  • Page 1 NOTE: Please read all instructions carefully before using this product Table of Contents Deluxe Upright Bike Safety Notice BF-6730A Hardware Pack Assembly Instruction Parts List Warranty Ordering Parts Model BF-6730A Retain This Manual for Reference 07-06-09 OWNER'S ® IMPEX INC.

  • Page 2: Table Of Contents

    EXPLODED DIAGRAM………………………………………………………………. PARTS LIST....................… WARRANTY....................…. ORDERING PARTS..................….. BEFORE YOU BEGIN Thank you for selecting the BODY FIT Deluxe Upright Bike BF-6730A by ® IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notice

    IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.

  • Page 4: Warning Label Placement

    WARNING LABEL PLACEMENT The Warning Label shown here has been placed on the Rear Stabilizer. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown.

  • Page 5: Hardware Pack

    HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

  • Page 6: Assembly Instruction

    ASSEMBLY INSTRUCTION NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury. STEP 1 (See Diagram1) A.) Do not tighten Nuts and Bolts until instructed to do so. B.) Attach the Front Stabilizer (#19) to the Main Frame (#42). Secure it with two M8 x 2 3/8” Carriage Bolts (#17), two 5/8”...
  • Page 7 STEP 2 (See Diagram 2) A.) Note: Extra help may be needed when installing the computer wires in Front Post (#12). B.) Attach the Front Post (#12) to the Main Frame (#42). Connect the Upper Computer Wire (#13) from the bottom of Front Post to the Lower Computer Wire (#14) from the main Fame. C.) Attach the Front Post to Main Frame.
  • Page 8 STEP 3 (See Diagram 3) A.) Remove the L-shaped Lock Bolt (#10) and Ø 5/8” Flat Washer (#11) from the handle holder bracket on Front Post (#12). Flip up the handle holder bracket. B.) Attach the Handle (#3) to Front Post, turn the Handle to desired hand holding position, and then flip down the handle holder bracket.
  • Page 9 STEP 4 (See Diagram 4) A.) Remove three Ø 5/8” Flat Zinc Washers (#55) and three M8 Aircraft Nuts (#54) from the Seat (#56). B.) Attach the Seat to the Seat Post (#53). Secure it with the three Ø 5/8” Flat Zinc Washers (#55), and three M8 Aircraft Nuts (#54).
  • Page 10 STEP 5 (See Diagram 5) A.) Thread the Left Pedal (#33L) counterclockwise onto the Crank (#41). B.) Thread the Right Pedal (#33R) clockwise onto the Crank on the other side. DIAGRAM 5...
  • Page 11 STEP 6 (see Diagram 6) A.) Connect the Pulse Sensor Wire (#6) to the Computer (#8). B.) Connect the Upper Computer Wire (#13) to the Computer. C.) Remove the four M5 x 3/8” Philips Screws (#9) from the Computer. Attach the Computer to the computer base on the Front Post (#12), secure the Computer to the Front Post with the four M5 x 3/8”...

  • Page 13: Parts List

    PARTS LIST KEY NO. DESCRIPTION QUANTITY Ø 7/8” Handle End Cap Handle Grip Handle Pulse Sensor ST4.2 x ¾” Philips Screw Pulse Sensor Wire Wire Sleeve Computer M5 x 3/8” Philips Screw L-shaped Lock Bolt Ø 5/8” Flat Washer Computer Post Upper Computer Wire Lower Computer Wire Ø...

  • Page 14: Limited Warranty

    ® IMPEX INC. LIMITED WARRANTY ® IMPEX Inc. ("IMPEX ") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser.
