Xerox WorkCentre 7232 Specifications

Color multifunction printer
Hide thumbs

Advertisement

WorkCentre
Color

Multifunction Printer

Output Speed – Printing and Copying
Black and white
Color
First-Image-Out Time
Black and white
Color
Print Specifications
System
Memory
System Disk
Network Printing – Network Controller
Processor
Printer Languages
(auto sensing/switching)
Network Printing – Resolution
7232 / 7242
®
WorkCentre 7232
shown with the Two Tray option.
WorkCentre 7232
Up to 32 ppm (pages per minute) 8.5 x 11 in. (A4/210 x
297 mm) LEF
Up to 16 ppm 8.5 x 14 in. (216 x 356 mm)
Up to 16 ppm 11 x 17 in. (A3/297 x 420 mm)
Up to 10 ppm 8.5 x 11 in. (A4/210 x 297 mm)
Up to 5 ppm 8.5 x 14 in. (216 x 356 mm)
Up to 5 ppm 11 x 17 in. (A3/297 x 420 mm)
As fast as 14 seconds
As fast as 23 seconds
1.2 GB
40 GB
667 MHz
Adobe
Postscript
3™ (optional)
®
®
TIFF
PCL
5c
®
PDF 1.5
PCL
6
®
HP-GL2™
XPS
®
600 x 600 x 4 dpi (achieves 1200 dpi with resolution enhancement)
WorkCentre 7242
shown with the Office Finisher LX.
WorkCentre 7242
Up to 40 ppm 8.5 x 11 in. (A4/210 x 297 mm) LEF
Up to 20 ppm 8.5 x 14 in. (216 x 356 mm)
Up to 20 ppm 11 x 17 in. (A3/297 x 420 mm)
Up to 10 ppm 8.5 x 11 in. (A4/210 x 297 mm)
Up to 5 ppm 8.5 x 14 in. (216 x 356 mm)
Up to 5 ppm 11 x 17 in. (A3/297 x 420 mm)
Detailed Specifications
1

Advertisement

loading

  Related Manuals for Xerox WorkCentre 7232

  Summary of Contents for Xerox WorkCentre 7232

  • Page 1: Multifunction Printer

    WorkCentre 7232 / 7242 ® Color Multifunction Printer WorkCentre 7232 WorkCentre 7242 shown with the Two Tray option. shown with the Office Finisher LX. WorkCentre 7232 WorkCentre 7242 Output Speed – Printing and Copying Black and white Up to 32 ppm (pages per minute) 8.5 x 11 in. (A4/210 x Up to 40 ppm 8.5 x 11 in.
  • Page 2 WorkCentre 7232 / 7242 Network Printing – Printing Features Features Print Calibration Secure print Delay print (specific time) Sample set Booklet creation Cover selection Paper selection by attribute N-up Watermark Fit to new paper size Transparency separators Banner sheet enable/disable...
  • Page 3 Tivoli NetView ® ® • Provides the ability to see the discovered Xerox printers/devices in a Xerox Printers Set in addition to the Printers SmartSet • Provides full integration with the NetView and Event Browser and Tivoli Enterprise Console (TEC)
  • Page 4 Provides built-in process intelligence that allows the printing of barcodes on any appropriately configured Barcode Utility (Optional) PostScript printer on the SAP R/3 4.x (or higher) network. Used in conjunction with Xerox Device Types for SAP R/3 Purchase via Type House Environment and Xerox Font Center Barcode Fonts.
  • Page 5 • ScanSoft OmniPage (for desktop/client installation) – OCR and file format conversion software • Image Retriever – provides fully automated retrieval of scanned images direct from a scan enabled Xerox WorkCentre to individual desktops. Scan to PC Desktop Pro •...
  • Page 6 Finisher output tray selection (top tray or main tray) Secure print on/off Fax Vendors Multiple vendors, certified by the Xerox Alliance Partners Program For details, visit www.xerox.com Fax (Optional) – Standard with One or Three Line Fax Option ITY (CCITT) group 3 quality/resolution superfine/600x600, super fine/400 x 400, fine/200x200, standard/200x100 dpi Speed/Modem(s) V.34 modem(s): 33,600 bps.
  • Page 7 WorkCentre 7232 / 7242 Fax Receive Mailboxes Up to 200 password-protected mailboxes Auto Dialing Auto redial, Batch send Single Line option Total of 200 speed dials (single-line option) Up to 200 dial groups with up to 200 recipients per group (single line option)
  • Page 8 ID Card Copy Foreign Device Interface Interface to third-party access control devices, coin machines and card readers Supports a variety of vending stations available through the Xerox Custom Application Service Device Specifications Paper Handling – Duplex Automatic Document Feeder Capacity...
  • Page 9 WorkCentre 7232 / 7242 Weights 17 lb bond to 80 lb Cover/64 to 216 gsm Types Plain Paper Recycled Bond Custom Type 1 through 5 Lightweight Heavyweight Extra Heavyweight Transparency Heavyweight Gloss Labels Gloss Extra Heavyweight Gloss Punched Letterhead Pre-printed Envelopes Paper Handling –...
  • Page 10 WorkCentre 7232 / 7242 Types Plain Paper Recycled Bond Custom Type 1 through 5 Lightweight Heavyweight Extra Heavyweight Transparency Heavyweight Gloss Labels Gloss Extra Heavyweight Gloss Punched Letterhead Pre-printed Envelopes Total Capacity* 2,720 sheets (Includes Tray 1, Tray 2, Tray 3 and Bypass Tray) Paper Handling –...
  • Page 11 WorkCentre 7232 / 7242 Output – Optional Booklet Maker (Score/Crease, Saddle-stitch Staple) Capacity 40 booklets (1-15 sheets per booklet – 80 gsm or less; 2-10 sheets per booklet – over 80 gsm) Sizes Letter – 8.5 x 11 in. (A4/210 x 297 mm) Legal –...
  • Page 12 WorkCentre 7232 / 7242 Accessories Office Finisher LX Integrated Office Finisher One-line fax option Three-line fax option Foreign Device Interface Network Accounting Enablement Scan to Email with Scan to Mailbox Scan Performance Kit Network Scanning With Email PostScript Kit Fax Server Kit...
  • Page 13 , CentreWare ® , Copier Assistant and the sphere of connectivity design are trademarks of Xeox Corporation. In support of Xerox’s environmental leadership goals, these models may contain some recycled components that are reconditioned. ENERGY STAR is a U.S. registered mark. As an ENERGY STAR Partner, Xerox Corporation has determined that these products meet the ®...
