- Page 1 32 5H Product Image to be inserted USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ Trademark of TEAC Corporation JAPAN www.teac.com.au...
- Page 2 Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service. If you require Warranty Service, please contact the TEAC Customer Support Hotline at 1300 553 315 for assistance. Please ensure that you have the model number, serial number and purchase receipt ready when you call.
-
Page 4: Table Of Contents
Table Of Contents Important Safety Instructions ............................. 2 Supplied Accessories ..............................4 View of Unit .................................. 5 Right Side Panel......................................5 Left Side Panel......................................6 Rear Panel ........................................7 Front Panel........................................8 Special Feature of DVD Module ..........................9 Disc Information.................................10 Remote Control ................................11 Remote Control Drawing ..................................11 Preparation of Remote Control................................14... -
Page 5: Important Safety Instructions
Important Safety Instructions This symbol indicates that dangerous voltage instituting a risk of electric shock is present within this unit. This symbol indicates that there are important operation and maintenance instructions in the literature accompanying the appliance. Caution: Laser radiation when open. Do not stare into beam. - Page 6 Important Safety Instructions Read these instructions. IMPORTANT FOR LASER PRODUCTS Keep these instructions. 1. CLASS 1 LASER PRODUCT Heed all warnings. 2. DANGER: Visible laser radiation when open and Follow all instructions. interlock failed or defeated. Avoid direct exposure to Do not use near water.
-
Page 7: Supplied Accessories
Supplied Accessories Make sure that the following accessories are provide with the product. ITEM NAME Remote Control Batteries for Remote Control Power Supply Cord AV Cables User Manual Note: Accessories and their numbers are subject to modification without prior notice. -
Page 8: View Of Unit
View of Unit Right Side Panel 1. INPUT button Press to select enter the source selecting menu, press the ▲▼ direction buttons to select desired mode and press the ENTER button to enter the selected mode. In system setup menu, this button also serves as the ENTER button. 2. -
Page 9: Left Side Panel
View of Unit Left Side Panel EJECT button Press to eject the disc from the unit. 7. ■ STOP button Press to stop disc playback in DVD mode. PLAY/PAUSE button Press to start disc playback and press it again to pause playback in DVD mode . 9. -
Page 10: Rear Panel
View of Unit Rear Panel... -
Page 11: Front Panel
View of Unit 1. HDMI 1, HDMI 2 and HDMI 3 Input Jacks 7. S-VIDEO Input Jack Connect the HDMI signal source. Connect Composite signal source in S-Video 2. UPGRADE PORT mode. Connect the USB device only for upgrading 8. AV2 and L/R Audio Input Jacks the TV software. -
Page 12: Special Feature Of Dvd Module
Special Feature of DVD Module Your TV comes equipped with a removable DVD module. Please follow the procedures below to remove or install the DVD module. Note: Before removing or installing the DVD module, ensure that the television is unplugged and turned off. DVD module removal: Refer to the illustration below and follow the procedures below to remove the DVD module from the unit:... -
Page 13: Disc Information
Disc Information Discs Supported DISC LOGO CONTENTS SIZE MAXIMUM TIME 133min(SS-SL) 242min(SS-DL) Audio + Video 12cm (active picture) 266min(DS-SL) 484min(DS-DL) Audio 12cm 74min JPEG Still high resolution 12cm Audio + Video 12cm The operating method of some DVD discs is specified by the software maker. Please refer to the instruction manual of the disc. -
Page 14: Remote Control
Remote Control Remote Control Drawing 3. ATV button Press to select ATV mode. 4. SOUND button Press to select the screen picture mode: choose from Standard, User, Sports, Movie or Music. 5. TV.RADIO button Press to select DTV program playback or Radio program playback in DTV mode. - Page 15 Remote Control 15. ► PLAY button In Channel Edit menu, press this button to set Press to play a disc in DVD mode. a favorite channel (see P25 for details). PAUSE button 23. CH.LIST button In DVD mode, press to pause playback and Press to display the channel list.
- Page 16 Remote Control Remote Control Drawing 35. REPEAT button Press to repeat a chapter, track, title or all program content in DVD mode. In teletext mode, press to hold the current page and press again to resume. 36. TITLE button During disc normal playback, press to go to display the title menu.
-
Page 17: Preparation Of Remote Control
Remote Control Preparation of Remote Control Using of Remote control Softly push the back cover to open the battery Point the remote control unit from no more than compartment. about 7 meters from the remote control sensor and within about 60 degrees of the front of the unit. -
Page 18: System Connections
System Connections Do not connect the power cord until all other connections have been made. Ensure that you observe the color code when connecting audio and video cables. Connecting to the Power Supply Connect one end of the power sully cord to the power jack on the rear panel of the unit and the other end to the wall AC outlet, see the figure below. -
Page 19: Connecting To An External Av Signal Source (Av1/S-Video)
System Connections Connecting to an External AV Signal Source (AV1/S-Video) Use the AV cables to connect the external AV signal source to the AV input jacks on the rear panel of the unit. Use a S-VIDEO cable (not supplied) to connect the external AV signal source to the S-VIDEO input jack on the rear panel of the unit. -
Page 20: Connecting To An External Av Signal Source (Av2)
System Connections Connecting to an External AV Signal Source (AV2) Use the AV cables to connect the external AV signal source to the AV input jacks on the rear panel of the unit. After connection, turn on the power of the unit and the external AV signal source. Press INPUT then direction buttons to select Composite 2 mode, and then press the ENTER button to confirm. -
Page 21: Connecting To An External Av Signal Source (Ypbpr)
System Connections Connecting to an External AV Signal Source (YPbPr) Use AV cables to connect an external AV signal source to the Y/Pb /Pr (Component) input jacks on the rear panel of the unit. After connection, turn on the power of the unit and the external AV signal source. Press INPUT then direction buttons to select Component mode, and then press the ENTER button to confirm. -
Page 22: Connecting To An External Av Signal Source (Hdmi)
System Connections Connecting to an External AV Signal Source (HDMI) Follow the figure below to connect an HDMI signal source to one of the HDMI jacks on the rear panel of the unit. After connection, turn on the power of the unit and the external AV signal source. Press INPUT then direction buttons to select HDMI 1, HDMI 2 or HDMI 3 mode, and then press the ENTER button to confirm. -
Page 23: Connecting To An External Signal Source (Av Output)
System Connections Connecting to an External Signal Source (AV Output) Use the AV cables to connect the external AV input device to the AV output jacks on the rear panel of the unit. After connection, turn on the power of the unit and the external AV signal source. Press INPUT then direction buttons to select the corresponding mode, and then press the ENTER button to confirm. -
Page 24: Connecting A Coaxial Digital Output
System Connections Connecting a Coaxial Digital Output This unit is designed with a coaxial digital audio jack, can be connected to the digital amplifier, see the figure below: This feature is available only for amplifiers equipped with coaxial digital audio input connectors. -
Page 25: Connecting To A Pc
System Connections Connecting to a PC Follow the steps and figure below to connect a PC to the unit. Connect one end of the VGA cable to the VGA IN jack on the jack panel of the unit and the other end to the PC VGA output. -
Page 26: Connecting A Usb Device For Upgrading
System Connections Connecting a USB Device for Upgrading This unit is designed with a USB upgrade port, can be connected to the USB device for upgrading the software, see the figure below: Make sure that Software file for upgrade is stored in the USB device before connection. -
Page 27: Input Source Selecting
Input Source Selecting The unit incorporates multiple video modes which can be selected via the INPUT button on the unit or remote control. Press the INPUT button to enter Input Source menu. The screen will display as shown below: NOTE: In this menu, “TV” stands for “ATV” mode. Use the ▲▼... -
Page 28: Tv Function
TV Function Preparations After connection, press the POWER button to turn on the unit. Press the INPUT button to select TV mode and you can then conduct the following operations: Note: In other mode, you can refer to the following instructions in TV mode to go on with some settings. -
Page 29: Channel Setting
TV Function If you did not use the unit for the first time or if your setup has changed, you can setup the unit from Channel Setup menu. Please follow the instructions below: Channel Setting Press the MENU button once to enter CHANNEL setup menu as shown on the right. - Page 30 TV Function DTV Manual Tuning Press the ▲▼ button to select DTV Manual Tuning and press the ENTER or ►button, the screen will display as shown on the right: Press the ◄► button to select desired channel number and press the ENTER button to start tuning.
-
Page 31: Picture Setting
TV Function Rename a channel: (this function is only available for ATV channels) Press the ▲▼ button to select a channel you want to rename and press the green button to set a ” on the channel. Press the ◄► button to highlight the character position of channel symbol “... - Page 32 TV Function Brightness Press the ▲▼ button to select Brightness and press the ◄► or ENTER button to enter the brightness adjusting bar. Press the ◄► button to darken or brighten the picture. Color Press the ▲▼ button to select Color and press the ◄► or ENTER button to enter the color adjusting bar.
- Page 33 TV Function Blue Press the ▲▼ button to select Blue and press the ◄► or ENTER button to enter the adjusting bar. Press the ◄► button to select adjust the level. Notes: The items Red, Green and Blue are only available when Color Temperature is set to User. Within the adjusting bar, you can select Red, Green and Blue by pressing the ▲▼...
-
Page 34: Sound Setting
TV Function Sound Setting Press the MENU button once to enter CHANNEL setup menu and press the ▲▼ button to select SOUND, the screen will display as shown. Press the ENTER or ► button to enter the menu. In the SOUND setup menu, press the ▲▼ button to select the desired item. -
Page 35: Time Setting
TV Function Time Setting Press the MENU button once to enter CHANNEL setup menu and press the ▲▼ button to select TIME, the screen will display as shown. Press the ENTER or ► button to enter the menu. In the TIME setup menu, press the ▲▼ button to select the desired item. -
Page 36: Option Setting
TV Function Option Setting Press the MENU button once to enter CHANNEL setup menu and press the ▲▼ button to select OPTION, the screen will display as shown. Press the ENTER or ► button to enter the menu. In the OPTION setup menu, press the ▲▼ button to select the desired item. - Page 37 TV Function Restore Factory Default Press the ▲▼ button to select Restore Factory Default and press the ENTER or ► button to prompt a confirmation information box, as shown: Press the ◄► button to highlight Yes or No, press the ENTER button to reset the settings to their default status or cancel.
-
Page 38: Epg Function
EPG Function In DTV mode, press the EPG button to display the CHANNEL GUIDE menu as shown below: Within this menu, press the ▲▼ button to select a desired channel. Press the DISPLAY button to display the detail information of the selected channel. Press the yellow button to check the date information. -
Page 39: Nicam Function
NICAM Function The unit supports NICAM function when in TV mode. Under NICAM TV broadcast: When receiving stereo audio signals, press the STEREO button on the remote control repeatedly to select the sound tracks between NICAM STEREO and Mono and the screen will show the corresponding display as shown below: When receiving bilingual audio signals, press the STEREO button on the remote control repeatedly to shift the sound tracks between NICAM DUAL I, NICAM DUAL II, NICAM DUAL I+II and Mono... -
Page 40: Dvd Playback Operation
DVD Playback Operation Preparation Connect the unit to the power supply and press the POWER button to turn on the unit. Repeatedly press the INPUT button on the remote control to select DVD mode and press the ENTER button to enter. Gently insert the disc, with the label side toward the front of the television, into the disc tray slot until about half of the disc is in the tray and then the disc will be drawn into the disc tray and loaded automatically. - Page 41 DVD Playback Operation Previous and Next Press the button to go to the next chapter. Press the button once to return to the beginning of the current chapter or track; press it twice to go to the previous chapter. Fast Playback During playback, press the button to activate fast backward or forward playback.
-
Page 42: Cd Playback
DVD Playback Operation Subtitle The DVD player can support multiple kinds of subtitles. When you play a multi-subtitle disc you can press the SUBTITLE button on the remote control to select different subtitles. Some discs do not support the shifting subtitle function. CD Playback The player will play all tracks on a CD disc by default. -
Page 43: Jpeg Playback
DVD Playback Operation JPEG Playback JPEG is a common picture format that requires small amounts of storage per image and has low loss in resolution. Hundreds of pictures can be stored on a disc in this format. In order to view JPEG photo albums, you can ask your film development company to make a ”PICTURE CD”... -
Page 44: Avi Playback
DVD Playback Operation Playback is the name of a revolutionary new video code, which is based on the new compression standard for video. Load a disc in the disc tray, the player will enter the reading mode. The screen displays the root menu. Use the ▲▼ buttons to select desired item and press the ENTER button to play. -
Page 45: Usb And Sd/Ms/Mmc Card Function
DVD Playback Operation USB and SD/MS/MMC Card Function In DVD mode, connect USB device to the USB port or insert SD/MS/MMC card into the SD/MS/MMC card slot on the left side of the unit. Make sure that files are stored in the USB and SD/MS/MMC card before connection. When you turn on the unit, the media select menu will appear on the screen, as shown on the right: This menu also appears when pressing the CARD button in... -
Page 46: Dvd System Setup
DVD System Setup This is the place where you can arrange all important settings for the cooperation of the DVD with the TV set and other audio equipment. General Operating Steps Press the INPUT button to change to DVD mode. Press the SETUP button on the remote control, the settings menu will appear. -
Page 47: Dvd Setup Menu
DVD Setup Menu OSD Lang Please select preferred language for the OSD menus. Captions You can activate the captions display during playback with “On” or deactivate the display with “Off”. Screen Saver When activated, under stop mode, the unit will go into screen saver mode if the same image remains on the screen for several minutes. - Page 48 DVD Setup Menu Dolby Digital Setup: Dual Mono This function is used to set audio output. Stereo: Stereo signal output. L-Mono: Left audio channel signal output. R-Mono: Right audio channel signal output. Mix-Mono: Output of left and right mixed audio signals. Dynamic Use this function for setting the linear, dynamic compression ratio that can be used to implement various signal compression...
- Page 49 DVD Setup Menu Sharpness This menu allows the settings for the sharpness of the picture: ”High“, “Medium“ or “Low“ . Select "Low" for a soft image and "High" to improve a blurry image. Brightness and Contrast Used to set the brightness and contrast of the image to conform to the surrounding light and according to individual preferences.
- Page 50 DVD Setup Menu Audio, Subtitle and Disc Menu If a DVD contains several languages, you can choose the language for the playback, subtitles and DVD menu. Default This option is used to reset the unit. The factory settings are adopted. Notes: Resetting is only possible when the disk is removed from the DVD drive.
-
Page 51: Troubleshooting
Troubleshooting SYMPTOM CHECK ITEM Make sure the disc is loaded in. Make sure the disc is not dirty or warped. Make sure the player’s region code is the same as the region code The player cannot play. of the DVD disc. Make sure water condensation has not occurred. -
Page 52: Specifications
Specifications Model LCDV3255HD Screen Size 32-inch TFT LCD TV Native Resolution 1366×768 Pixels Brightness 500 cd/m2 Contrast Ratio 2500 :1 Response time (ms) 6.5 ms Color System Sound System BG/I/DK Tuner VHF/UHF: 48.25~863.25MHz Antenna 75Ω VHF/UHF input Stereo NICAM/A2 VIDEO INPUT... - Page 53 TEAC CUSTOMER SUPPORT HOTLINE (TCS) 1300 553 315 Between Monday to Friday – AEST 8.30AM to 6PM...
