Impex MARCY NS-652 Owner's Manual

Marcy foldable bike
Hide thumbs Also See for MARCY NS-652:

Advertisement

Table of Contents

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
NS-652
Retain This
Manual for
Reference
130204
OWNER'S
MANUAL
MARCY
Foldable Bike
NS-652
IMPEX
2801 S. Towne Ave, Pomona, CA 91766
Tel: (800) 999-8899
www.impex-fitness.com
info@impex-fitness.com
®
®
INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MARCY NS-652 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Impex MARCY NS-652

Summary of Contents for Impex MARCY NS-652

  • Page 1 NOTE: Please read all instructions carefully before using this product ® MARCY Table of Contents Safety Notice Foldable Bike Hardware Pack NS-652 Assembly Instruction Parts List Warranty Ordering Parts Model NS-652 Retain This Manual for Reference 130204 OWNER'S ® IMPEX INC.

  • Page 2: Table Of Contents

    ORDERING PARTS..................….. BEFORE YOU BEGIN ® Thank you for selecting the MARCY MARCY Foldable Bike NS-652 by ® IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notices

    IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.

  • Page 4: Warning Label Placement

    WARNING LABEL REPLACEMENT The Warning Label shown here has been placed on the rear Stabilizer. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown. Impex Inc. www.impex-fitness.com...

  • Page 5: Pre-Assembly Check List, Hardware Pack

    PRE-ASSEMBLY CHECK LIST HARDWARE PACK No. Description Identifier Q’ty Adjustment knob Allen Wrench Crossing Wrench Above hardware are all you need to assemble this machine. Before you start to assemble, please check the hardware pack to make sure they are included. Impex Inc.

  • Page 6: Assembly Instructions

    ASSEMBLY INSTRUCTION NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury. STEP 1 (See Diagram1) A). Pull the Safety-Pin (#11) from the Main Frame (#1). B.) Pull the upright frame and the seat post apart, and then insert back the Safety-Pin to securely lock the Main Frame in X-position.
  • Page 7 STEP 2 (See Diagram 2) A.) Remove the two Carriage Bolts (#8), Curved Washers (#9), and Dome Nuts (#10) from one of the Stabilizers (#2). B.) Attach the Front Stabilizer to the front of Main Frame (#1). Secure it with the two Carriage Bolts, Curved Washers, and Dome Nuts.
  • Page 8 STEP 3 (See Diagram 3) A.) Firmly thread the Left Pedal (marked “L) (#3) counterclockwise to the left crank. B.) Firmly thread the Right Pedal (marked “R” (#4) clockwise to the right crank. DIAGRAM 3 Impex Inc. www.impex-fitness.com...
  • Page 9 STEP 4 (See Diagram 4) A.) Remove the two Nylon Nuts (#13) and two Flat Washers (#14) under the Seat (#6). B.) Attach the Seat to the Seat Post (#5). Secure it with the two Nylon Nuts (#13) and two Flat Washers (#14). C.) Insert the Seat Post into the opening on Main Frame.
  • Page 10 STEP 5 (See Diagram 5) A.) Remove the four Allen Bolts (#15), four Spring Washers (#16), two Flat Washers (#17), and two Curved Washers (#18) from the Handlebar (#7). B.) Attach the Handlebar to the front post of Main Frame (#1). Secure it with two Allen Bolts (#15), two Spring Washers (#16), and two Flat Washers (#17) from the sides.
  • Page 11 STEP 6 (See Diagram 6) A.) Connect Sensor Wire (#20) from the front post of the Main Frame and connect to the Computer wire (#19) from Computer. DIAGRAM 6 Impex Inc. www.impex-fitness.com...

  • Page 12: Exploded Diagram

    EXPLODED DIAGRAM Impex Inc. www.impex-fitness.com...

  • Page 13: Parts List

    PARTS LIST KEY NO. DESCRIPTION QUANTITY Main frame Stabilizer Left pedal Right Pedal Seat post Seat Handlebar w/computer Carriage bolt Curve washer Domed nut Safety-pin Adjustment knob Nylon nut Flat washer Allen bolt Spring washer Flat washer Curved washer Computer wire Sensor wire Allen wrench Crossing wrench...

  • Page 14: Computer

    COMPUTER AUTO START / STOP When exercise starts, the monitor will automatically turn on and display the progress. When exercise stops, the monitor will automatically turn off after 5 minutes to save energy. Press “MODE” key, will automatically scan Time, Speed, Distance, Calories, and ODO for every 4 seconds.

  • Page 15: Exercise Instructions

    EXERCISE INSTRUCTIONS Using your FOLDABLE BIKE will provide you with several benefits, it will improve your physical fitness, tone muscle and in conjunction with calorie controlled diet help you lose weight. 1. The Warm Up Phase This stage helps get the blood flowing around the body and the muscles working properly.

  • Page 16: Weight Loss

    . The Cool Down Phase This stage is to let your Car dio-vascular System and muscles wind down. This is a repeat of the warm up exercise e.g. reduce your tempo, continue for approximately 5 minutes. The stretching exercises should now be repeated, again remembering not force or jerk your muscles into the stretch.

  • Page 17: Warranty

    ® IMPEX INC. LIMITED WARRANTY ® IMPEX Inc. ("IMPEX ") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase.
