 4030008630 S.CERAMIC
C45 4030008630 S.CERAMIC
C46 4030008630 S.CERAMIC
C47 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C48 4510006650 S.ELECTROLYTIC ECEV1EA100SR
C49 4030008630 S.CERAMIC
C50 4030008630 S.CERAMIC
C51 4030008630 S.CERAMIC
C52 4030008630 S.CERAMIC
C53 4030008630 S.CERAMIC
C54 4030008630 S.CERAMIC
C55 4030008630 S.CERAMIC
C56 4030008630 S.CERAMIC
C58 4030008630 S.CERAMIC
C59 4550000460 S.TANTALUM
C61 4030008630 S.CERAMIC
C64 4030008630 S.CERAMIC
C65 4030008630 S.CERAMIC
C66 4030008630 S.CERAMIC
C67 4030008630 S.CERAMIC
C68 4510005310 S.ELECTROLYTIC ECEV1CA220SR
C69 4030008630 S.CERAMIC
C70 4030011810 S.CERAMIC
J1 6510021170 CONNECTOR
J2 6510021040 CONNECTOR
J3 6510021020 CONNECTOR
J6 6510021510 CONNECTOR
BT1 3020000130 LITHIUM
W1 8900009030 CABLE
W2 8900008740 CABLE
8900009380 CABLE
W3 8900008920 CABLE
W19 7120000470 JUMPER
W20 7120000470 JUMPER
EP1 0910051401 PCB
DESCRIPTION
ERJ3GEYJ 152 V (1.5 k )
ERJ3GEYJ 153 V (15 k )
ERJ3GEYJ 104 V (100 k )
C2012 JB 1A 105M-T-A
C1608 JB 1H 102K-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
TESVA 1C 105M1-8L
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JB 1A 224K-T-N
ICME68H-L8-D1121RHA
52806-3010
52806-1810
52807-2410
CR3032-1T2
OPC-902
OPC-867 [GEN]
OPC-906 [EUR]
OPC-882
ERDS2T0
ERDS2T0
B 5306A
[SW UNIT]
REF ORDER
NO. NO.
Q1 1530001950 S.TRANSISTOR
Q2 1530001950 S.TRANSISTOR
Q3 1530001950 S.TRANSISTOR
Q4 1530001950 S.TRANSISTOR
D1 1750000550 S.DIODE
D2 1750000550 S.DIODE
D3 1750000550 S.DIODE
D4 1750000550 S.DIODE
D5 1750000550 S.DIODE
D6 1750000550 S.DIODE
D7 1750000550 S.DIODE
D8 1750000550 S.DIODE
D9 1750000550 S.DIODE
D10 1750000550 S.DIODE
D11 1750000550 S.DIODE
D12 1750000550 S.DIODE
D13 1750000550 S.DIODE
D14 1750000550 S.DIODE
D15 1750000550 S.DIODE
D16 1750000550 S.DIODE
D17 1750000550 S.DIODE
R1 7030003640 S.RESISTOR
R2 7030003640 S.RESISTOR
R3 7030003640 S.RESISTOR
R4 7030003640 S.RESISTOR
R5 7030003640 S.RESISTOR
R6 7030003640 S.RESISTOR
R7 7030003460 S.RESISTOR
R8 7030003460 S.RESISTOR
R9 7030003460 S.RESISTOR
R10 7030003520 S.RESISTOR
R11 7030003520 S.RESISTOR
R12 7030003520 S.RESISTOR
R13 7030003520 S.RESISTOR
R14 7030003520 S.RESISTOR
R15 7030003550 S.RESISTOR
R16 7030003550 S.RESISTOR
R17 7030003550 S.RESISTOR
C1 4030006860 S.CERAMIC
C2 4030006860 S.CERAMIC
C3 4030006860 S.CERAMIC
C4 4030006860 S.CERAMIC
C5 4030006860 S.CERAMIC
C6 4030006860 S.CERAMIC
C7 4030006860 S.CERAMIC
C8 4030006860 S.CERAMIC
C9 4030006860 S.CERAMIC
C10 4030006860 S.CERAMIC
C11 4030006860 S.CERAMIC
C12 4550006480 S.TANTALUM
C14 4030006860 S.CERAMIC
J1 6510021020 CONNECTOR
DS1 5040002420 S.LED
DS2 5040002420 S.LED
DS3 5040002420 S.LED
DS4 5040002420 S.LED
DS5 5040002420 S.LED
DS6 5040002420 S.LED
DS7 5040002420 S.LED
DS8 5040002420 S.LED
DS9 5040002420 S.LED
S1 2230001030 SWITCH
S2 2260001680 S.SWITCH
S3 2260001680 S.SWITCH
S4 2260001680 S.SWITCH
S5 2260001680 S.SWITCH
S6 2260001680 S.SWITCH
S7 2260001680 S.SWITCH
S8 2260001680 S.SWITCH
S9 2260001680 S.SWITCH
5 - 4
DESCRIPTION
2SC2712-GR (TE85R)
2SC2712-GR (TE85R)
2SC2712-GR (TE85R)
2SC2712-GR (TE85R)
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
ERJ3GEYJ 473 V (47 k )
ERJ3GEYJ 473 V (47 k )
ERJ3GEYJ 473 V (47 k )
ERJ3GEYJ 473 V (47 k )
ERJ3GEYJ 473 V (47 k )
ERJ3GEYJ 473 V (47 k )
ERJ3GEYJ 152 V (1.5 k )
ERJ3GEYJ 152 V (1.5 k )
ERJ3GEYJ 152 V (1.5 k )
ERJ3GEYJ 472 V (4.7 k )
ERJ3GEYJ 472 V (4.7 k )
ERJ3GEYJ 472 V (4.7 k )
ERJ3GEYJ 472 V (4.7 k )
ERJ3GEYJ 472 V (4.7 k )
ERJ3GEYJ 822 V (8.2 k )
ERJ3GEYJ 822 V (8.2 k )
ERJ3GEYJ 822 V (8.2 k )
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
TEMSVA 1C 475M-8L
C1608 JB 1H 102K-T-A
52806-1810
SML-310MT T86
SML-310MT T86
SML-310MT T86
SML-310MT T86
SML-310MT T86
SML-310MT T86
SML-310MT T86
SML-310MT T86
SML-310MT T86
MS-666K
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
S.=Surface mount
