- Page 1 ESP-2 OPTO Serial Hub Installation and User Guide 590-397-001B October 2004...
-
Page 3: Table Of Contents
5.3 Passwords ............26 Equinox ESP-2 OPTO Serial Hub Installation and User Guide... - Page 4 6.8 Completion Status..........35 Equinox ESP-2 OPTO Serial Hub Installation and User Guide...
-
Page 5: Section 1 - Introduction
RS-232 serial ports. The optical coupling uses ground and positive voltage from the target devices (TDs) that are attached to the ESP-2 OPTO hub serial ports; there is no metallic connection between the ESP-2 OPTO hub and the TD or between the two TDs. -
Page 6: What You Get
Installation Guide (this document) 021-0013 Split/Snap-On Ferrite Core The ESP-2 OPTO serial hub model includes an external power supply with an attached PS-to-unit barrel connector. The line cord for the power supply is appropriate to the intended country of operation. -
Page 7: Section 2 - Hardware
Section 2 - Hardware All connectors, LEDs and buttons are on the front of the ESP-2 OPTO serial hub, as shown in Figure 1. Figure 1: ESP-2 OPTO Serial Hub The POWER connector is located in the lower left corner of the front panel; see Electrical on page 5 for more information. - Page 8 ** DSR and CTS are required for operation, but are not seen by the hub’s CPU. Table 5 lists the pin assignments for the RJ-45 shielded Ethernet connector. The 4- wire power and 8-wire power columns apply to ESP-2 OPTO hubs that use POE; additional information follows the table.
-
Page 9: Electrical
The polarity itself is undefined. In powered network cables with the full CAT 5 cable (4 twisted pairs), power may be provided as described for the two-pair method or over the two spare twisted pairs (polarity undefined), but not both. The ESP-2 OPTO serial hub will automatically accept either method. -
Page 10: Installing On A Table
Make the power connection for the hub. If the hub’s power will be supplied through the external power supply, plug the barrel connector of the PS into the front of the ESP-2 hub, then attach the line cord connector to an appropriate power source. -
Page 11: Installing The Ferrite Core (Poe Only)
A split/snap-on ferrite core (part number 021-0013) is included in the shipment. It is recommended that this be used to further suppress electromagnetic interference (EMI) for ESP-2 POE hubs by installing the ferrite core on the LAN (Ethernet) cable. Use Figure 2 for reference. -
Page 12: Reinitializing And Resetting The Hub
Be careful to avoid crimping or squeezing any part of the cable. Use of the ferrite core is the responsibility of the user. The ESP-2 OPTO hub generates, uses and may radiate radio frequency energy and, if not used in accordance with these instructions, may cause harmful interference to radio communications. -
Page 13: Section 3 - Serial Port Connection Methods And Attributes
Section 3 - Serial Port Connection Methods and Attributes There are several methods a remote device may use to access a serial port on an ESP-2 OPTO hub and then transmit/receive data from that port: • Serial port redirection - see page 9 •... -
Page 14: Telnet Server
For example, a value of 100 indicates that once serial data is received, the Serial ESP-2 hub will buffer the data until 1 second (100 hundredths of a second) has buffering elapsed, at which time all data will be sent. -
Page 15: Raw Tcp Server
For example, a value of 100 indicates that once serial data is received, the Serial ESP-2 hub will buffer the data until 1 second (100 hundredths of a second) has buffering elapsed, at which time all data will be sent. -
Page 16: Raw Tcp Client
Valid values are 0-65535 hundredths of a second. For example, a value of 100 indicates that once serial data is received, the ESP-2 hub will buffer the data until 1 second (100 hundredths of a second) has Serial buffering elapsed, at which time all data will be sent. -
Page 17: Configuration Utility
For example, a value of 100 indicates that once serial data is received, the Serial ESP-2 hub will buffer the data until 1 second (100 hundredths of a second) has buffering elapsed, at which time all data will be sent. -
Page 18: Serial Port Attributes
Valid values: None, Even, Odd, Mark and Space Parity Default value: None Valid values: 1 and 2 Stop bits Default value: 1 Valid values: None and XON/XOFF Flow control Default value: None Flow control settings are full duplex Equinox ESP-2 OPTO Serial Hub Installation and User Guide... -
Page 19: Section 4 - Web Interface
4.1 Accessing the Web Interface The ESP-2 web interface may be accessed using any standard web browser with the IP address of the hub as the URL. For example, if an ESP-2 serial hub has an IP address of 192.168.0.5, entering the URL will connect to the web interface. -
Page 20: Passwords
When using the web interface, the password is encrypted by the browser when it is sent to the interface. If you reinitialize the ESP-2 serial hub, the password is lost. You will be required to create a password the next time you access the web interface or the configuration utility. -
Page 21: Displaying Or Changing Port Attributes And Connection Methods
To reboot, click the Reboot button. If the IP address had not been previously set (or the hub has been reinitialized), the ESP-2 hub reboots automatically. 4.5 Displaying or Changing Port Attributes and Connection Methods The Port 1 Configuration display includes the serial port attributes and connection methods for port 1. -
Page 22: Displaying Hardware Information
Click the Apply button. The update process may take up to 30 seconds to complete. After the update completes, status will be displayed. To update the bootstrap image: Click the Update Bootstrap button. The Bootstrap Image Update window appears. Equinox ESP-2 OPTO Serial Hub Installation and User Guide... -
Page 23: Displaying Or Changing Configurable Features
Click the Apply button. The update process may take up to 30 seconds to complete. After the update completes, status will be displayed. The new FLASH image will be used after the ESP-2 serial hub reboots. 4.8 Displaying or Changing Configurable Features The Configurable Features display includes the current settings of the features described in Table 14. -
Page 24: Displaying General Statistics
4.11 Displaying Port Statistics The Port Statistics display includes the information described in Table 16 for each port. All values are cumulative since the ESP-2 serial hub was last reset. This display refreshes every five seconds. Equinox ESP-2 OPTO Serial Hub Installation and User Guide... -
Page 25: Displaying Connection Status
If no time-out was configured, this field indicates disabled. Number of minutes and seconds remaining until the inactivity Time Remaining time-out occurs. If no time-out was configured, this field indicates not applicable. Equinox ESP-2 OPTO Serial Hub Installation and User Guide... -
Page 26: Rebooting The Hub
The Port Redirection Connections section includes the information described in Table 18 about the servers that are connected to each of the ESP-2 serial ports. This display is meaningful only when a serial port is being accessed using the serial redirection connection method. -
Page 27: Reinitializing The Hub
30 seconds, direct your browser to the predefined IP address (192.1.1.1). You may also reinitialize the ESP-2 serial hub using the configuration utility (see Reinitializing the Hub on page 30) or the INIT button on the front panel (see Reinitializing on page 8). -
Page 28: Section 5 - Configuration Utility
The configuration utility may be accessed three ways: with Telnet, by serial connection to port 1 when the ESP-2 serial hub has no configured IP address or by serial connection to the port(s) that have the configuration utility connection method enabled. -
Page 29: About The Configuration Utility Interface
(usually ). If the serial configuration utility connection method is used to access the utility and an inactivity time-out is enabled, a session will end if the inactivity period is reached. Equinox ESP-2 OPTO Serial Hub Installation and User Guide... -
Page 30: Passwords
If you reinitialize the ESP-2 serial hub, the password is lost; you will be required to create a password the next time you access the configuration utility or the web interface. -
Page 31: Displaying Or Changing Port Attributes And Connection Methods
See this table for descriptions, rules and values Serial port redirection Table 7 on page 9 Telnet server Table 8 on page 10 Raw TCP server Table 9 on page 11 Equinox ESP-2 OPTO Serial Hub Installation and User Guide... -
Page 32: Displaying Hardware Information
From the Server Configuration menu, enter to select Flash status and update. The application image information is displayed. You are prompted to update the application image. Enter for yes or for no. Equinox ESP-2 OPTO Serial Hub Installation and User Guide... -
Page 33: Displaying Or Changing Configurable Features
The Configurable Features display includes the current settings of the features described in Table 14 on page 19. When the ESP-2 serial hub is reinitialized, all configurable features are restored to their default settings. To view or change configurable features: From the Top Menu, enter to select Server Configuration. -
Page 34: Rebooting The Hub
From the Server Configuration menu, enter to select Reboot. You may also reboot the ESP-2 serial hub using the web interface (see Rebooting the Hub on page 22) or the RESET button on the front panel (see Resetting on page 8). -
Page 35: Displaying Connection Status
The Port Redirection Connections section includes the information described in Table 18 on page 22 about the servers that are connected to each of the ESP-2 serial ports. This display is meaningful only when a serial port is being accessed using the serial redirection connection method. -
Page 36: Section 6 - Configuration Files
A configuration file may also be downloaded using the web interface or the configuration utility. A file-based reconfiguration of an ESP-2 hub may also be initiated using a third party SNMP agent. An SNMP MIB is available through Equinox Technical Support. -
Page 37: Port Connection Method Commands
In commands that require a port number, you may specify instead of a port number if you wish the command to be applied to both ESP-2 MI hub serial ports. The command syntax in this manual uses the following conventions: •... -
Page 38: Port Tcp Server Command
[PARITY=NONE|EVEN|ODD|MARK|SPACE] [STOP=1|2] [FLOW=NONE|XON/XOFF] 6.5 Network Command The Network command specifies the ESP-2 hub address information. NETWORK IP=<ip> MASK=<mask> GATEWAY=<gateway> The addresses must be entered in standard IP dot notation. The gateway address must be in the same subnet as the IP address. You cannot set the IP address to: a Class A address of 0.0.x.x, a loopback address of 127.x.x.x, the default value of 192.1.1.1 or... -
Page 39: Configurable Features Commands
When used from a BootP or SNMP server, no user interaction is required when a configuration file is downloaded. Specify the configuration file as the “bootfile” option on the server. (To use a DHCP server, the ESP-2 hub must have an infinite lease on its assigned IP address.) When using the web interface, follow the instructions in Downloading a Configuration File on page 19. -
Page 40: Declaration Of Conformity
Canada This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Equinox ESP-2 OPTO Serial Hub Installation and User Guide... -
Page 41: European Union
Communications du Canada. European Union WARNING: This is a Class A product. In domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Equinox ESP-2 OPTO Serial Hub Installation and User Guide... - Page 42 Equinox ESP-2 OPTO Serial Hub Installation and User Guide...
- Page 43 FLASH 28 displaying information in the web using debug features 31 interface 18 Configuration utility connection method installation 5 about 13 configurable items description 13 setting in a configuration file 34 Equinox ESP-2 OPTO Serial Hub Installation and User Guide...
- Page 44 12 setting attributes in the configuration configurable items description 12 utility 27 setting in a configuration file 34 setting attributes in the web interface 17 setting in the configuration utility 27 Equinox ESP-2 OPTO Serial Hub Installation and User Guide...
- Page 45 22 reinitializing 23 setting configurable features 19 setting connection methods 17 setting network address values 16 setting password 16 setting port attributes 17 setting RS-485 transfer mode 17 updating FLASH 18 Equinox ESP-2 OPTO Serial Hub Installation and User Guide...
- Page 46 Equinox ESP-2 OPTO Serial Hub Installation and User Guide...
-
Page 47: Limited Warranty
LIMITED WARRANTY Equinox warrants that the Product(s) shall be free from manufacturing defects in materials and workmanship for a period of five (5) years from the date of delivery provided that the Product was properly installed and used. Defects, malfunctions or failures of the warranted Product caused by damage resulting from acts of God (such as floods, fire, etc.), environmental and atmospheric disturbances, other external forces such as power line disturbances, host computer malfunction, plugging the... - Page 48 Equinox Systems One Equinox Way Sunrise, Florida 33351-6709 (954) 746-9000 Fax: (954) 746-9101 ftp.equinox.com www.equinox.com support@equinox.com...
