6 Viewing Information About the BM325

6.1 Viewing the Device Information

The device information includes the device type, software version number, hardware
version number, and device status.
The BM325 has three types of working status, including not connected to the network,
connecting to the network, and connected to the network. The three types of working
status are described as follows:
Not connected to the network: The device is about to set up a network connection.
Connecting to the network: The device is setting up a network connection.
Connected to the network: The device has set up a network connection.
Start the BWA Partner and click Device to view the device information.

6.2 Viewing the Network Information

The network information includes the connecting status of the BM325, uplink and
downlink rates, and link quality.
Start the BWA Partner and click Network to view the network information.

6.3 Viewing the IP Information

The IP information includes the IP address, default gateway, subnet mask, Dynamic Host
Configuration Protocol (DHCP) server address, and Domain Name Server (DNS)
address.
Start the BWA Partner and click Network.
Click IP Information to view the IP information.
Releasing the IP Address
Start the BWA Partner and click Network.
Click IP Release to release the IP address, and then click IP Information to check
whether the IP address is released.
Obtaining the IP Address
Start the BWA Partner and click Network.
Click IP Acquire to obtain the IP address, and then click IP Information to view the
obtained IP address.
