- Page 1 EA-650 Platinum POWER SUPPLY USER’S MANUAL V1.1...
- Page 2 By using the EA-650 Platinum, you can reduce your electricity bill up to 25%. A 3 year Antec Quality warranty, a whisper-quiet 120mm DBB fan controlled by Antec’s renowned Thermal Manager and CircuitShield™’s industry-leading 8 levels of protection make the EA-650 Platinum one of the best choices available.
- Page 3 PLUS® certified power supply uses less energy and generates less heat to stay cooler, run quieter and last longer. The EA-650 Platinum has been 80 PLUS® PLATINUM certified to be at least 89% efficient at a wide range of operating loads; this will lower your operating costs and help protect the environment.
- Page 4 TABLE 2 Cable Quantity Connectors +12V Rail Description +12V3 24-pin Motherboard +12V2 8(4+4)-pin ATX12V/EPS12V +12V4 8(6+2)-pin PCI-E +12V1 SATA +12V1 Molex + FDD +12V1 SATA + Molex...
- Page 5 INSTALLATION Install the PSU into either the top or bottom of your case with the four screws provided. Refer to your case manual if you are unsure where the power supply should be installed. Connect the 24-pin main power connector to your motherboard. Connect the 8-pin or 4+4-pin connector for the CPU.
- Page 6 Connect the AC power cord to the power supply AC inlet. Be sure to use the heavy-duty cord supplied with your PSU. PCI-E graphics cards use different amounts of power. For some, a single 6-pin connector is sufficient, making the hardwired connector the preferred choice. More powerful cards use multiple connectors, including the advanced 8-pin PCI-E connector.
-
Page 7: Technical Support
Tel: 510-770-1200 - Fax: 510-770-1288 www.antec.com ©2013 Antec, Inc. All rights reserved. Specifications are subject to change without prior notice. Actual product(s) and accessories may differ from illustrations. Omissions and printing errors excepted. Content of delivery might differ in different countries or areas. Some trademarks may be claimed as the property of others.
