Summary of Contents for Teac LCDV2250SD

  • Page 2 The warranty does not cover freight or insurance. In all cases of transit damage or lost, a claim must be filed against the carrier by the purchaser, even if shipment is arranged by TEAC. TEAC in- home service may also be available at a fee upon request.
  • Page 3 *Your nearest Authorised TEAC Service Centre is listed in your Owners Manual 10. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection with the sale of any equipment other than as stated in this warranty and outlined above.
  • Page 4 Dealer’s Address Postcode Please ensure that your product is packed appropriately upon return to the service centre. If you have any other queries regarding service or warranty please contact the TEAC Customer Care Centre below: service@teac.com.au www.teac.com.au 1800 656 700...

  • Page 5: Table Of Contents

    Table of Contents Important Safety Instructions ................2 View of Unit ......................5 Installing the DVD Module................... 8 Disc Information....................9 Remote Control ....................10 System Connections ..................16 Connecting to Power Supply................16 Connecting to an External AV Signal Source (Composite/S-Video) ..... 16 Connecting to an External AV Signal Source (YPbPr)..........

  • Page 6: Important Safety Instructions

    Important Safety Instructions This symbol indicates that dangerous voltage instituting a risk of electric shock is present within this unit. This symbol indicates that there are important operation and maintenance instructions in the literature accompanying the appliance. Caution: Laser radiation when open. Do not stare into beam. Caution: use of any controls, adjustments, or procedures other than those specified herein may result in hazardous radiation exposure.
  • Page 7 Important Safety Instructions NOTES: 1. Read these instructions. IMPORTANT FOR LASER PRODUCTS 2. Keep these instructions. 1. CLASS 1 LASER PRODUCT 2. DANGER: Visible laser radiation when open and 3. Heed all warnings. interlock failed or defeated. Avoid direct exposure to 4.
  • Page 8 Recommendation to Avoid or Minimize Phosphor Burn-in Like all phosphor-based display devices and all TFT LCD Displays, LCD TV' s can be susceptible to phosphor burn under certain circumstances. Certain operating conditions, such as the continuous display of a static image over a prolonged period of time, can result in phosphor burn if proper precautions are not taken.

  • Page 9: View Of Unit

    View Of Unit Front and Right View 1. Color TFT screen Color TFT screen clearly show the data. 2. Disc Tray Slot Insert disc into this slot. 3. USB Port Connect external USB device. 4. SD/MS/MMC card port Insert SD/MS/MMC card into this slot. 5.
  • Page 10 View Of Unit Front and Right View 9. VOL ▲/▼ button Press to decrease or increase the volume. In setup menu, the same function as ◄/►direction buttons. 10. POWER button Press to enter or exit the standby mode. 11. MENU button Press to enter or exit system setup menu.

  • Page 11: Rear View

    View Of Unit Rear View Open the back cover on the right side of the unit’s rear panel and all the connecting jacks will appear, as shown on the below figure: 1. Antenna socket Connect external TV or DVB-T signal source.

  • Page 12: Installing The Dvd Module

    Installing the DVD Module This TV set comes equipped with a removable DVD module. Please follow the procedures below to remove or install the DVD module. Note: Before removing or installing the DVD module, ensure that the television is unplugged and turned off.

  • Page 13: Disc Information

    Disc Information Discs Supported DISC LOGO CONTENTS SIZE MAXIMUM TIME 133min(SS-SL) Audio+Video 242min(SS-DL) 12cm (active picture) 266min(DS-SL) 484min(DS-DL) Audio 12cm 74min JPEG Still high resolution 12cm DIVX 12cm Operating systems and features of individual DVD discs are specified by the software maker. Please refer to the instructions accompanying the disc.

  • Page 14: Remote Control

    Remote Control Remote Control Drawing 3. DVD button Press to enter DVD mode. 4. ASPECT button Press to select the picture size: choose from Auto, Full and 4:3. 5. SLEEP button Press repeatedly to select the sleep time and Off. 6.

  • Page 15: Remote Control Drawing

    Remote Control Remote Control Drawing PAUSE button In DVD mode, press to pause the playback; press it again to resume normal playback. PLAY button In DVD mode, press to play the disc. button In teletext (TV) mode, they are color buttons.
  • Page 16 Remote Control Remote Control Drawing 21. AUDIO/EXIT button In teletext (TV) mode, press once to display the concealed information, such as solution of riddles or puzzles; press again to remove the riddles answers from the display. In DVB mode, press to exit the DVB setup menu.
  • Page 17 Remote Control Remote Control Drawing 27. SOUND button Press repeatedly to select the sound mode: choose from User, Normal, News, Cinema and Concert. 28. CH button In TV or DVB mode, press to select channels. 29. STEREO button Press to select sound track in TV mode (please see for details).
  • Page 18 Remote Control Remote Control Drawing 35. SUBTITLE button In teletext (TV) mode, press to hold the current page and press again to resume. In DVB mode, press to select desired subtitle language during a multiple subtitle languages program playback. In DVD mode, press to select different subtitle languages during...

  • Page 19: Preparation Of Remote Control

    Remote Control Preparation of Remote Control Using of Remote control Softly push the back cover to open the battery Point the remote control unit from no more than compartment. about 7m from the remote control sensor and within about 60 degrees of the front of the unit. Insert two batteries (1.5V, size AAA), please make sure the polarity matches the marks inside the compartment.

  • Page 20: System Connections

    System Connections • Do not connect the power cord until all other connections have been made. • Ensure that you observe the colour cord when connecting audio and video cables. • Before connecting, open the cover on the right side of the unit’s rear panel. Connecting to Power Supply Plug the power supply cord to the wall AC outlet.

  • Page 21: Connecting To An External Av Signal Source(Ypbpr)

    System Connections Connecting to an External AV Signal Source(YPbPr) Use the audio and video cables to connect the Y/PbCb/PrCr input Jacks on the right side of the unit’s rear panel to the external AV signal source. After connection, turn on the power of the unit and the external AV signal source. Press the INPUT button on the remote control or the SOURCE button on the TV set to select YPbPr mode.

  • Page 22: Connecting To A Pc

    System Connections Connecting to a PC The unit can be connected to PC (personal computer) via the VGA cable. Follow the steps and the figure below to connect. Connect one end of the VGA cable to the VGA input jack on the right side of the unit’s rear panel and the other end to the PC.

  • Page 23: Connecting To An External Av Signal Source(Av Output)

    System Connections Connecting to an External Signal Source(AV Output) Use the AV cables to connect the external AV input device to the AV output jacks on the side panel of the unit. Note: the unit can output TV, COMPOSITE and S-Video signals. After connection, turn on the power of the television and the external AV signal source.

  • Page 24: Connecting To A Dvb-T Antenna

    System Connections Connecting to a DVB-T Antenna Connect the DVB-T antenna to the DVB-T input Jacks on the rear panel of the unit. After connection, turn on the power of the unit. Then press the INPUT button on the remote control or the SOURCE button on the TV set to select DVB mode .

  • Page 25: Tv Function

    TV Function NOTE: In other mode, you can refer to the following instructions in TV mode to go on with some settings. Preparation 1. After connection, press the POWER button to turn on the unit. 2. Press the INPUT button on the remote control or the SOURCE button on the TV set repeatedly to select TV mode.
  • Page 26 TV Function Sharpness Press the ▲▼ button to select Sharpness and press the ◄► button to enter the menu as shown: within the menu, press the ◄► button to adjust the value. Press the MENU button to return the previous menu. Color Temperature Press the ▲▼...

  • Page 27: Audio Setting

    TV Function Audio Setting Press the MENU button once to enter the main setup menu. Press the ◄ ► button to select Audio and the screen will display as the right figure. In the menu, press the OK or ► button to enter the menu.

  • Page 28: Misc Setting

    TV Function Misc Setting Press the MENU button once to enter the main setup menu. Press the ◄► button to select Misc, and the screen will display as the right figure. In the menu, press the OK or ▼ button to enter the menu.
  • Page 29 TV Function Region Selection Press the ▲▼ button to select Region Selection. Press the ◄ ► buttont to select the desired region. Searching Press the ▲▼ button to select Searching. Press the OK or ► button to start auto searching and the screen will display: When auto-searching is over, all searched programs will be stored automatically and it will return to the first searched channel.
  • Page 30 TV Function Program Edit Press the ▲▼ button to select Program Edit, press the OK or button to enter the menu as shown: Use the four colour buttons on the remote control to swap, insert, copy or delete a program. Use the ▲▼buttons to select a program you want to swap, insert, copy or delete.
  • Page 31 TV Function In the menu (on Page 26), press the ▲▼◄ ► buttons to select characters or numbers and press the OK button to confirm. You can enter 6 characters at most. After entering characters, select “Cancel” and press the OK button to cancel; select “OK” and press OK button to confirm. Press the EXIT button to return to the previous menu.

  • Page 32: Geometric Setting (Vga Mode Only)

    TV Function Store In the program Edit Menu, press the ▲▼ button to select Store. Press the OK button to store the settings and return to the previous menu. Geometric Setting (VGA mode) Press the MENU button once to enter the main setup menu.
  • Page 33 TV Function Display Adjustment Press the ▲▼ button to select Display Adjustment. Press the OK or ► button to enter the menu as shown on the right: In the menu, press the ▲▼ button to select H Position or V Position and press the ◄►...

  • Page 34: Nicam Function

    NICAM Function The unit supports NICAM function when in TV mode. Under NICAM TV broadcast: 1. When receiving stereo audio signals, press the STEREO button on the remote control repeatedly to select the sound tracks between Nicam Stereo and Mono and the screen will show the corresponding display as shown below: 2.

  • Page 35: Teletext Function

    TELETEXT Function Teletext is an optional function, therefore only the sets with the teletext system can receive the teletext broadcast. Teletext is a free service broadcast by most TV stations which provides up-to-the-minute information on news, weather, television programs, stock prices and many other topics. The teletext decoder of this TV can support the SIMPLE and FASTEXT systems.

  • Page 36: Dvb-T Function

    DVB-T Functions Preparation After connection, press the POWER button to turn on the unit. Press the INPUT button on the remote control or the SOURCE button on the TV set to select DVB mode. Press the SETUP button on the remote control to display the setup menu. Press the direction buttons on the remote control to select a category.

  • Page 37: Language Setting

    DVB-T Functions 2. Banner Time Setting Select Banner Time Setting and press the OK button to enter. Press the direction button to display different options. Press the direction buttons to select desired item. Press the OK button to confirm and return. Language Setting Press the button to select Language Setting, press the OK button to enter the menu as...
  • Page 38 DVB-T Functions 1. Change Pin Code Select Change Pin Code and press the OK button to enter. The screen will display as shown right. Use the number buttons to input the old pin code. The default pin code is 888888. User the direction buttons and the number buttons to input the new code and again.
  • Page 39 DVB-T Functions 1. Restore Default Select Restore Default and press the OK button to display the confirm information on the screen. Press the OK button again to reset all the settings to the default status. Press the AUDIO/EXIT button to exit. 2.

  • Page 40: Channel Setting

    DVB-T Functions 2. Service Select Service and press the OK button to enter the Select Service menu. Press the direction buttons to select desired item. Press the OK button to confirm and return. 3. Event Type Select Event Type and press the direction button to enter.

  • Page 41: Channel Search

    DVB-T Functions Channel Search Press the button to select Channel Search in the Channel Setting menu, press the OK button to enter the Channel Search menu, the screen will display as below: In the menu, press the direction buttons to select desire item.

  • Page 42: Channel List

    DVB-T Functions Sort Channel Press the button to select Sort Channel in the Channel Setting menu, press the OK button to enter the menu as shown below: In the menu, press the direction buttons to select desire item and press the OK button to confirm.
  • Page 43 DVB-T Functions Add a Channel Select Add and press the OK button to enter. The screen will display as shown. Press the direction buttons to select desired items, press the button to enter, or use the number buttons to input, press the (yellow) button to open the softboard and press the direction buttons to select character or number,...

  • Page 44: Favourite List

    DVB-T Functions Favourite List Press the SETUP button to enter the setup menu. Press the direction buttons to select Favourite List and press the OK button to enter, the screen will display as below: In the menu, press the (red) button repeatedly to select different Fav Group.
  • Page 45 DVB-T Functions Press the SETUP button to enter the setup menu. Press the direction buttons to select EPG and press the OK button to enter, the screen will display as below: Use the button to select channel, press the OK button to booking channel, press the AUDIO/EXIT button to return.

  • Page 46: Dvd Playback Operation

    DVD Playback Operation Preparation Connect the unit to the power supply and press the POWER button to turn on the unit. Press the INPUT button on the remote control or the SOURCE button on the TV set to select DVD mode and press the OK button to enter. Gently insert the disc, with the label side toward the front of the television, into the disc tray slot until about half of the disc is in the tray and then the disc will be drawn into the disc tray and loaded automatically.
  • Page 47 DVD Playback Operation Previous and Next Press the button to go to the next chapter. Press the button once to return to the beginning of the current chapter or track; press it twice to go to the previous chapter or track. Fast Playback During playback, press the button to activate fast forward or backward playback.
  • Page 48 DVD Playback Operation CD Playback The player will play all tracks on a CD disc by default. You can use the buttons, or number buttons to select a track. Stop Press the ■ STOP button once to stop playback and press the ► PLAY button to resume normal playback.

  • Page 49: Jpeg Playback

    DVD Playback Operation JPEG Playback JPEG is a common picture format that requires small amounts of storage per image and has low loss in resolution. Hundreds of pictures can be stored on a disc in this format. In order to view JPEG photo albums, you can ask your film development company to make a ”PICTURE CD”...

  • Page 50: Divx Playback

    DVD Playback Operation DIVX Playback DIVX is the name of a revolutionary new video code, which is based on the new DIVX compression standard for video. Load a DIVX disc in the disc tray, the player will enter the reading mode. The screen displays the root menu.

  • Page 51: Usb And Sd/Ms/Mmc Card Function

    USB and SD/MS/MMC Card Function Preparation In DVD mode, connect USB memory to the USB port or insert SD/MS/MMC card into the SD/MS/MMC card slot on the right side of the unit. Make sure that files are stored in the USB and SD/MS/MMC card before connection. 1.

  • Page 52: Dvd System Setup

    DVD System Setup Preparation In DVD mode, press the SETUP button to enter DVD setup menu. Press the ◄► button to select setup menu. Press the SETUP button again to exit DVD setup menu. General Setup Page Press the SETUP button to enter the General Setup Page. The screen will display as below: On the menu, use the ▲▼...
  • Page 53 DVD System Setup OSD Lang The item is used to select the OSD language. 1. Press the ▲▼ direction buttons to select OSD Lang. 2. Press the OK button to enter the setup. 3. Use the ▲▼ direction buttons to select items. 4.
  • Page 54 DVD System Setup Audio Setup Page Press the SETUP button to enter the General setup menu, then use the ◄► direction buttons to select Audio Setup Page, the screen will display as the below: On the menu, Use the ▲▼ direction buttons to select the desired item.

  • Page 55: Video Setup

    DVD System Setup HDCD Setup In the Audio Setup Page, use the ▲▼ direction buttons to select HDCD Setup. Press the OK button to enter the menu as shown below: 1. On the menu, press the OK button to enter the setup.
  • Page 56 DVD System Setup Sharpness 1. Press the ▲▼ direction buttons to select Sharpness. 2. Press the OK button to enter the setup. 3. Use the ▲▼ direction buttons to select High, Medium or Low. 4. Press the OK button again to confirm selection and return.

  • Page 57: Preference Setup

    DVD System Setup Preference Setup Press the SETUP button to enter the General setup menu, then use the ◄► direction buttons to select Preference Page, the screen will display as the below: On the menu, Use the ▲▼ direction buttons to select the desired item.
  • Page 58 DVD System Setup Disc Menu 1. Press the ▲▼ direction buttons to select Disc Menu. 2. Press the OK button to enter the setup 3. Press the ▲▼ direction buttons to select Menu language. 4. Press the OK button again to confirm setting and return.

  • Page 59: Troubleshooting

    Troubleshooting Take steps described in the tables below to solve simple problems before contacting customer service. If you suspect something wrong with this unit, immediately turn the power off and disconnect the power connector from the unit. Never try to repair the unit yourself because it is dangerous to do so. SYMPTOM CHECK ITEM There is no display on the...

  • Page 60: Specifications

    Specifications Model LCDV2250SD Screen Size 22-inch TFT LCD TV Native Resolution 1680×1050 Pixels Brightness 300cd/m2 Contrast Radio 700 : 1 Response time (ms) Color System Sound System BG/I/DK Tuner VHF/UHF: 48.25~863.25MHz Antenna 75Ω VHF/UHF input Stereo NICAM/A2 VIDEO INPUT CVBS input PAL/SECAM/NTSC Y/C separate video signal Y...1 Vp-p/negative sync/75Ωinput C...0.283...
  • Page 67 TEAC CUSTOMER CARE CENTRE (TCCC) Free call: 1800 656 700 Between Monday to Friday – EST 9AM to 5PM...
