Summary of Contents for Huawei BM632
- Page 1 WiMAX CPE Quick Start...
- Page 3 Copyright © Huawei Technologies Co., Ltd. 2009. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors.
- Page 4 Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation.
-
Page 5: Table Of Contents
Safety Precautions ........ 1 Before you begin ........3 Getting to Know Your CPE ...... 3 Preparing for Installation ....... 7 Logging in to the Web UI ....... 9 Troubleshooting ........11 Specifications ........13... -
Page 6: Safety Precautions
Without prior written consent, no organization or individual is permitted to make any change to the structure or safety design of the device. Huawei Technologies Co., Ltd. is not liable to any consequences or legal issues due to such changes. - Page 7 20 cm from all persons. EU Regulatory Conformance � Huawei Technologies Co., Ltd., hereby, declares that the product complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. � The product is compliant with the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) Regulation (Regulation 1907/2006/EC).
-
Page 8: Before You Begin
Ethernet Cable Quick Start Qualification Card Getting to Know Your CPE The supported functions and actual appearance of the CPE may vary with the product you purchase. The following pictures are provided for illustration purpose only. Front Panel BM632/BM622/BM652 WiMAX –3–... - Page 9 BM631a The following table lists the meanings of the indicators and buttons on the front panel. Indicator Status Meaning WiMAX The indicators indicate the signal strength of the WiMAX network. When all the indicators are on, it indicates that the signal strength is at the highest level.
-
Page 10: Rear Panel
The telephone is on-hook or the TEL interface is disabled. Power The CPE is powered on. The CPE is powered off. Notes: WiMAX: Worldwide Interoperability for Microwave Access LAN: Local Area Network CPE: Customer Premises Equipment Rear Panel BM632/BM622/BM652 BM631a –5–... -
Page 11: Side Panel
The following table lists the functions of the ports on the rear panel. Port Description POWER The interface is used to connect to the output interface of the power adapter. The interfaces are used to connect a telephone line. The interfaces are used to connect the CPE to the computer. Side Panel RESET Button... -
Page 12: Preparing For Installation
Connecting Cables CAUTION During lightning weather, power off the CPE and disconnect it from the power supply. Do not touch the antenna. BM632/BM622/BM652 –7–... - Page 13 BM631a When the cables are connected correctly, the CPE will search for a WiMAX network automatically. After accessing the network successfully, the CPE can be used. Connecting the External Antenna (Optional) CAUTION • Do not use the external antenna outdoors. •...
-
Page 14: Logging In To The Web Ui
Connect the external antenna to the CPE. Put the external antenna in an open space without any obstacle surrounded, to ensure good reception of network signals. The schematic figure is only for your reference. The actual external antenna may differ. RESET External Antenna Logging in to the Web UI... - Page 15 and then press Enter. Enter the correct user name and password in the displayed Web-based utility, and then click the Login button. Both the initial user name and password are user. After the user name and the password are verified, you can perform operations on the Web-based utility.
-
Page 16: Troubleshooting
Troubleshooting The power indicator is not on. The WiMAX network cannot be found. • Check the power supply, ensuring that the power supply is properly • Ensure that the antenna is properly connected. connected. • Check whether the power adapter •... - Page 17 You cannot log in to the Web- The device or the power adapter based utility. overheats. • Check the power supply, ensuring • The device may get heated that the power supply is properly after being used for a long time. connected.
-
Page 18: Specifications
Specifications WiMAX Parameters Standard IEEE 802.16e-2005 3.4–3.62 GHz (BM632/BM631a) Frequency 2.496–2.69 GHz (BM622) 2.3–2.4 GHz (BM652) Multiple Access Method Orthogonal Frequency-Division Multiple Access (OFDMA) Duplex Mode Time-Division Duplex (TDD) Modulation QPSK, 16QAM, 64QAM (For downlink only) Data Rate Up to 15Mbps downlink, 5Mbps uplink... - Page 20 Huawei Technologies Co., Ltd. Huawei Industrial Base Bantian, Longgang Shenzhen 518129, People's Republic of China www.huawei.com Issue: 02(2009-09-05) Part Number: 00517891...
