Icom IC-R2 Service Manual page 22

[RF UNIT]
REF ORDER
NO. NO.
C99 4030014230 S.CERAMIC
C100 4030013970 S.CERAMIC
C101 4030014120 S.CERAMIC
C102 4030013850 S.CERAMIC
C103 4030009820 S.CERAMIC
C104 4030006900 S.CERAMIC
C105 4550003220 S.TANTALUM
C106 4030011600 S.CERAMIC
C107 4030011810 S.CERAMIC
C108 4030011810 S.CERAMIC
C118 4030013850 S.CERAMIC
C119 4030013850 S.CERAMIC
C121 4030013850 S.CERAMIC
C134 4030013850 S.CERAMIC
C135 4030013850 S.CERAMIC
C136 4030014100 S.CERAMIC
C138 4030014220 S.CERAMIC
C139 4030014120 S.CERAMIC
C141 4030009820 S.CERAMIC
C142 4030013850 S.CERAMIC
C145 4030014220 S.CERAMIC
C147 4030014030 S.CERAMIC
C148 4030014220 S.CERAMIC
C150 4030013850 S.CERAMIC
C151 4030014070 S.CERAMIC
C153 4030013970 S.CERAMIC
C154 4030014120 S.CERAMIC
C155 4030014080 S.CERAMIC
C156 4030014420 S.CERAMIC
C158 4030013850 S.CERAMIC
C160 4030013850 S.CERAMIC
C162 4550006200 S.TANTALUM
C163 4030013850 S.CERAMIC
C164 4030013850 S.CERAMIC
C165 4030014020 S.CERAMIC
C166 4030013850 S.CERAMIC
C167 4030013850 S.CERAMIC
C168 4030013850 S.CERAMIC
C169 4030013850 S.CERAMIC
C170 4030013850 S.CERAMIC
C171 4030013850 S.CERAMIC
C172 4030013850 S.CERAMIC
C173 4030013850 S.CERAMIC
C178 4030013850 S.CERAMIC
C180 4030013850 S.CERAMIC
C182 4030013850 S.CERAMIC
C183 4030014000 S.CERAMIC
C186 4030013850 S.CERAMIC
C188 4030013850 S.CERAMIC
C190 4030014000 S.CERAMIC
C191 4030014020 S.CERAMIC
C192 4030014070 S.CERAMIC
C193 4030014110 S.CERAMIC
C194 4030014150 S.CERAMIC
C195 4030014000 S.CERAMIC
C196 4030014020 S.CERAMIC
C197 4030014060 S.CERAMIC
C198 4030014090 S.CERAMIC
C199 4030014130 S.CERAMIC
C200 4030009820 S.CERAMIC
C206 4030014060 S.CERAMIC
C207 4030014170 S.CERAMIC
C208 4030014180 S.CERAMIC
C209 4030013850 S.CERAMIC
C210 4550000530 S.TANTALUM
C211 4030013850 S.CERAMIC
C214 4030013850 S.CERAMIC
C216 4030014130 S.CERAMIC
C218 4030013980 S.CERAMIC
C233 4030013850 S.CERAMIC
C234 4030013850 S.CERAMIC
C235 4030013850 S.CERAMIC
C236 4030013850 S.CERAMIC
C237 4030014000 S.CERAMIC
C239 4030009820 S.CERAMIC
C241 4030011810 S.CERAMIC
C242 4030011810 S.CERAMIC
C243 4030014240 S.CERAMIC
C244 4030014080 S.CERAMIC
C247 4030014090 S.CERAMIC
C248 4550003220 S.TANTALUM
C249 4030009820 S.CERAMIC
DESCRIPTION
ECUE1E681KBQ
C1005 JB 0J 104K-T-N
ECUE1H100CCQ
ECUE1E102KBQ
C1005 JB 1C 103K-T-A
C1608 JB 1E 103K-T-A
TEMSVA 1E 105M-8L
C1608 JB 1C 104KT-N
C1608 JB 1A 224K-T-N
C1608 JB 1A 224K-T-N
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H070CCQ
ECUE1E471KBQ
ECUE1H100CCQ
C1005 JB 1C 103K-T-A
ECUE1E102KBQ
ECUE1E471KBQ
ECUE1H2R5BCQ
ECUE1E471KBQ
ECUE1E102KBQ
ECUE1H040BCQ
C1005 JB 0J 104K-T-N
ECUE1H100CCQ
ECUE1H050BCQ
ECUE1H0R5BCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECST0JY106R
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H020BCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H1R5BCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H1R5BCQ
ECUE1H020BCQ
ECUE1H040BCQ
ECUE1H080CCQ
ECUE1H220JCQ
ECUE1H1R5BCQ
ECUE1H020BCQ
ECUE1H3R5BCQ
ECUE1H060CCQ
ECUE1H120JCQ
C1005 JB 1C 103K-T-A
ECUE1H3R5BCQ
ECUE1H330JCQ
ECUE1H470JCQ
ECUE1E102KBQ
TESVA 1V 104M1-8L
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H120JCQ
ECUE1H010BCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H1R5BCQ
C1005 JB 1C 103K-T-A
C1608 JB 1A 224K-T-N
C1608 JB 1A 224K-T-N
ECUE1H180JCQ
ECUE1H050BCQ
ECUE1H060CCQ
TEMSVA 1E 105M-8L
C1005 JB 1C 103K-T-A
[RF UNIT]
REF ORDER
NO. NO.
C250 4030014110 S.CERAMIC
C251 4030014070 S.CERAMIC
C252 4030014110 S.CERAMIC
C256 4030013850 S.CERAMIC
C257 4030013850 S.CERAMIC
C258 4030013850 S.CERAMIC
C259 4030014200 S.CERAMIC
C264 4030013850 S.CERAMIC
C402 4030014180 S.CERAMIC
C410 4030013850 S.CERAMIC
C414 4030013850 S.CERAMIC
C416 4030014160 S.CERAMIC
C423 4550003220 S.TANTALUM
C424 4030009820 S.CERAMIC
C427 4030014350 S.CERAMIC
C429 4030009820 S.CERAMIC
C430 4030009820 S.CERAMIC
C431 4030009820 S.CERAMIC
C432 4030013850 S.CERAMIC
C433 4030013850 S.CERAMIC
C434 4030009820 S.CERAMIC
C435 4030013850 S.CERAMIC
C436 4030014070 S.CERAMIC
C503 4030013850 S.CERAMIC
C504 4030013850 S.CERAMIC
C505 4030013850 S.CERAMIC
C507 4030014210 S.CERAMIC
C510 4030014020 S.CERAMIC
C511 4030014170 S.CERAMIC
C512 4030014130 S.CERAMIC
C513 4030014440 S.CERAMIC
C514 4030014210 S.CERAMIC
C515 4030014200 S.CERAMIC
C516 4030014330 S.CERAMIC
C517 4030014320 S.CERAMIC
C518 4030009810 S.CERAMIC
C519 4030013890 S.CERAMIC
C520 4030009820 S.CERAMIC
C521 4030013970 S.CERAMIC
C522 4030013880 S.CERAMIC
C523 4030013890 S.CERAMIC
C524 4030009820 S.CERAMIC
C525 4030009820 S.CERAMIC
C526 4030013950 S.CERAMIC
C527 4030014440 S.CERAMIC
C528 4030014160 S.CERAMIC
C529 4030014210 S.CERAMIC
C530 4030014490 S.CERAMIC
C531 4030014320 S.CERAMIC
C532 4030013970 S.CERAMIC
C533 4030013890 S.CERAMIC
C534 4030014490 S.CERAMIC
C535 4030013850 S.CERAMIC
C536 4030013970 S.CERAMIC
C537 4030013970 S.CERAMIC
C538 4030013970 S.CERAMIC
C539 4030013970 S.CERAMIC
C540 4030013970 S.CERAMIC
C541 4030013970 S.CERAMIC
C542 4030013970 S.CERAMIC
C543 4030013850 S.CERAMIC
C544 4030013850 S.CERAMIC
C545 4030009820 S.CERAMIC
C546 4030013970 S.CERAMIC
C548 4030013850 S.CERAMIC
C550 4030014110 S.CERAMIC
C553 4030013850 S.CERAMIC
C557 4030013850 S.CERAMIC
C558 4030013850 S.CERAMIC
C560 4030013850 S.CERAMIC
C561 4030013850 S.CERAMIC
C562 4030013850 S.CERAMIC
C563 4030013850 S.CERAMIC
C654 4030011810 S.CERAMIC
C655 4550000510 S.TANTALUM
C656 4030014110 S.CERAMIC
C657 4030014230 S.CERAMIC
C658 4030013880 S.CERAMIC
C659 4550006200 S.TANTALUM
C662 4030013850 S.CERAMIC
C663 4030013970 S.CERAMIC
C664 4030013970 S.CERAMIC
6 - 5
DESCRIPTION
ECUE1H080CCQ
ECUE1H040BCQ
ECUE1H080CCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H101JCQ
ECUE1E102KBQ
ECUE1H470JCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H270JCQ
TEMSVA 1E 105M-8L
C1005 JB 1C 103K-T-A
ECUE1H560JCQ
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
ECUE1E102KBQ
ECUE1E102KBQ
C1005 JB 1C 103K-T-A
ECUE1E102KBQ
ECUE1H040BCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1H151JCQ
ECUE1H020BCQ
ECUE1H330JCQ
ECUE1H120JCQ
ECUE1H820JCQ
ECUE1H151JCQ
ECUE1H101JCQ
ECUE1H221JCQ
ECUE1H181JCQ
C1005 JB 1E 102K-T-A
C1005 JB 1H 152K-T-N
C1005 JB 1C 103K-T-A
C1005 JB 0J 104K-T-N
C1005 JB 1H 222K-T-N
C1005 JB 1H 152K-T-N
C1005 JB 1C 103K-T-A
C1005 JB 1C 103K-T-A
C1005 JB 1A 393K-T-N
ECUE1H820JCQ
ECUE1H270JCQ
ECUE1H151JCQ
ECUE1E331KBQ
ECUE1H181JCQ
C1005 JB 0J 104K-T-N
C1005 JB 1H 152K-T-N
ECUE1E331KBQ
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
ECUE1E102KBQ
C1005 JB 1C 103K-T-A
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
ECUE1H080CCQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
ECUE1E102KBQ
C1608 JB 1A 224K-T-N
TESVA 1V 473M1-8L
ECUE1H080CCQ
ECUE1E681KBQ
C1005 JB 1H 222K-T-N
ECST0JY106R
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
S.=Surface mount
