Salter Brecknell BS150 User And Service Manual

Portable bench scales
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
User and Service Manual
Salter Brecknell Weighing Products
Models BS150 and BS300
1000 Armstrong Drive
Portable Bench Scales
Fairmont, Minnesota 56031
Toll Free 800-637-0529 · Voice 507-238-8702 · Fax 507-238-8271
Email:
sales@salterbrecknell.com
INDICATOR (DP-10)
www.salterbrecknell.com
February 2004
©Copyright 2001, 2002 Salter Brecknell Weighing Products

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BS150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Salter Brecknell BS150

Summary of Contents for Salter Brecknell BS150

  • Page 1 Salter Brecknell Weighing Products Models BS150 and BS300 1000 Armstrong Drive Portable Bench Scales Fairmont, Minnesota 56031 Toll Free 800-637-0529 · Voice 507-238-8702 · Fax 507-238-8271 Email: sales@salterbrecknell.com INDICATOR (DP-10) www.salterbrecknell.com February 2004 ©Copyright 2001, 2002 Salter Brecknell Weighing Products...

  • Page 2: Operation

    Introduction: Model BS150 and BS250 are portable scales designed for today’s tough and demanding remote situations. Each scale comes with an internal, rechargeable battery that provides up to 8 hours of continuous operation (non-backlight, four hours with backlight on). A built in carry handle allows for easy transport of the scale to locations where AC power may not be present.
  • Page 3 Hold Used for larger items or unstable loads. Press the hold key, apply the load for 5 seconds and then remove the load. The display will hold the weight until the hold key is pressed again and the scale returns to normal operation.

  • Page 4: Indicator Features

    INDICATOR FEATURES: PIN ASSIGNMENTS FOR THE EXTERNAL CABLE: DP 10 1. Compact Dimensions: 11.3” X 3.5” X 2.7” (290 x 90 x 70 Pin 1: (+) Sig. (Green) Pin 1: (+) Sig. (Red) Pin 2: (+) Exc. (Red) Pin 2: (+) Ex. (Green) 2.
  • Page 5 11. Error message indication: CALIBRATION CALIBRATION CALIBRATION CAP. SPAN SPAN Overload WEIGHT WEIGHT RANGE RANGE 1000∼ 910∼ Power on zero count too low 0000 25 kg 50 lb. 5000 4100 100 kg 2000∼ 1820∼ Power on zero count too high 50 kg 100 lb.

  • Page 6: Key Descriptions

    CALIBRATION PROCEDURE KEY DESCRIPTIONS: 1. Press ON/ZERO/OFF key without releasing, and then press UNIT key 3 times to enter test mode, the display shows zero count (1000-6000). HOLD UNIT ZERO COUNT 2. Press ON/ZERO/OFF key and display shows “0”. 3. Load the calibration weight. (Note: Please see following table- UNIT: calibration weight): 1) Select weight units: kg, lb., or oz.

  • Page 7: Function Settings

    (next page) FUNCTION SETTINGS A.OFF Time for auto off (120s/180s/240s/300s/off). Unit Weight units (kg/lb./oz.). Capacity (3/6/15/30/60/150/300/600/1500/3000kg). Overload (100/150kg). divS Division (1/1500, 1/3000, 1/6000). Filt Filter (fast, normal, slow). CAL.C Calibration Capacity (1/4, 1/2, full). Hold Hold (Average Hold / Peak Hold). A.H.d.r.

  • Page 8: Outline Drawing

    Outline Drawing...
