Kohler 31141T-NA Installation Instructions

INSTALLATION INSTRUCTIONS
安装说明书
安装之前
所有的资料是按最新出版的产品资料编写而成。科勒
公司保留任何时候不经通知即可改变产品特性、包装
或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，请
把这些资料交给用户阅读。
注意事项：
1. 一定要先彻底冲洗供水管以清除管道中的杂质。
2. 检查供水管有无损坏和漏水。如需要，进行替换
和维修。
3. 遵守当地管路安装条例。
4. 埋墙前测试安装连接部位是否有渗漏，根据需要
修理之。
5. 本产品只接受水压测试，且测试前需先排空管路与
龙头之间的空气。测试水压不超过0.8MPa(8bar)，
时间不超过30分钟。
6. 对于31141T-NA，搭配一字把手；对于34667T-NA
搭配十字把手或其它把手。
安装尺寸
G1/2˝
Hot
(热)
Ø35~Ø40
1443561-T2-B
Two-Handle Wall-Mount Sink Faucet Valve A Version
31141T-NA 双把墙出水脸盆龙头阀芯 A型
34667T-NA 双把墙出水脸盆龙头阀芯 B型
280
252
Ø35~Ø40
200
BEFORE YOU BEGIN
All information is based on the latest product
information available at the time of publication.
Kohler Co. reserves the right to make changes in
product characteristics, packaging, or availability at
any time without notice.
Please leave these instructions for the consumer.
They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove
debris.
2. Inspect the supply tubing for damage and leakage.
Replace and maintain as necessary.
3. Observe local plumbing codes.
4. Check for leaks before covering the pipes, repairs
as needed.
5. Please ensure only apply water pressure test
on the product, and empty the air in pipe and faucet
thoroughly before the test. Please ensure test
pressure below 0.8MPa(8bar) and test duration
within 30 minutes.
6. For 31141T-NA, match with lever handles.
，
For 34667T-NA, match with cross handles or others.
ROUGH-IN DIMENSIONS
G1/2˝
Cold
(冷)
17
1
