- Page 1 Users Guide & Installation Handbook Belling SCGHU60GC / SCGHU70GC Built-in Gas Hobs UK 1.364 082761100 09/01/2013...
- Page 2 CONTENTS & INTRODUCTION CONTENTS WARRANTY • SAFETY Your new appliance comes with our • USING THE PRODUCT 12-month guarantee, protecting you against electrical and mechanical • CLEANING breakdown. To register your appliance please call 0844 481 0182, complete • INSTALLATION INSTRUCTIONS the registration form included or register •...
- Page 3 SAFETY WARNING! - switch off the appliance This appliance and its and then cover flame accessible parts may e.g. with a lid or fire become hot during use. blanket. To avoid burns, children WARNING! - Metallic less than 8 years of age objects such as knives, shall be kept away unless forks, spoons and lids...
- Page 4 SAFETY General edge of the hob. If pans are knocked they may move on the hob top. Servicing should be carried out only by Fire Safety Advice authorised personnel. Most kitchen fires occur when people are Do not spray aerosols in the vicinity of distracted or leave things unattended, so this appliance while it is in operation.
-
Page 5: Packaging Material
SAFETY Avoiding damage to the appliance. DISPOSAL Objects that melt and things that boil Packaging Material over can burn onto the hob and should be The packaging materials used with this removed as soon as possible. appliance can be recycled. To avoid damage to cookware do not al- Please dispose of the packaging materials low sauce pans or frying pans to boil dry. - Page 6 USING THE HOB - GAS • If your hob is supplied with left and • To simmer, turn the control knob right handed pan supports, ensure to the small flame symbol. This will that they are located over the align- ensure that the flame is just large ment pins and are sitting flat on the enough to gently heat the contents of...
- Page 7 USING THE HOB - GAS FOLD DOWN LID (IF FITTED) WOK RING (IF SUPPLIED) Caution: Glass lids may shatter when The wok ring should only be used heated. Turn off all the burners before with a wok. No other style of pan is shutting the lid.
- Page 8 CLEANING General • Some foods are corrosive eg; vinegar, fruit juices and especially salt - they • It is important to clean the product can mark or damage the metal if they regularly as a build up of fat can af- are left on the surface.
- Page 9 CLEANING GAS HOB Cast iron griddle or pan supports (if fitted) Burner caps and heads • Ensure the griddle has fully cooled • The slots in the burner head where and scrape off any stubborn marks the flames burn should be cleared of and bits of food with a plastic or deposits.
- Page 10 INSTALLATION Installation In the UK the regulations and standards are as follows (inclusive This appliance must be installed in of successive issues: accordance with the regulations in 1. Gas Safety Regulations force, and only in a well ventilated (Installation and Use). space.
-
Page 11: Ventilation Requirements
INSTALLATION Ventilation Requirements The room containing the appliance should have an air supply in accordance with BS5440: Part 2 • All rooms require an openable window, or equivalent, and some rooms will require a permanent vent as well. • For room volumes up to 5m3 an air vent of 100cm2 is required. - Page 12 INSTALLATION Clearances & dimensions The room should have good light and We recommend ceramic tiling for the ventilation but be free from draughts. rear wall directly behind the hob. The worktop should be at least No shelf or overhang of combustible 600mm deep, &...
-
Page 13: Important Information
INSTALLATION Important Information It is important when installing front control gas hobs, that the work top cut out is the same as is quoted in this installation manual. If the cut out is too large, then batons must be fitted to the front, rear and sides - to correct the discrepancy and ensure the correct fit. - Page 14 INSTALLATION Fit the hob into the cutout & the base of the hob may interfere with secure to worktop the sides of these units. It will be neces- sary Place the hob into the cutout and to cut away the top of the unit secure in place using the four brackets sides locally to clear the hob, clamp and screws provided.
- Page 15 INSTALLATION Alternative clamp positions If the front and rear clamp positions are problematic, alternative positions can be used on the sides of the hob, dependant on the particular installation. These positions will require clearance from any cabinet sides and may effect how tightly the hob will meet the worktop.
- Page 16 INSTALLATION Connect gas hob to gas supply Make sure the appliance is gas sound & all components are The inlet is at the rear RHS of the hob. operating correctly. The hob may be connected to the gas supply either by rigid pipework or flexible Connect to the electricity supply connection.
- Page 17 INSTALLATION Connect to the electricity supply be connected to the terminal marked L For hobs that are supplied/manufactured (Live), or coloured Red. with a 13Amp supply cord and plug only. The plug and socket must be accessible Warning: Ensure that the power rating of after installation.
-
Page 18: Troubleshooting
INSTALLATION Troubleshooting Before you call Customer Care, please check the following points: Burner fails to ignite: • Check the electricity supply is on. • Check the fuse. There is a spark to the burner but it fails to ignite: • Check that the flame holes in the flame spreader are clear of water or deposits. -
Page 19: Technical Data
TECHNICAL DATA This information is for the following Appliance Class appliances: Class 3 Bulit-In Hotplate Belling Hobs SCGHU60GC / SCGHU70GC Gas pressure settings - NG only G20 Natural Gas @ 20 mbar Data badge Underside of the hob base Countries of destination... -
Page 20: Customer Care
CUSTOMER CARE CUSTOMER CARE WEB SHOP range of Bake ware and Cookware essen- tials including Roasting Pans, Cake Tins Having purchased a superior cooker, hob and Non-Stick Cooking Liners. or hood from us, you’ll naturally want to keep it looking great. And who better to For all enquires, please visit our Web Shop at www.gdhaonline.co.uk or help you care for it than the manufac-... - Page 21 Please keep this handbook for future reference, or for anyone else who may use the appliance.
- Page 22 Please keep this handbook for future reference, or for anyone else who may use the appliance.
- Page 23 Please keep this handbook for future reference, or for anyone else who may use the appliance.
- Page 24 CUSTOMER CARE To contact Belling about your appliance, please call Warranty Registration 0844 481 0182 to register your appliance Customer Care Helpline 0844 815 3746 in case of difficulty within the UK Alternatively general, spares and service information is available from our website at www.belling.co.uk...
