- Page 1 Installation & User Guide Dual-Flush Two Piece Toilet 12756A-0 7380A-0 12757A-0 12695A-0 8833A-0, 8835A-0 12754A-0 12758A-0, 12759A-0 45541A-0 45542A-0 1104782-A2-D...
-
Page 2: Tools And Materials
Tools and Materials Thank You For Choosing Englefield Thank You For Choosing Englefield. We appreciate your commitment to Englefield quality. Please take a few minutes to review this manual before you start installation. If you encounter any installation or performance problems, please don’t hesitate to contact us. Our phone numbers and website are listed on the back cover. - Page 3 Included components Description Image Suite code Seat Tank Domani link piece 12754A-0 18302A-0 18303A-0 1063069 S-Trap 4 star Emerald CC 45541A-0 18304A-0 18309A-0 16998A-0 S-Trap 4 star Emerald CC 45542A-0 18305A-0 18309A-0 16998A-0 P-Trap 4 star Delano CC 8833A-0 8831A-0...
-
Page 4: Installation
Installation Remove the existing toilet: Turn off the water supply and flush the toilet, then sponge out all remaining water from the cistern. Disconnect the supply shut-off valve (if present), and remove the old pan and cistern. CAUTION: Risk of hazardous gases. If the new toilet is not installed immediately, temporarity stuff a rag in the closet flange. - Page 5 Floor fixing option Bracket Drill 3/8” (10 mm) mounting hole between the mark locations on the floor and insert the anchor. Install the washer and insert the hexagon screw into the bracket then tighten the screw. Install the sleeves, tighten the screw and attach the caps.
- Page 6 Cistern Mounting Hole: Install Install the Cistern to Wall: Drill sufficient backing behind the finished 15/16” (8 mm) mounting hole on wall. Mark the cistern mounting hole mark location, insert the anchors. according to the rough-in. Position the cistern, tighten the (Alpha cistern only) screw and attach the caps.
- Page 7 Tank fixing Position the cistern on the pan by centering the gasket on the pan inlet. As- semble the retaining washing and sealing washer to the screw. Securely tighten the screw so the cistern is level. * Optional for different product Brass* Gasket Retaining Washer...
- Page 8 Bottom Water Inlet - Close Coupled Bottom Water Inlet - Coversion Kit (148794A-NA) Stop Valve Tank Hose Inlet Valve Inlet Valve Flush Valve Flush Valve For use with models: 7380A-0 Models: 12756A-0, 12757A-0, 12695A-0 8833A-0, 8835A-0, 12758A-0, 12759A-0, 45541A-0, 45542A-0 ENGLEFIELD 1104782-A2-D...
- Page 9 Install the Push Buttons Disassemble the push rods. Using the push rod, measure the distance between the flush valve and the top of the tank lid. Mark this lengh and cut the push rod to length. Cut the push rod to length. Reassemble the push rods. Fit the lid and test the buttons.
- Page 10 Install Flush Valve Flush Valve A Release flush valve by turning Assemble flush valve by pushing right and pulling straight up on the straight down into the canister and canister. turning left. Flush Valve B Release flush valve by squeezing Assemble flush valve by pressing it into the flush valve base so it snaps the tabs on both sides of the into place.
- Page 11 1104782-A2-C ENGLEFIELD...
- Page 12 For warranty information, please visit our website Australia www.englefield.com New Zealand www.englefield.co.nz CALL US FOR HELP NEW ZEALAND AUSTRALIA KOHLER NZ LTD KOHLER CO. Free Ph: 1 800 228 476 Free Ph: 0800 100 382 www.englefield.com Free Fax: 0800 664 488 www.englefield.co.nz 1104782-A2-D...
