Watertile Rainshower
Installation and User Guide
MODEL NUMBERS
8030A
Important! Please quote the above model number(s) when ordering spares
IMPORTANT
INSTALLER: THIS MANUAL IS THE PROPERTY OF THE
CUSTOMER AND MUST BE RETAINED WITH THE PRODUCT
FOR MAINTENANCE AND OPERATIONAL PURPOSES.
1071288-AN2-F
09/03/12
1
Advertisement
Table of Contents
Related Manuals for Kohler 8030A
Summary of Contents for Kohler 8030A
- Page 1 Watertile Rainshower Installation and User Guide MODEL NUMBERS 8030A Important! Please quote the above model number(s) when ordering spares IMPORTANT INSTALLER: THIS MANUAL IS THE PROPERTY OF THE CUSTOMER AND MUST BE RETAINED WITH THE PRODUCT FOR MAINTENANCE AND OPERATIONAL PURPOSES.
-
Page 2: Before You Begin
BEFORE YOU BEGIN All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time without notice. Please leave these instructions for the consumer. -
Page 3: Specification
Make sure that the Watertile Rainshower is installed by a competent installer. Before installation carefully inspect the new fixture for any signs of damage. Kohler Co. reserves the right to make revisions in the design of products without notice. 1071288-AN2-F... - Page 4 Install the Supply Pipework - Single Supply Pressure Balancing Loop 127 mm 127 mm Soldering Template G1/2" Nipple G1/2" Male Thread Pressure Adapter with Flow Control Balancing Loop Soldering Template Install the water supply pipes. Use the soldering template to construct a pressure balancing loop, this will ensure correct alignment with the product.
- Page 5 Install the Support Framework Existing Ceiling 229 mm Joist 2 x 2 (50 mm x 50 mm) 2 x 4 (50 mm x 100 mm) 2 x 4 368 mm (50 mm x 100 mm) Typical 2 x 2 (50 mm x 50 mm) 2 x 4 50 mm x 100 mm) Existing...
- Page 6 Install the Pipe Nipples Remove the pipe nipples. Note! The minimum distance between the face of the tees/elbows and the surface of the finished ceiling should be 57 mm. The measurement for typical installations is 70 mm. Measure the distance from the face of the tees/elbows to the surface of the finished ceiling.
- Page 7 Install the adapter onto one of the nipples using the 11 mm bit (supplied), 11 mm or 7/16” socket, the extension and the socket wrench. Note! Use masking tape to hold the bit in place, as the bit could fall off and cause damage.
- Page 8 Applying pressure evenly, press the membrane seal into the sprayhead groove. Install the Sprayface Ribs Finished Ceiling Sprayface Setscrews Tilt the sprayhead downward so that the ribs on the top of the sprayhead are exposed. Note! For product with brushed finishes, align the brush pattern of the sprayfaces with the direction of the brushed pattern of the concealing plate.
-
Page 9: Spare Parts
SPARE PARTS 1054349 Template 1059024** Escutcheon 1051498 Nipple G1/2” 1056179 3/16” Wrench 1036043 Shield 1055988 1055233 Gasket Adapter 1051681 Screen Washer 1044060 O-Ring 1071652 11 mm 1032955 5/64” Wrench Hex Bit 1041362 Wire 1045773 1036038 Base Screw 1056104 (Includes Spring Washer Clamps) 1036040 Spacer... -
Page 10: Care And Cleaning
Adapter CARE AND CLEANING Like anything of lasting quality, Kohler tapware and fittings require a certain amount of periodic care to preserve their lustrous finish. Clean your new Kohler tapware and fittings with a mild soap, rinse thoroughly with warm water and dry with a clean, soft cloth. The ideal cleaning technique is to always blot dry any water from metal surfaces.
