NordicTrack 29826.3 User Manual
  1. Manuals
  2. Brands
  3. NordicTrack Manuals
  4. Elliptical Trainer
  5. 29826.3
  6. User manual
NordicTrack 29826.3 User Manual

NordicTrack 29826.3 User Manual

E7.1
Hide thumbs
Table of Contents

Advertisement

Quick Links

www.nordictrack.com
Model No. 29826.3
Serial No.
USER'S MANUAL
Write the serial number in the space
above for reference.
Serial Number
Decal (under frame)
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
contact Customer Service.
CUSTOMER SERVICE
Call toll-free 1-888-936-4266
Mon.–Fri. 7:30 a.m.–4:30 p.m. ET
(excluding holidays)
or email us at
customerservice@iconcanada.ca
Please do not contact the store.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 29826.3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NordicTrack 29826.3

Summary of Contents for NordicTrack 29826.3

  • Page 1 Model No. 29826.3 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal (under frame) ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, contact Customer Service. CUSTOMER SERVICE Call toll-free 1-888-936-4266 Mon.–Fri.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 18. The elliptical does not have a freewheel; the 20. Over exercising may result in serious injury pedals will continue to move until the fly- or death. If you feel faint or if you experience wheel stops. Reduce your pedaling speed in pain while exercising, stop immediately and a controlled way.
  • Page 6 Your new tness equipment represents a signi cant investment in your health. Protect your investment now from unexpected mechanical or electrical failures for up to ve years. PLAN FEATURES • Protection for one to ve years • Easy enrollment • Over 100 authorized repair centers •...

  • Page 7: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK E 7.1 elliptical. The E 7.1 elliptical manual. To help us assist you, note the product model ® provides an impressive selection of features designed number and serial number before contacting us.

  • Page 8: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 9: Assembly

    ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tool(s): • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you finish all assembly steps.
  • Page 10 2. Orient the Rear Stabilizer (4) as shown. Attach the Rear Stabilizer (4) to the Folding Frame (2) with two M10 x 95mm Screws (100). Next, hold the handle on the Rear Stabilizer (4), Handle press the Latch Button (67), and lower the Rear Stabilizer and the Folding Frame (2) to the floor.
  • Page 11 4. Identify and orient the Upright (5) and the Top Cover (27) as shown. Wire Tie Slide the Top Cover (27) upward onto the Upright (5). Avoid pinching the Wire Harness (60) Have a second person hold the Upright (5) and the Top Cover (27) near the Main Frame (1).
  • Page 12 5. Tip: Avoid pinching the Wire Harness (60). Insert the Upright (5) into the Main Frame (1). Attach the Upright (5) with four M8 x 16mm Screws (102) and four M8 Split Washers (103); do not tighten the Screws yet. 6.
  • Page 13 7. Identify the Right Pedal (14), the Right Pedal Pad (88), and the Right Pedal Arm (12) assem- bly and orient them as shown. Set the Right Pedal Pad (88) on the Right Pedal Arm (12). Then, set the Right Pedal (14) on the Right Pedal Pad.
  • Page 14 9. See drawing 9a. Locate the Pedal Arm Roller (32) on the Right Pedal Arm (12). Set the Pedal Arm Roller (32) on the right side of the Ramp (130). See drawing 9b. Pull upward on the Latch (50) on the Right Pedal Arm (12). Press the Right Pedal Arm (12) onto the right Pedal Arm Sleeve (46).
  • Page 15 10. Orient the Ramp Cover (131) around the Upright (5) as shown. Press the tabs on the Ramp Cover (131) into the Ramp (130). 11. Apply grease to a Link Arm Axle (114). Insert the Link Arm Axle (114) into the Right Upper Body Leg (6) and the Right Link Arm (43) from the side shown.
  • Page 16 12. Identify the Right Upper Body Arm (8) and orient it as shown. Have a second person hold the Right Upper Body Arm (8) near the Right Upper Body Leg (6). Attach the Right Upper Body Arm (8) to the Right Upper Body Leg (6) with three M8 x 16mm Screws (102) and three M8 Split Washers (103).
  • Page 17 14. Untie and discard the wire tie attached to the Wire Harness (60). Avoid pinching the wires While a second person holds the Console (33) near the Upright (5), connect the wires on the Console to the Wire Harness (60) and to the Upper Pulse Wires (105).
  • Page 18 16. Attach the lower end of the Console (33) to the Upright (5) with two M4 x 19mm Screws (80). See step 14 on page 17. Tighten the M4 x 19mm Screws (80) in the upper end of the Console (33). 17.

  • Page 19: How To Use The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD A temporary adapter may 2-pole Receptacle This product must be grounded. If it should malfunc- be used to tion or break down, grounding provides a path of least connect the Adapter resistance for electric current to reduce the risk of...
  • Page 20 HOW TO FOLD AND UNFOLD THE ELLIPTICAL Next, pull the magnets on the pedal arms off the han- dlebars. Then, lift the latches under the pedal arms, When the ellipti- and set the pedal arms on the sleeves on the crank cal is not in use, arms.
  • Page 21 HOW TO EXERCISE ON THE ELLIPTICAL To dismount the elliptical, wait until the pedals come to a complete stop. Note: The elliptical does not have To mount the elliptical, hold the upper body arms and a free wheel; the pedals will continue to move until the flywheel stops.
  • Page 22 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The advanced console offers an array of features designed to make your workouts more effective and enjoyable. When you use the manual mode of the console, you can change the resistance of the pedals and the incline of the ramp with the touch of a button.
  • Page 23 HOW TO TURN ON THE POWER If you have selected a workout or the iFit Training mode, press the Menu button to return to the main IMPORTANT: If the elliptical has been exposed to cold menu. temperatures, allow it to warm to room temperature 3.
  • Page 24 Resistance—This display mode will show the When your pulse is detected, your heart rate will resistance level of the pedals for a few seconds appear in the display. For the most accurate heart each time the resistance level changes. rate reading, hold the contacts for at least 15 seconds.
  • Page 25 HOW TO USE A PRESET WORKOUT 3. Begin pedaling to start the workout. 1. Begin pedaling or press any button on the Each workout is divided into one-minute segments. console to turn on the console. One resistance level and one target rpm (pedaling pace) are programmed for each segment.
  • Page 26 HOW TO USE THE IFIT TRAINING MODE If the resistance level for the current segment is too high or too low, you can manually override the setting by pressing the Digital Resistance buttons. The optional iFit module allows your console to com- IMPORTANT: When the current segment of the municate with your wireless network and unlocks workout ends, the pedals will automatically...
  • Page 27 HOW TO USE THE INFORMATION MODE desired contrast level. Press the Enter button again to save your selection. The console features an information mode that allows 5. Determine if an iFit module is connected to the you to view usage information, select a unit of mea- console.

  • Page 28: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical regularly. Next, look into the access opening and locate the Replace any worn parts immediately. Reed Switch (69). Rotate the Large Pulley (74) until a Pulley Magnet (75) is aligned with the Reed Switch. To clean the elliptical, use a damp cloth and a small amount of mild soap.
  • Page 29 HOW TO ADJUST THE DRIVE BELT See EXPLODED DRAWING C on page 35. Remove the M4 x 16mm Round Head Screws (84) and the M4 If you can feel the pedals slip while you are pedaling, x 42mm Screws (83) from the Right and Left Shields (18, 19).

  • Page 30: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 31: Part List

    PART LIST Model No. 29826.3 R1212B Key No. Qty. Description Key No. Qty. Description Main Frame Large Latch Spring Folding Frame Latch Insert Front Stabilizer Long Latch Spring Rear Stabilizer Arm/Leg Bushing Upright M4 x 16mm Flat Head Screw Right Upper Body Leg...
  • Page 32 Key No. Qty. Description Key No. Qty. Description Small Pedal Arm Snap Ring Long C-pin M8 x 16mm Screw Short C-pin M8 Split Washer M4 x 12mm Screw Lift Arm Snap Ring Ramp Pulse Wire Ramp Cover M4 x 16mm Screw Ramp Bushing M10 x 20mm Screw Ramp Axle...

  • Page 33: Exploded Drawing

    EXPLODED DRAWING A Model No. 29826.3 R1212B...
  • Page 34 EXPLODED DRAWING B Model No. 29826.3 R1212B...
  • Page 35 EXPLODED DRAWING C Model No. 29826.3 R1212B...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) • the name of the product (see the front cover of this manual) • t he key number and description of the replacement part(s) (see the PART LIST and the EXPLODED DRAWING near the end of this manual) LIMITED WARRANTY IMPORTANT: To protect your fitness equipment with an extended service plan, see page 6.

This manual is also suitable for:

E 7.1

Table of Contents
