Icom IC-R2 Service Manual page 19

[LOGIC UNIT]
REF ORDER
NO. NO.
C1 4030014200 S.CERAMIC
C3 4030013970 S.CERAMIC
C4 4550006760 S.TANTALUM
C5 4030013850 S.CERAMIC
C6 4030008680 S.CERAMIC
C8 4030014120 S.CERAMIC
C9 4030014120 S.CERAMIC
C11 4030013970 S.CERAMIC
C12 4030013950 S.CERAMIC
C13 4030013970 S.CERAMIC
C14 4030013890 S.CERAMIC
C15 4510007130 S.ELECTROLYTIC EEFCD0J470R
C15 4550006670 S.TANTALUM
C16 4030013850 S.CERAMIC
C17 4030008680 S.CERAMIC
C18 4550006920 S.TANTALLUM
C19 4030008680 S.CERAMIC
C24 4550006200 S.TANTALUM
C33 4030008680 S.CERAMIC
C35 4030013850 S.CERAMIC
C36 4030008680 S.CERAMIC
C37 4030013850 S.CERAMIC
C39 4030013970 S.CERAMIC
C40 4030013850 S.CERAMIC
C41 4030013970 S.CERAMIC
C42 4030013970 S.CERAMIC
C43 4030013850 S.CERAMIC
C44 4030013970 S.CERAMIC
C48 4030008680 S.CERAMIC
C51 4030013850 S.CERAMIC
C52 4030013850 S.CERAMIC
C53 4030013970 S.CERAMIC
C57 4030013850 S.CERAMIC
C58 4030013970 S.CERAMIC
C60 4550006690 S.TANTALUM
C61 4550006550 S.TANTALUM
C62 4030013850 S.CERAMIC
C63 4030013970 S.CERAMIC
C65 4030013970 S.CERAMIC
C66 4030013970 S.CERAMIC
C67 4030013970 S.CERAMIC
C68 4030013930 S.CERAMIC
C69 4030013910 S.CERAMIC
C70 4030013910 S.CERAMIC
C71 4030013880 S.CERAMIC
C72 4030013910 S.CERAMIC
C73 4030013970 S.CERAMIC
C74 4030013970 S.CERAMIC
C76 4030013970 S.CERAMIC
C77 4030013970 S.CERAMIC
C78 4030013960 S.CERAMIC
C79 4030014200 S.CERAMIC
C80 4030013970 S.CERAMIC
C81 4030013970 S.CERAMIC
C82 4030013970 S.CERAMIC
C86 4030008680 S.CERAMIC
C87 4030008680 S.CERAMIC
C88 4550006320 S.TANTALUM
C89 4550006320 S.TANTALUM
C90 4030013910 S.CERAMIC
C91 4030013970 S.CERAMIC
C92 4030013970 S.CERAMIC
C93 4030013930 S.CERAMIC
C94 4030008680 S.CERAMIC
C96 4550006320 S.TANTALUM
C97 4030013970 S.CERAMIC
C98 4550006760 S.TANTALUM
C100 4030013970 S.CERAMIC
C101 4030013850 S.CERAMIC
C102 4030014200 S.CERAMIC
C103 4030013970 S.CERAMIC
C106 4030013970 S.CERAMIC
C107 4030011810 S.CERAMIC
C108 4030013850 S.CERAMIC
C114 4030013970 S.CERAMIC
C116 4030013970 S.CERAMIC
C118 4550006140 S.TANTALUM
C119 4030008680 S.CERAMIC
C120 4030008680 S.CERAMIC
C121 4030008680 S.CERAMIC
C123 4030013970 S.CERAMIC
DESCRIPTION
ECUE1H101JCQ
C1005 JB 0J 104K-T-N
TEMSVB2 1A 336M-8R
ECUE1E102KBQ
C2012 JF 1C 105Z-T-A
ECUE1H100CCQ
ECUE1H100CCQ
C1005 JB 0J 104K-T-N
C1005 JB 1A 393K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 1H 152K-T-N
ECST1AD107R
ECUE1E102KBQ
C2012 JF 1C 105Z-T-A
TEMSVB2 1E 335M-8R
C2012 JF 1C 105Z-T-A
ECST0JY106R
C2012 JF 1C 105Z-T-A
ECUE1E102KBQ
C2012 JF 1C 105Z-T-A
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
C2012 JF 1C 105Z-T-A
ECUE1E102KBQ
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
ECST1AC476R
TEMSVD 0G 227M-12R
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 1C 183K-T-N
C1005 JB 1E 472K-T-N
C1005 JB 1E 472K-T-N
C1005 JB 1H 222K-T-N
C1005 JB 1E 472K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 1A 473K-T-N
ECUE1H101JCQ
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C2012 JF 1C 105Z-T-A
C2012 JF 1C 105Z-T-A
ECST0JY475R
ECST0JY475R
C1005 JB 1E 472K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1005 JB 1C 183K-T-N
C2012 JF 1C 105Z-T-A
ECST0JY475R
C1005 JB 0J 104K-T-N
TEMSVB2 1A 336M-8R
C1005 JB 0J 104K-T-N
ECUE1E102KBQ
ECUE1H101JCQ
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
C1608 JB 1A 224K-T-N
ECUE1E102KBQ
C1005 JB 0J 104K-T-N
C1005 JB 0J 104K-T-N
ECST1EY474R
C2012 JF 1C 105Z-T-A
C2012 JF 1C 105Z-T-A
C2012 JF 1C 105Z-T-A
C1005 JB 0J 104K-T-N
[LOGIC UNIT]
REF ORDER
NO. NO.
DS2 5040002230 S.LED
DS8 5030001610 LCD
S8 2230000900 S.SWITCH
S9 2250000390 ENCODER
S10 2230000900 S.SWITCH
J1 6510020560 S.CONNECTOR AXK5S40340P
J2 6450001910 CONNECTOR
W2 7030003860 S.JUMPER
W3 7030003860 S.JUMPER
W5 7030003860 S.JUMPER
EP1 0910050773 PCB
EP2 8930046581 LCD CONTACT SRCN-1995-SP-N-W-1
[RF UNIT]
REF ORDER
NO. NO.
IC1 1110004020 S.IC
IC2 1110003200 S.IC
IC3 1130007610 S.IC
IC4 1110003470 S.IC
IC10 1110004020 S.IC
IC11 1110003470 S.IC
Q1 1590001190 S.TRANSISTOR XP6501-(TX).AB
Q2 1560000540 S.FET
Q4 1590001190 S.TRANSISTOR XP6501-(TX).AB
Q5 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q6 1530003610 S.TRANSISTOR FH102-TL
Q14 1530003610 S.TRANSISTOR FH102-TL
Q24 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q26 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q28 1530003260 S.TRANSISTOR 2SC5006-T1
Q29 1590001940 S.TRANSISTOR DTC144EE TL
Q30 1530003260 S.TRANSISTOR 2SC5006-T1
Q31 1530003610 S.TRANSISTOR FH102-TL
Q33 1590001810 S.TRANSISTOR XP1113 (TX)
Q35 1590002650 S.TRANSISTOR UPA805T-T1
Q36 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q37 1530003630 S.TRANSISTOR 2SC4617 TLS
Q40 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q41 1590002430 S.TRANSISTOR DTA144EE TL
Q43 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q44 1590001660 S.TRANSISTOR XP4312 (TX)
Q45 1530003010 S.TRANSISTOR 2SC4117-GR (TE85R)
Q46 1590001660 S.TRANSISTOR XP4312 (TX)
Q501 1590002430 S.TRANSISTOR DTA144EE TL
Q502 1590001810 S.TRANSISTOR XP1113 (TX)
Q503 1590001810 S.TRANSISTOR XP1113 (TX)
Q504 1590001810 S.TRANSISTOR XP1113 (TX)
Q505 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q506 1590002430 S.TRANSISTOR DTA144EE TL
Q507 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q508 1590001660 S.TRANSISTOR XP4312 (TX)
Q509 1590002430 S.TRANSISTOR DTA144EE TL
D1 1720000370 S.VARICAP
D2 1720000370 S.VARICAP
D3 1790001620 S.DIODE
D4 1720000370 S.VARICAP
D5 1720000370 S.VARICAP
D11 1790001620 S.DIODE
D13 1790001620 S.DIODE
D17 1720000700 S.VARICAP
D18 1720000370 S.VARICAP
D20 1790001590 S.DIODE
D21 1790001590 S.DIODE
6 - 2
DESCRIPTION
CL-200YG-C-TS
DLC-7995YBGF
JPM1990-2013R
TP90N00E20-16F-1995
JPM1990-2013R
HSJ1594-010050
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
B 5164C
DESCRIPTION
µPC2757T-E3
TA31136FN (EL)
µPD3140GS-E1 (DS8)
µPC2746T-E3
µPC2757T-E3
µPC2746T-E3
2SK880-Y (TE85R)
HVU350TRF
HVU350TRF
ISV308 (TPL3)
HVU350TRF
HVU350TRF
ISV308 (TPL3)
ISV308 (TPL3)
1SV305 (TPL3)
HVU350TRF
MA6S718 (TX)
MA6S718 (TX)
S.=Surface mount
