Extech Instruments EX230 User Manual page 13

Function Range
Resistance 400 Ω
4 kΩ
40 kΩ
400 kΩ
4 MΩ
40 MΩ
Capacitance 40.00 nF
400.0 nF
4.000 µF
40.00 µF
100.0 µF
Note: Auto ranging; Input protection 600Vdc and AC rms
Frequency 5.000 Hz
50.00 Hz
500.0 Hz
5.000 kHz
50.00 kHz
500.0 kHz
5.000 MHz
10.00 MHz
Notes: Sensitivity: >0.5V rms (≤1MHz); >3V rms (>1MHZ);
Input protection: 600V dc or ac rms
Duty Cycle 0.1 to 99.9%
Notes: Pulse width: >100 µS <100ms; Frequency: 5Hz to150kHz;
Sensitivity: <0.5V rms; Overload protect: 600V dc or ac rms
Temperature
-4 to + 1400°F 0.1°F
-20 to +760°C 0.1°C
Sensor: Thermocouple type 'K'; Overload protection: 600V dc or ac rms
Temperature IR -20 to 0°C
0 to 93°C
93 to 230
-5 to 32°F
32 to 200°F
200 to 446°F
Resolution
0.1 Ω ±(0.8% reading + 5 digits)
0.001 kΩ
±(0.8% reading + 2 digits)
0.01 kΩ
0.1 kΩ
0.001 MΩ
±(2.5% reading + 8 digits)
0.01 MΩ
10 pF
0.1 nF
1 nF ±(5.0% reading + 7 digits)
10 nF
0.1 µF
0.001Hz
0.01 Hz
0.1 Hz
±(1.0% reading + 3 digits)
1 Hz
10 Hz
100Hz
1kHz ±(1.2% reading + 4 digits)
10kH
0.1% ±(1.2% reading + 2 digits)
±(3.0% reading +9°F)
±(3.0% reading + 5°C)
±(2.0%rdg or 2°C)
±(3.0%rdg or 3°C)
0.1°C/°F
13
Accuracy
±4°C
± 8°F
±(2.0%rdg or 4°F)
±(3.0%rdg or 6°F)
EX230-EU-EN-V1.2-09/10
