Table of Contents
loading
Need help?

Need help?

Do you have a question about the MARCY PL-01012RP and is the answer not in the manual?

Questions and answers

Summary of Contents for Impex MARCY PL-01012RP

  • Page 1 Assembly Instruction Parts List Warranty Ordering Parts Model PL-01012RP Retain This Manual for Reference 08-29-02 OWNER'S MANUAL MARCY RECUMBENT BIKE PL-01012RP IMPEX FITNESS PRODUCTS 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com...
  • Page 2: Table Of Contents

    COMPUTER...…… WARRANTY...…. ORDERING PARTS...… BEFORE YOU BEGIN Thank you for selecting the MARCY Recumbent Bike PL-01012RP by IMPEX FITNESS PRODUCTS. manual carefully before using the machine. committed to provide you complete customer satisfaction. If you have any questions, or find there are missing or damaged parts, we guarantee you complete satisfaction through direct assistance from our factory.
  • Page 3: Important Safety Notices

    BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES RESPONSIBILITY SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram1) A.) Attach the Front Stabilizer (#10) to the Main Frame (#9). Secure it with two M10 x 3 1/8”...
  • Page 6 STEP 2 (See Diagram 2) A.) Connect the Upper Tension Connector (#6) from the Computer Post (#4) to the Lower Tension Connector (#7) from the Main Frame (#9). Slide the cable wire from the Upper Tension Connector (#6) in between the opening on the wire holder on the Lower Connector (#7).
  • Page 7: How To Connect Tension Connector

    HOW TO CONNECT TENSION CONNECTOR STEP 3 (See Diagram 3) Slide the Cable wire from the Upper Tension Connector in between the opening on the wire holder on the Lower Tension Connector. Pull the Upper Tension Connector upward and slide the wire through the slot on the bracket.
  • Page 8 A.) Attach the Seat Support (#28) to the Seat Post (#16). Secure it with five M8 x 5/8” Allen Bolts (#20) and B.) Attach the Handlebar (#25) to the Seat Support (#28). Secure it with two M8 x 2 ¾” Hex Bolts (#26), four STEP 4 (See Diagram 4) 5/8”...
  • Page 9 A.) Attach the Backrest Board (#29) to the Seat Support (#28). Secure it with four M8 x 5/8” Allen Bolts (#20). B.) Place the Seat Pad (#30) onto the Seat Support (#28). Secure it with two M8 x 5/8” Allen Bolts (#20).
  • Page 10: Exploded Diagram

    EXPLODED DIAGRAM...
  • Page 11: Parts List

    PARTS LIST KEY NO. DESCRIPTION Computer M5 x 3/8” Philips Screw Upper Sensor Wire Connector Computer Post Tension Adjustment Knob Upper Tension Connector Lower Tension Connector Lower Sensor Wire Connector Main Frame Front Stabilizer M10 x 3 1/8” Carriage Bolt M10 Acorn Nut 1”...
  • Page 12: Computer

    Maintenance and Storage 1. Inspect and tighten all parts each time you use the bike. Replace any worn parts immediately. 2. The bike can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. 3. Store the bike INDOOR. Excess moisture and water would cause rust on the frame.
  • Page 13: Functions And Operations

    FUNCTIONS AND OPERATIONS Function & Mode Scan Speed Distance Time Calorie Reset HOW TO INSTALL BATTERY 1. Pull off the battery cover and place two SIZE-AA batteries into the battery compartment on the back of the computer (See Diagram below). 2.
  • Page 14: Warranty

    No other warranty beyond that specifically set forth above is authorized by IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.

Table of Contents
