LCD2681FHD
LCD TV
" For Optimum picture and sound quality,
please use TEAC Audio/Video cables "
TEAC High Performance Audio/Video cables and connectors have
been designed to enhance your home entertainment experience.
USER MANUAL
IMPORTANT !
WARRANTY INFORMATION INSIDE. PLEASE READ
www.teac.com.au
Trademark of TEAC Corporation JAPAN
Advertisement
Table of Contents
Related Manuals for Teac LCD2681FHD
Summary of Contents for Teac LCD2681FHD
- Page 1 LCD2681FHD LCD TV “ For Optimum picture and sound quality, please use TEAC Audio/Video cables ” TEAC High Performance Audio/Video cables and connectors have been designed to enhance your home entertainment experience. USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au...
- Page 2 Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service. If you require Warranty Service, please contact the TEAC Customer Support Hotline at 1300 553 315 for assistance. Please ensure that you have the model number, serial number and purchase receipt ready when you call.
- Page 3 Authorised Service Centre for repair. In this event, proof of purchase is required to support a warranty claim. After the repair, the product will be available for collection by or return to the purchaser at a fee upon request. TEAC in- home service can be made available at a fee upon request.
-
Page 4: Table Of Contents
Contents Contents Safety Precautions Power Supply..............................1 Installation................................. 2 Use and Maintenance............................3 Important Safety Instructions ..........................4-5 User Guidance Information Accessories / Wall Mounting Information ......................6 Names of each part(Front View) ........................7 Names of each part(Back View) ........................8 Remote control .............................. -
Page 5: Safety Precautions
Safety Precautions Power Supply DO NOT plug several devices DO NOT touch the power DO NOT use a damaged Insert the power plug fully into into the same outlet. plug with wet hands. power cord or plug or a the outlet. loose outlet. -
Page 6: Installation
Safety Precautions Installation DO NOT place the unit on an unstable DO NOT place containers with DO NOT place the unit where DO NOT use or store flammable surface, such as a sloped table, or any liquids such as flower vases, soft it is exposed to rain, excessive or combustible materials near stand with a contact area smaller than... -
Page 7: Use And Maintenance
Safety Precautions Use and Maintenance Although the LCD screen is made with high-precision technology and 99.99% or more of the pixels are effective, black dots may appear or bright points of light (red, blue, or green) may appear constantly on the LCD screen. This is a property of the LCD screen and is not a malfunction. -
Page 8: Important Safety Instructions
Safety Precautions Important Safety Instructions power socket. Do not bend the power cord excessively, prevent the cord from being walked on or pinched by weights placed on it. -
Page 9: Important Safety Instructions
Caution: Use of any controls, adjustments, or procedures other than those specified herein may Important Safety Instructions result in hazardous radiation exposure. Servicing of this unit should be conducted by qualified and certified TEAC service personnel. The manufacturer will not be held responsible for any damage caused by any modifications done on the product without authorisation from the manufacturer’s... -
Page 10: User Guidance Information
User Guidance Information Accessories 2 x AAA Battery Remote Control User’s Guide Mains cable Wall Mounting Information Stand and wall-mounted (optional) Your LCD TV is able to accommodate wall mounting with the use of a wall mount bracket (not supplied with LCD TV, please contact your local hardware store) and the mounting hole screw size (M4X10) on the back of the unit. -
Page 11: Names Of Each Part(Front View)
User Guidance Information Names of each part Front View INPUT: Display the input source menu. MENU: Display/exit the OSD menu. CH+/-: Scan through channels. VOL+/-: Adjust the volume. POWER: Turn on/standby the TV set. -
Page 12: Names Of Each Part(Back View)
User Guidance Information Names of each part Back View Name Function Description SWITCH Turn on/off the power supply AC POWER IN Connect to power supply Connect to USB device for multimedia HDMI1/2/3 Connect to the HDMI socket of your DVD or Satellite Box Connect to the PC VGA output to display PC graphics PC audio in PC audio input... -
Page 13: Remote Control
User Guidance Information Remote Control (POWER) : Turn the TV on/standby. DTV/USB INPUT AUDIO MUTE DTV/USB: Switch to DTV/USB. INPUT : Display the input source menu. PICTURE SOUND SLEEP ASPECT AUDIO : Select different audio languages, subject to availability from broadcaster. MUTE: Press to mute the sound, press again or press VOL+ to unmute. -
Page 14: Remote Control
User Guidance Information Remote Control AUDIO MUTE DTV/USB INPUT PICTURE SOUND SLEEP ASPECT Buttons for USB operation: (REC): Press to start record the program in DTV mode. : No function. : Stop program. : Previous chapter. : Next chapter. : Play/Pause program. : Fast reverse. -
Page 15: Basic Operation
Basic Operation Basic Operation The following section conveys the unit’s general operation, such as, switching the unit on, selecting the input source, and using the automated channel search command. Switching the unit on The following steps are a guide to switch the unit on: 1. - Page 16 Basic Operation Basic Operation Using the On Screen Display Menu The On Screen Display (OSD) menu acts as the Main Menu and aids the user in browsing through the different options/properties available on the television unit. Press the MENU button on the remote control to access the OSD menu as shown below: Main menu CHANNEL PICTURE...
-
Page 17: Osd Menu
OSD Menu OSD Menu 1. CHANNEL Menu This menu selection contains scanning preferences (either automatic or manual tuning), Program Edit options, Signal Information, Recording options, Recording lists and Recording files. Settings can be altered for individual channels. Record Start Description Press MENU button once to enter CHANNEL setup menu as shown above. - Page 18 OSD Menu OSD Menu DTV Manual Tuning Press OK button to enter the DTV Manual Tuning menu. Select a DTV channel, and press OK button to start searching. ATV Manual Tuning Press OK button to enter the ATV Manual Tuning menu.
- Page 19 Your device attached will be required to be formatted before any recording is done. NOTE: Formatting will erase any existing data on the device. Back up all existing data before formatting. TEAC accepts no responsibility for any loss of data.
-
Page 20: Picture Menu
OSD Menu OSD Menu 2. PICTURE menu Picture display settings can be altered, according to the users desired settings. The following options are available for adjustments: Description Picture Mode: There are four preset settings to choose from, Standard, Dynamic, User and Mild. Note: Contrast, Brightness, Colour and sharpness can only be adjusted in User mode option from the Picture Mode Settings. -
Page 21: Sound Menu
OSD Menu OSD Menu 3. SOUND menu General sound settings can be adjusted according to the user’s personal preference with the following options: SPDIF MODE Description Sound Mode: There are five preset settings to choose from, Standard, Music, Movie, Sports and User. -
Page 22: Timer Menu
OSD Menu OSD Menu 4. TIME menu This option allows the user to change the time settings of the unit. Description Clock: Use the buttons to select the position, and buttons to set the time. NOTE : User cannot change the time manually in DTV mode because the program is synchronised with the broadcast signals received. -
Page 23: Option Menu
OSD Menu OSD Menu 5. OPTION menu The option settings allow the user to make alterations to the language settings. OSD Duration Blue Screen Country Australia Description OSD Menu Language: Allows the user to select the language option for the OSD menu. Audio Language 1st/2nd (can be selected in DTV mode): Allows you to select first and second audio language. -
Page 24: Lock Menu
OSD Menu OSD Menu 6. LOCK menu This option allows parents to block channels and programs using a password. NOTE: The default password is 0000. In case the user has forgotten the password, the master Password is 8899. Please take note of this. Lock Channel Program Guide No Lock... -
Page 25: Multimedia Operation
Multimedia Operation Multimedia Operation Basic Operation 1). Press the INPUT button on the remote control to display the input source menu, select USB source by the buttons, and press OK button to enter the Multimedia menu as illustrated below. Input Source Move Select Quit... - Page 26 Multimedia Operation Multimedia Operation To access photo, audio, video, or text files from an external drive. The right input has to be accessed by selecting from a range of choices by pressing the INPUT button. 1. Photo To display photos, select files from the folder and press play to view in full screen. The image should appear on screen as illustrated below.
- Page 27 Multimedia Operation Multimedia Operation Press button to select the option on the table, and press OK button to change. Press button search for music, and press OK button to select. Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None. Goto Time: Start playing music from your desired time.
- Page 28 Multimedia Operation Multimedia Operation Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None. Set A-B: Select and play the preferable frame of the program in a loop, by setting A and B at the beginning and end, and there will be a sign on the left of the screen, press OK button again to cancel. Playlist: Display the playlist on the screen.
-
Page 29: Multimedia Operation
Multimedia Operation Multimedia Operation Supporting Format MOVIE The max bit rate is 6Mbps The max resolution is 720*576P (AVI) Supported mono colour 16colour 256colour 16bit 24bit; 32bit The max resolution is PHOTO 3000*3000 the min resolution is 100*100 Sample rate 8K-48K Bit rate 32K-320K MUSIC Special Note 1 The media unit can only support USB memory devices, such as hard disks and flash drives, and will not support... -
Page 30: Recording Operation
Recording Operation Recording Operation Digital Video Recording (DVR) settings (In DTV Mode only) The DVR function allows this unit to record live digital TV (DTV) programs, allowing for viewing on demand at any time. This function supports recording, timeshift and playback function as explained here. - Page 31 Recording Operation Recording Operation Digital Video Recording (DVR) File System Attach a compatible USB device to the back panel of the unit. From the CHANNEL menu, enter the DVR File System to access recording options. NOTE: NOT all USB devices, such as phones, MP3 players, cameras, and the like, are compatible with recording files.
- Page 32 Recording Operation Recording Operation Check DVR File System Press ‘OK’ button to check if your USB device is ready and compatible for DVR functions. If the USB device is formatted and compatible with the unit, it will display a ‘SUCCESS’ prompt, if the device is not compatible, it will display ‘FAIL’.
- Page 33 Recording Operation Recording Operation Signal Information Record Start Recorded List Recorded Mode Schedule List Free Record Limit 1Hr. DVR File System 1) Free Record Limit Select recording time from 1 hour to 6 hours. Note 1- This is only apply for manual (instant) recording. 2- record will stopped once it reaches the maximum set time.
- Page 34 Recording Operation Recording Operation RECORDING IN STANDBY MODE - This unit is able to do recording while in sleep mode. - Start a recording, then press the power button. above - A pop up message as shown will be displayed. Select "Turn off the screen, and continue recording".
- Page 35 Recording Operation Recording Operation Electronic Program Guide (EPG) Press the EPG button to display the OSD menu as below: Press Index button then press </> button to choose list type. Details information Curr nt channel of selected press </> change program.
-
Page 36: Recording Operation
Recording Operation Recording Operation The Schedule List can be viewed by accessing it through the OSD menu. by pressing the MENU button on the remote control. NOTE: • Unit will only record one program at a time. If a recording is done with conflicting start and end times, it will not register onto the schedule list. -
Page 37: Maintenance And Service
Maintenance and Service Trouble shooting Do not use other functions that are not mentioned in this user’s manual. In case a problem occurs with your LCD TV, please take the following steps first. If you still have the problem, turn the power off and contact your dealer or an authorized service center. Action Problem Is the power plugged in? Insert the power plug. -
Page 38: Specifications
Maintenance and Service Specifications LCD Panel Panel Size Max. Resolution VIDEO Input Connector YPbPr AUDIO (L/R) PC/AUDIO HDMI 3 The HDMI support 1.3, the HDCP support 1.1) Output Connector HEADPHONE COAX 100-240V 50/60Hz Power Source 100W Power Consumption Standby Power Consumption <1W Contrast Ratio 800:1... - Page 39 Maintenance and Service Specifications Supporting Format MOVIE The max bit rate is 6Mbps The max resolution is 720*576P (AVI) Supported mono color 16color 256color 16bit 24bit; 32bit The max resolution is PHOTO 3000*3000 the min resolution is 100*100 MUSIC Sample rate 8K-48K Bit rate 32K-320K...
