QuickSpecs
Memory
DIMM installation guidelines:
1. All DIMMs must be PC2-4200 DIMMs (DDR2 533MHz)
2. Both DIMM slots in a memory bank must be populated.
3. Banks must be populated in sequential numeric order, starting with bank 0.
4. Both DIMMs in a memory bank must be identical. Install identical DIMMs in pairs, starting with DIMM socket A, bank 0.
5. DIMMs must be installed in decreasing capacity with the largest DIMMs installed in the smallest numbered DIMM slot.
HP Integrity BL860c Server Blade
Standard Memory
4 GB Registered PC2-4200, DDR2 533MHz ECC DIMMs (4 x 1 GB)
Memory Bus Bandwidth:12.8 GB/s
Standard Memory Plus Optional Memory
Up to 48GB of PC2-4200, DDR2-533 DIMMs memory is available.
Memory
Standard 4 GB
Maximum 48 GB
Following are memory options available from HP:
HP 2GB PC4200 DDR-SDRAM(2x1GB DIMMs)
HP 4GB PC4200 DDR-SDRAM(2x2GB DIMMs)
HP 8GB PC4200 DDR-SDRAM(2x4GB DIMMs)
NOTE: Must be installed in pairs.
NOTE: DIMMs must be installed in decreasing capacity with the largest DIMMs smallest numbered slot.
0A 0B
1 GB 1 GB
1A 1B
1 GB 1 GB
0A 0B
4 GB 4 GB
1A 1B
4 GB 4 GB
DA - 12671 U.S. QuickSpecs — Version 18 — 2/18/2009
HP Integrity BL860c Server Blade
Slot
2A 2B
Empty Empty
3A 3B
Empty Empty
2A 2B
4 GB 4 GB
3A 3B
4 GB 4 GB
4A 4B
Empty Empty
5A 5B
Empty Empty
4A 4B
4 GB 4 GB
5A 5B
4 GB 4 GB
AD343A
AD344A
AD345A
