Daikin Quaternity FTXG09HVJU Engineering Data

Daikin Quaternity FTXG09HVJU Engineering Data

H series split-system room air conditioners
Hide thumbs Also See for Quaternity FTXG09HVJU:
Table of Contents

Advertisement

Quick Links

See also: Engineeiring Data , Service Manual
EDUS04-906_a
- Heat Pump -
H-Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quaternity FTXG09HVJU and is the answer not in the manual?

Questions and answers

Related Manuals for Daikin Quaternity FTXG09HVJU

Summary of Contents for Daikin Quaternity FTXG09HVJU

  • Page 1 EDUS04-906_a - Heat Pump - H-Series...

  • Page 2: Table Of Contents

    EDUS04-906 Split-System Room Air Conditioners H-Series Heat Pump FTXG09HVJU RXG09HVJU Quaternity FTXG12HVJU RXG12HVJU FTXG15HVJU RXG15HVJU 1. Power Supply ....................2 2. Functions.....................3 3. Specifications ....................4 4. Dimensions ....................6 5. Wiring Diagrams..................7 6. Piping Diagrams..................8 7. Capacity Tables ..................9 7.1 Heat Pump ....................9 8.

  • Page 3: Ftxg09Hvju Rxg09Hvju

    Power Supply EDUS04-906 1. Power Supply Indoor Units Outdoor Units Power Supply FTXG09HVJU RXG09HVJU φ Quaternity FTXG12HVJU RXG12HVJU , 208-230V, 60Hz FTXG15HVJU RXG15HVJU Note: Power Supply Intake ; Outdoor Unit Room Air Conditioners H-Series...

  • Page 4: Functions

    EDUS04-906 Functions 2. Functions Category Functions Category Functions Basic Inverter (with Inverter Power Control) Health & Air-Purifying Filter — Function Clean Operation Limit for Cooling (°FDB) Photocatalytic Deodorizing Filter — –4~ Air-Purifying Filter Operation Limit for Heating (°FWB) — with Photocatalytic Deodorizing Function PAM Control Titanium Apatite Photocatalytic Air-Purifying Filter...

  • Page 5: Specifications

    Specifications 60Hz 230V EDUS04-906 3. Specifications 60Hz 230V Indoor Units FTXG09HVJU FTXG12HVJU Models RXG09HVJU RXG12HVJU Outdoor Units Cooling Heating Cooling Heating Capacity Btu/h 9,000 (5,300~12,300) 12,000 (4,400~18,000) 12,000 (5,300~15,700) 16,000 (4,400~19,100) Rated (Min.~Max.) Moisture Removal Pt/h — — Running Current (Rated) 3.10 4.04 4.30...
  • Page 6 EDUS04-906 Specifications 60Hz 230V 230V Indoor Units FTXG15HVJU Model RXG15HVJU Outdoor Units Cooling Heating Capacity Btu/h 15,000 (5,300~18,000) 18,000 (4,400~21,200) Rated (Min.~Max.) Moisture Removal Pt/h — Running Current (Rated) 5.64 6.36 Power Consumption Rated (Min.~Max.) 1,160 (260~1,930) 1,320 (230~2,120) Power Factor 89.0 99.0 EER (Rated)

  • Page 7: Dimensions

    Dimensions EDUS04-906 4. Dimensions FTXG09/12/15HVJU THE MARK (→) SHOWS PIPING DIRECTION REQUIRED SPACE 35-1/16(890) AIR FLOW (INDOOR) REAR INCLUDING MOUNTING PLATE RIGHT LEFT 10-13/16(275) 10-3/4(273) 8-1/4(209) 1-15/16(50)MIN. 1-15/16(50)MIN. GEAR CASE UNIT FIXED SCREWS (SPACE FOR (SPACE FOR (INSIDE PANEL) MAINTENANCE) PERFORMANCE) NAME PLATE...

  • Page 8: Wiring Diagrams

    EDUS04-906 Wiring Diagrams 5. Wiring Diagrams FTXG09/12/15HVJU A1P~A5P : PRINTED CIRCUIT BOARD : FLAME GROUND : FUSE : MULTI MONITOR CAUTION H2P, H3P : PILOT LAMP outdoor NOTE THAT OPERATION WILL : LIMIT SWITCH FOR PANEL RESTART AUTOMATICALLY IF THE MAIN POWER SUPPLY IS : LIMIT SWITCH FOR STREAMER TURNED OFF AND THEN BACK : FAN MOTOR...

  • Page 9: Piping Diagrams

    Piping Diagrams EDUS04-906 6. Piping Diagrams FTXG09/12/15HVJU INDOOR UNIT HEAT EXCHANGER THERMISTOR SOLENOID VALVE ON HEAT EXCH. AT RATED VOLTAGE: CLOSED (UNDER DEHUMIDIFICATION OPERATION) CROSS FLOW FAN HEAT EXCHANGER FAN MOTOR FIELD PIPING 1/ 4(6.4)CuT SINGLE UNION JOINT 3/8(9.5)CuT FIELD PIPING 3/8(9.5)CuT SINGLE UNION JOINT REFRIGERANT FLOW...

  • Page 10: Capacity Tables

    EDUS04-906 Capacity Tables 7. Capacity Tables Heat Pump FTXG09HVJU + RXG09HVJU (60Hz 230V) Cooling 11.9 0.10 Temp: Celsius / TC, SHC, PI: kW INDOOR OUTDOOR TEMPERATURE (°CDB) 20.0 25.0 30.0 32.0 35.0 40.0 °C °C 14.0 2.70 2.42 0.44 2.58 2.37 0.48 2.46...
  • Page 11 Capacity Tables EDUS04-906 Symbols Note: : Airflow rate /min.) 1. Ratings shown are net capacities which include a deduction for indoor fan motor heat. : Bypass factor shows nominal (rated) capacities and power input. 3. TC, PI and SHC must be calculated by interpolation using the figures in : Entering wet bulb temp.
  • Page 12 EDUS04-906 Capacity Tables FTXG12HVJU + RXG12HVJU (60Hz 230V) Cooling 13.0 0.14 Temp: Celsius / TC, SHC, PI: kW INDOOR OUTDOOR TEMPERATURE (°CDB) 20.0 25.0 30.0 32.0 35.0 40.0 °C °F 14.0 3.61 2.86 0.66 3.44 2.78 0.72 3.28 2.71 0.79 3.21 2.68 0.81...
  • Page 13 Capacity Tables EDUS04-906 Symbols Note: : Airflow rate /min.) 1. Ratings shown are net capacities which include a deduction for indoor fan motor heat. : Bypass factor shows nominal (rated) capacities and power input. 3. TC, PI and SHC must be calculated by interpolation using the figures in : Entering wet bulb temp.
  • Page 14 EDUS04-906 Capacity Tables FTXG15HVJU + RXG15HVJU (60Hz 230V) Cooling 13.8 0.16 Temp: Celsius / TC, SHC, PI: kW INDOOR OUTDOOR TEMPERATURE (°CDB) 20.0 25.0 30.0 32.0 35.0 40.0 °C °C 14.0 4.51 3.36 0.89 4.30 3.26 0.98 4.10 3.15 1.06 4.02 3.11 1.10...
  • Page 15 Capacity Tables EDUS04-906 Symbols Note: : Airflow rate /min.) 1. Ratings shown are net capacities which include a deduction for indoor fan motor heat. : Bypass factor shows nominal (rated) capacities and power input. 3. TC, PI and SHC must be calculated by interpolation using the figures in : Entering wet bulb temp.

  • Page 16: Operation Limit

    EDUS04-906 Operation Limit 8. Operation Limit RXG09/12/15HVJU Cooling Heating (-4°FDB) 73.4 82.4 Indoor temp. (°FWB) Indoor temp. (°FDB) Notes: The graphs are based on the following conditions. • Equivalent piping length 25ft • Level difference 3D063096 • Air flow rate High Room Air Conditioners H-Series...

  • Page 17: Sound Level

    Sound Level EDUS04-906 9. Sound Level Measuring Location Indoor Unit 3.3ft (R5162) Outdoor Unit 3.3ft (R4796) Note: 1. Operation sound is measured in an anechoic chamber. 2. The data are based on the conditions shown in the table below. Cooling Heating Piping Length Indoor ;...

  • Page 18: Octave Band Level

    EDUS04-906 Sound Level Octave Band Level 9.2.1 Indoor Units FTXG09HVJU COOLING HEATING OVER ALL ( dB ) OVER ALL ( dB ) 60Hz 60Hz 60Hz 60Hz NC-60 NC-60 SCALE 208/230V 208/230V SCALE 208/230V 208/230V NC-50 NC-50 ( B.G.N IS ALREADY RECTIFIED ) ( B.G.N IS ALREADY RECTIFIED ) OPERATING CONDITIONS OPERATING CONDITIONS...

  • Page 19: Outdoor Units

    Sound Level EDUS04-906 9.2.2 Outdoor Units RXG09HVJU COOLING HEATING OVER ALL ( dB ) OVER ALL ( dB ) NC-60 NC-60 60Hz 60Hz SCALE SCALE 208-230V 208-230V NC-50 NC-50 ( B.G.N IS ALREADY RECTIFIED ) ( B.G.N IS ALREADY RECTIFIED ) OPERATING CONDITIONS OPERATING CONDITIONS NC-40...

  • Page 20: Electric Characteristics

    EDUS04-906 Electric Characteristics 10. Electric Characteristics Representative Unit Combination Power Supply COMP Indoor Unit Outdoor Unit Hz-Volts Voltage Range 60-208 0.13 MAX. 60Hz 253V FTXG09HVJU RXG09HVJU 14.5 0.10 MIN. 60Hz 187V 60-230 0.12 60-208 0.15 MAX. 60Hz 253V FTXG12HVJU RXG12HVJU 14.5 0.13 MIN.

  • Page 21: Installation Manual

    Installation Manual EDUS04-906 11. Installation Manual 11.1 Indoor Units Safety Precautions • Read these Safety Precautions carefully to ensure correct installation. • This manual classifies the precautions into DANGER, WARNING and CAUTION. Be sure to follow all the precautions below: they are all important for ensuring safety. DANGER ..Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 22: Choosing An Installation Site

    EDUS04-906 Installation Manual Safety Precautions WARNING • During installation, attach the refrigerant piping securely before running the compressor. If the compressor is not attached and the stop valve is open during pump-down, air will be sucked in when the compressor is run, causing abnormally high pressure which could lead to equipment damage and personal injury.

  • Page 23: Indoor Unit Installation Drawings

    Installation Manual EDUS04-906 Indoor Unit Installation Drawings Removing and installing indoor unit. • Installation method 1) Using the marks (3 locations) on top of the indoor unit, attach the mounting plate hooks Mounting Mounting onto the indoor unit. plate plate 2) Attach the tabs on the bottom frame onto the Bottom mounting plate.

  • Page 24: Installation Tips

    EDUS04-906 Installation Manual Installation Tips Removing and installing front panel. Rotating shaft Rotating shaft • Removal method 1) Open the front panel. 2) Spread out the shaft hole on the left side and remove the rotating shaft. Spread out the shaft hole on the right side as well Shaft hole Shaft hole and remove the rotating shaft.

  • Page 25: Drain Hose

    Installation Manual EDUS04-906 Installing the titanium apatite photocatalytic air-purifying filter and deodorizing filter for streamer. 1) Open the front panel to pull out the air filter. 2) Attach the titanium apatite photocatalytic air- Left side Right side purifying filter. Titanium apatite Deodorizing filter 3) Attach the deodorizing filter for streamer.

  • Page 26: Indoor Unit Installation

    EDUS04-906 Installation Manual Indoor Unit Installation Installing the mounting plate. • The mounting plate should be installed on a wall which can support the weight of the indoor unit. 1) Temporarily secure the mounting plate to the wall, make sure that the panel is completely level, and mark the boring points on the wall.
  • Page 27 Installation Manual EDUS04-906 Laying piping and wiring. • Lay the piping and drain hose according to the Piping bundle diagram orientation of the piping coming out of the unit, as shown below. Inter-unit wiring • Make sure the drain hose is sloped downward. Gas pipe Drain hose •...

  • Page 28: Wall Embedded Piping

    EDUS04-906 Installation Manual Indoor Unit Installation 4-4. Wall embedded piping. Inner wall Follow the instructions given under Insert drain hose to this depth so Left-side, left-back, or left-bottom piping it won’t be pulled out of drain pipe. 1) Insert the drain hose to this depth so it won’t be 1-15/16 inch Drain hose (50mm)
  • Page 29 Installation Manual EDUS04-906 Connecting to the HA system. 1) Remove the front grille. (3 screws) Fig. 1 Location of the tabs 2) Remove the decelerator assembly parts. on the electric parts box (1 screw) Anti-drip cover fixing screw 2-1) Remove the decelerator assembly part screws.

  • Page 30: Drain Piping

    EDUS04-906 Installation Manual Indoor Unit Installation Drain piping. The drain hose should be inclined downward. 1) Connect the drain hose, as described right. No trap is permitted. Do not put the end of the hose in water. 2) Remove the air filters and pour some water into the drain pan to check the water flows smoothly.

  • Page 31: Refrigerant Piping Work

    Installation Manual EDUS04-906 Refrigerant Piping Work Flaring the pipe end. (Cut exactly at 1) Cut the pipe end with a pipe cutter. right angles.) Remove burrs 2) Remove burrs with the cut surface facing downward Flaring so that the chips do not enter the pipe. Set exactly at the position shown below.
  • Page 32 EDUS04-906 Installation Manual Trial Operation and Testing Trial operation and testing. 1-1. Measure the supply voltage and make sure that it falls in the specified range. 1-2. Trial operation should be carried out in either cooling or heating mode. • In cooling mode, select the lowest programmable temperature; in heating mode, select the highest programmable temperature.

  • Page 33: Outdoor Units

    Installation Manual EDUS04-906 11.2 Outdoor Units Safety Precautions (1) • Read these Safety Precautions carefully to ensure correct installation. • This manual classifies the precautions into DANGER, WARNING and CAUTION. Be sure to follow all the precautions below: they are all important for ensuring safety. DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 34 EDUS04-906 Installation Manual Safety Precautions (2) WARNING • During pump-down, stop the compressor before removing the refrigerant piping. If the compressor is still running and the stop valve is open during pump-down, air will be sucked in when the refrigerant piping is removed, causing abnormally high pressure which could lead to equipment damage or and personal injury. •...

  • Page 35: Precautions On Installation

    Installation Manual EDUS04-906 Precautions on Installation • Ensure the strength and level of the installation will not cause any operating vibration or noise after installed. • In accordance with the foundation drawing, fix the unit securely by means of the foundation bolts. (Prepare four sets of 3/8 inch (M10) or 7/16 inch (M12) foundation bolts, nuts and washers each which are available on the market.) •...

  • Page 36: Installing Outdoor Unit

    EDUS04-906 Installation Manual Outdoor Unit Installation (1) Installing outdoor unit. 1) When installing the outdoor unit, refer to “Precautions for Selecting the Location” and the “Outdoor Unit Installation Drawings”. 2) If drain work is necessary, follow the procedures below. Drain work (heat pump-models). 1) Use drain plug for drainage.

  • Page 37: Outdoor Unit Installation

    Installation Manual EDUS04-906 Outdoor Unit Installation (2) Purging air and checking gas leakage. • When piping work is completed, it is necessary to purge the air and check for gas leakage. WARNING 1) Do not mix any substance other than the specified refrigerant (R410A) into the refrigeration cycle. 2) When refrigerant gas leaks occur, ventilate the room as soon and as much as possible.

  • Page 38: Pump Down Operation

    EDUS04-906 Installation Manual Outdoor Unit Installation (3) Refilling the refrigerant. Check the type of refrigerant to be used on the machine nameplate. Filling a cylinder with an Filling other cylinders Precautions when adding R410A attached siphon Fill from the liquid pipe in liquid form. Stand the cylinder upright Turn the cylinder when filling.
  • Page 39 Installation Manual EDUS04-906 Wiring (1) WARNING 1) Do not use spliced wires, stranded wires, extension cords, or starburst connections, as they may cause overheating, electrical shock, or fire. Follow all Local, and State electrical codes. 2) Do not use locally purchased electrical parts inside the product. (Do not overload the circuit by adding drain pump or other electrical equipment to unit terminals.) Doing so may cause electric shock or fire.

  • Page 40: Test Run And Final Check

    EDUS04-906 Installation Manual Wiring (2) CAUTION (1) In case using stranded wires is unavoidable for some reason, Round make sure to install the round crimp-style terminals on the tip. crimp-style terminal Stranded Place the round crimp-style terminals on the wires up to the wire covered part and secure in place.

  • Page 41: Operation Manual

    Operation Manual EDUS04-906 12. Operation Manual Avoid exposure to airflow for long periods of time. Room Air Conditioners H-Series...
  • Page 42 EDUS04-906 Operation Manual Avoid direct exposure to airflow. Keep unit free of leaves and insects that can cause malfunction or electrical fire. Room Air Conditioners H-Series...
  • Page 43 Operation Manual EDUS04-906 QUATERNITY DRYING / DRY COOLING....YELLOW The lamp color also changes according to the optional function Room Air Conditioners H-Series...
  • Page 44 EDUS04-906 Operation Manual Ground terminal Room Air Conditioners H-Series...
  • Page 45 Operation Manual EDUS04-906 DRY button Room Air Conditioners H-Series...
  • Page 46 EDUS04-906 Operation Manual Room Air Conditioners H-Series...
  • Page 47 Operation Manual EDUS04-906 Room Air Conditioners H-Series...
  • Page 48 EDUS04-906 Operation Manual Room Air Conditioners H-Series...

  • Page 49: Dry Operation

    Operation Manual EDUS04-906 COOLING DRY Operation • “DRY COOLING” Operation DRY operation Constant (60% RH) (55% RH) (50% RH) (no change) Note on “Dry Cooling” operation “DRY COOLING” may raise humidity temporarily. Note on Dry Operation The operation mode change from COOLING to DRY may raise humidity temporarily. Room Air Conditioners H-Series...
  • Page 50 EDUS04-906 Operation Manual Room Air Conditioners H-Series...
  • Page 51 Operation Manual EDUS04-906 Room Air Conditioners H-Series...
  • Page 52 EDUS04-906 Operation Manual Room Air Conditioners H-Series...

  • Page 53: Operation Manual

    Operation Manual EDUS04-906 COOLING or “DRY COOLING” operation, the A) FLASH STEAMER AIR PURIFYING individual operation B) “DRY COOLING” • COOLING C) HEATING Room Air Conditioners H-Series...
  • Page 54 EDUS04-906 Operation Manual COOLING BREEZE operation is for COOLING, “DRY COOLING” AND FLASH STREAMER, AIR PURIFYING operation. Room Air Conditioners H-Series...
  • Page 55 Operation Manual EDUS04-906 Room Air Conditioners H-Series...
  • Page 56 EDUS04-906 Operation Manual -1.8°F (-1°C) -3.6°F (-2°C) Room Air Conditioners H-Series...
  • Page 57 Operation Manual EDUS04-906 Room Air Conditioners H-Series...
  • Page 58 EDUS04-906 Operation Manual COOLING or “DRY COOLING” mode or Room Air Conditioners H-Series...
  • Page 59 Operation Manual EDUS04-906 Room Air Conditioners H-Series...
  • Page 60 EDUS04-906 Operation Manual Room Air Conditioners H-Series...
  • Page 61 Operation Manual EDUS04-906 Room Air Conditioners H-Series...
  • Page 62 EDUS04-906 Operation Manual Room Air Conditioners H-Series...
  • Page 63 Operation Manual EDUS04-906 Room Air Conditioners H-Series...
  • Page 64 EDUS04-906 Operation Manual Room Air Conditioners H-Series...
  • Page 65 Operation Manual EDUS04-906 Room Air Conditioners H-Series...
  • Page 66 EDUS04-906 Operation Manual Room Air Conditioners H-Series...
  • Page 67 Operation Manual EDUS04-906 Room Air Conditioners H-Series...
  • Page 68 EDUS04-906 Operation Manual Room Air Conditioners H-Series...
  • Page 69 Operation Manual EDUS04-906 Room Air Conditioners H-Series...
  • Page 70 EDUS04-906 Operation Manual 3P226009-1 Room Air Conditioners H-Series...

  • Page 71: Optional Accessories

    Optional Accessories EDUS04-906 13. Optional Accessories 13.1 Option List 13.1.1 Indoor Units Option Name FTXG09/12/15HVJU Centralized Control Board-Up to 5 Rooms KRC72 Wiring Adapter for Time Clock / Remote Control KRP413A1S (Normal Open Pulse Contact / Normal Open Contact) Central Remote Controller (Fahrenheit) DCS302C71 Central Remote Controller (Celsius) DCS302CA61...

  • Page 72: Installation Manual

    2. Field Wiring Below is a key to symbols used in this manual. For interconnecting wiring, use Daikin KDC100A12 cable (not supplied) or Be sure to follow instructions. other similar cable. The cable should have the specifications shown below.
  • Page 73 Optional Accessories EDUS04-906 Installation This product is available in two types. The KRP413A1S · KRP413AA1S is for installation in a case independent of the indoor unit, and KRP413A1 is for installation within the indoor unit. 1. KRP413A1S · KRP413AA1S 3. Attaching Adaptor Case Assy (for KRP413A1S · KRP413AA1S) Installation diagram Using the screws (to mount on a wall, etc.) Adaptor case...
  • Page 74 EDUS04-906 Optional Accessories Wiring 1. Wiring 4. Connection with Remote Controller Connect one end of the wiring to connector S21 of the PCB in the Example connections with three kinds of remote controllers are shown indoor unit. bellow. Connect the other end of the wiring to connector S6 of the adaptor Note: These connections cannot be used in combination.
  • Page 75 Optional Accessories EDUS04-906 Test Operation and Confirmation 1. When the System is Not Working Is the air conditioner working properly? Are the connectors of the wiring properly connected? Are the remote controller and field wiring properly connected? Are all switch settings correct? If there is nothing apparently wrong, conduct a diagnostic check using the following procedure.

  • Page 76: Safety Precautions

    1.Overview, Features and Compatible Models Safety Precautions This kit is the interface required when connecting the central controller and a Daikin Room Air Read these Safety Precautions carefully to ensure correct installation. Conditioner. Use of the central controller makes it possible to perform the following monitoring This manual classifies precautions into WARNING and CAUTION.

  • Page 77: Switch Settings

    Optional Accessories EDUS04-906 4.Switch Settings 5.Control Codes When using a central remote controller, the operating codes can be used to limit T u rn the power on after all the switches have been set. operation from wireless remote controllers. NOTE Settings made while the power is on are invalid.

  • Page 78: Before Installation

    EDUS04-906 Optional Accessories 13.2.3 KPW937A4 Before Installation Check the following parts Checking the parts Name Louver Installation manual Shape With 4 screws Quantity 1piece 1piece Installation Procedure Selection of Installation Location Use when installing in a location that meets the following conditions. When installing near the border to a neighbor's house If exhaust blows directly on passers-by because outdoor unit is installed facing a road.
  • Page 79 Optional Accessories EDUS04-906 Room Air Conditioners H-Series...
