Extech Instruments MN16A User Manual page 13

Function Range
5.000Hz
Frequency
50.00Hz
500.0Hz
5.000kHz
50.00kHz
500.0kHz
5.000MHz
Sensitivity: >0.5V rms min. [ 1MHz; >3V rms > 1MHz
NOTE:
Accuracy is stated at 65
Diode Test
Continuity Check
Temperature Sensor
Input Impedance
AC Response
ACV Bandwidth
Display
Overrange indication
Auto Power Off
Polarity
Measurement Rate
Low Battery Indication
Battery
Fuses
Operating Temperature 41°F to 104°F (5°C to 40°C)
Storage Temperature
Operating Humidity
Storage Humidity
Operating Altitude
Weight
Size
Safety
Approvals
Resolution
0.001Hz
0.01Hz
0.1Hz
0.001kHz
0.01kHz
0.1kHz
0.001MHz
o o o
F to 83 F (18 C to 28
Test current of 0.3mA typical, open circuit voltage 1.5V DC typical
Audible signal will sound if the resistance is less than 150Ω (approx.), test
current <0.3mA
Requires type K thermocouple
7.8MΩ
Average responding
50Hz to 400Hz
4,000 count liquid crystal
"OL" is displayed
30 minutes (approximately)
Automatic (no indication for positive); Minus (-) sign for negative
2 times per second, nominal
" " is displayed if battery voltage drops below operating voltage
Two AAA batteries
mA, µA ranges; 0.5A/250V ceramic fast blow
A range; 10A/250V ceramic fast blow
-4°F to 140°F (-20°C to 60°C)
Max 80% up to 87°F (31°C) decreasing linearly to 50% at 104°F (40°C)
<80%
7000ft. (2000meters) maximum.
0.5lb (225g) (includes holster).
5.31" x 2.67" x 1.7" (135 x 68 x 43mm)
This meter is intended for indoor use and protected, against the users, by
double insulation per EN61010-1 and IEC61010-1 2nd Edition (2001) to
CAT III 600V; Pollution Degree 2. The meter also meets UL 61010-1,
Second Edition (2004), CAN/CSA C22.2 No. 61010-1, Second Edition
(2004), and UL 61010B-2-031, First Edition (2003)
CE, ETL
Accuracy
±(1.5% reading + 5 digits)
±(1.2% reading + 3 digits)
±(1.5% reading + 4 digits)
o
C) and less than 75% RH.
13 MN16A V1.4 03/12
