Technical Specifications

Scale Indicator
Input signal range:
Sensitivity:
Internal Resolution:
Display Resolution:
System Linearity:
Loadcell excitation Voltage:
Loadcell
Sensitivity:
Input Resistor:
Output Resistor:
Temperature
Operation:
Storage:
Humidity:
Power
Battery:
When the voltage of battery is below 5.7V, the "Low Bat" annunciator will be lighted, plug in AC adapter to charge
the battery. When "Lo.bAt" and actual weight is displayed alternately, this indicates the voltage of battery is below
5.5V and the scale will be turned off in two minutes automatically.
AC Adapter:
10.5-12V 600mA, with central positive, 5.7 VDC -9 VDC
DC

Error Messages

Error Message Definition
Weight above range for calibrated
0¯ ¯ ¯ ¯: zero point.
Weight below range for calibrated
zero point.
0_____:
Indicates an under range condition
_____:
Capacity exceeded
¯ ¯ ¯ ¯:
CAL-Er: Calibration error
Lo.bAt: Low Battery
EEP.E0 EEPROM can't be accessed
EEP.E1 Configuration settings have
changed and not been stored
EEP.E2 P7-P9 settings exceed scale's
normal range
0mV ～ +30mV
>0.2uV/grad
Approximately 520,000 counts
Can be selected between 500-100,000
Within 0.01% of FS
+5 V (MAX current: 85mA)
DC
0.3mV/V --- 3mV/V (must be fit to >0.2uV/display grad.)
≥60 Ω
<10 KΩ
o o
5 C - 35 C
o o
10 C - 70 C
≤95%RH (no condensation)
6V4AH lead acid battery, 30 hrs continuous use
Required
Solution/Troubleshooting
Remove load before zeroing
Or
Recalibrate the scale.
Remove load before zeroing
Or
Recalibrate the scale.
Remove all loads and zero the
scale.
Remove the load and try again. If
the load is great than 6 kg a scale
with a larger capacity is required.
Restart calibration
Recharge the battery. Upon initial
use, it is recommended to charge
battery for 8 hours prior to use.
Replace S100 Indicator
Calibrate the scale to store
settings
Reconfigure P7-P9 setting
