- Page 1 LCD4282FHDR LCD TV “ For Optimum picture and sound quality, please use TEAC Audio/Video cables ” TEAC High Performance Audio/Video cables and connectors have been designed to enhance your home entertainment experience. USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ...
- Page 2 Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service. If you require Warranty Service, please contact the TEAC Customer Support Hotline at 1300 553 315 for assistance. Please ensure that you have the model number, serial number and purchase receipt ready when you call.
-
Page 4: Table Of Contents
Contents Safety Precautions Power Supply..............................1 Installation................................. 2 Use and Maintenance............................3 Important Safety Instructions ..........................4-5 User Guidance Information Accessories / Wall Mounting Information ......................6 Names of each part(Front View) ........................7 Names of each part(Back View) ........................8 Remote control .............................. -
Page 5: Power Supply
Power Supply DO NOT plug several devices DO NOT touch the power DO NOT use a damaged Insert the power plug fully into into the same outlet. plug with wet hands. power cord or plug or a the outlet. loose outlet. •... -
Page 6: Installation
Installation DO NOT place the unit on an unstable DO NOT place containers with DO NOT place the unit where DO NOT use or store flammable surface, such as a sloped table, or any liquids such as vases, drink cans, it is exposed to rain, excessive or combustible materials near stand with a contact area smaller than... -
Page 7: Use And Maintenance
Use and Maintenance Although the LCD screen is made with high-precision technology and 99.99% or more of the pixels are effective, black dots may appear or bright points of light (red, blue, or green) may appear constantly on the LCD screen. This is a property of the LCD screen and is not a malfunction. -
Page 8: Important Safety Instructions
Important Safety Instructions power socket. Do not bend the power cord excessively. Prevent the cord from being walked on or pinched by weights placed on it. -
Page 9: Important Safety Instructions
TEAC service personnel for assistance. Servicing of this unit should be conducted by qualified and certified TEAC service personnel. The manufacturer will not be held responsible for any damage caused by any modifications done on the product without authorisation from the manufacturer’s... -
Page 10: Accessories / Wall Mounting Information
Accessories Remote Control Quick Start Guide User’s Guide Mains cable Wall Mounting Information Stand and wall-mounted (optional) Your LCD TV is able to accommodate wall mounting with the use of a wall mount bracket (not supplied with LCD TV, please contact your local hardware store) and the mounting hole screw size (M5X15) on the back of the unit. -
Page 11: Names Of Each Part(Front View)
Names of each part Front View INPUT: Display the input source menu. MENU: Display/exit the OSD menu. CH+/-: Scan through channels. VOL+/-: Adjust the volume. POWER: Turn on/standby the TV set. -
Page 12: Names Of Each Part(Back View)
Names of each part Back View SWITCH VIDEO VIDEO Name Function Description AC POWER IN Connect to power supply SWITCH Turn on/off the power supply Connect to USB device for multimedia HDMI1/2/3 Connect to the HDMI socket of your DVD or Satellite Box Connect to the PC VGA output to display PC graphics PC audio in PC audio input... -
Page 13: Remote Control
Remote Control (POWER) : Turn the TV on/back to Standby mode. DTV/USB INPUT AUDIO MUTE DTV/USB: Switch to DTV/USB. INPUT : Display the input source menu. PICTURE SOUND SLEEP ASPECT AUDIO : Select different audio languages, subject to availability from broadcaster. MUTE: Press to mute the sound, press again or press VOL+ to unmute. -
Page 14: Remote Control
Remote Control DTV/USB INPUT AUDIO MUTE PICTURE SOUND SLEEP ASPECT Buttons for USB operation: (REC): Press to start record the program in DTV mode. : No function. : Stop program. : Previous chapter. : Next chapter. : Play/Pause program. : Fast reverse. : Fast forward. -
Page 15: Basic Operation
Basic Operation The following section conveys the unit’s general operation, such as, switching the unit on, selecting the input source, and using the automated channel search command. Switching the unit on The following steps are a guide to switch the unit on: 1. - Page 16 Basic Operation Using the On Screen Display Menu The On Screen Display (OSD) menu acts as the Main Menu and aids the user in browsing through the different options/properties available on the television unit. Press the MENU button on the remote control to access the OSD menu as shown below: Main menu CHANNEL PICTURE...
-
Page 17: Osd Menu
OSD Menu 1. CHANNEL Menu This menu selection contains scanning preferences (either automatic or manual tuning), Program Edit options, Signal Information, Software Update Recording options, Record List and Record Start. Settings can be altered for individual channels. Description Press the MENU button once to enter CHANNEL setup menu as shown above. Press OK to enter the submenu. - Page 18 OSD Menu DTV Manual Tuning Press the OK button to enter the DTV Manual Tuning menu. Select a DTV channel, and press OK to start searching. ATV Manual Tuning Press the OK button to enter the ATV Manual Tuning menu. Current CH : Select the channel you want to tune.
- Page 19 Your device will need to be formatted before any recording is done. NOTE: Formatting will erase any existing data on the device. Back up all existing data before formatting. TEAC accepts no responsibility for any loss of data.
-
Page 20: Picture Menu
OSD Menu 2. PICTURE menu Picture display settings can be altered as desired. The following options are adjustable: Description Picture Mode: There are four preset settings to choose from: Standard, Dynamic, User and Mild. Note: Contrast, Brightness, Colour and Sharpness in the Picture Mode settings can only be adjusted and saved while in User Mode. -
Page 21: Sound Menu
OSD Menu 3. SOUND menu General sound settings can be adjusted according to personal preference with the following options: Description Sound Mode: There are five preset settings to choose from: Standard, Music, Movie, Sports and User. Note: Treble and Bass can only be adjusted in User mode. Treble: Adjust the relative intensity of higher pitched sounds. -
Page 22: Timer Menu
OSD Menu 4. TIME menu This menu allows the user to change the time settings of the unit. Description Clock: Use the buttons to select the position, and buttons to set the time. NOTE : The time cannot be changed manually in DTV mode because the clock is synchronised with the broadcast signals received. -
Page 23: Option Menu
LCD TV to automatically detect and pop up a message when new software is available for download. Alternatively software can also be downloaded from TEAC's website at http://www.teac.com.au and installed via the USB input on the LCD TV. Back Light: Set back light level, allows you to select. -
Page 24: Lock Menu
OSD Menu 6. LOCK menu This option allows parents to block channels and programs using a password. NOTE: The default password is 0000. If you have forgotten your current password, the master password is 4711. Please take note of this. Description Lock Channel: Turn on/off the Lock Channel function. -
Page 25: Multimedia Operation
Multimedia Operation Basic Operation 1). Press the INPUT button on the remote control to display the input source menu, select USB source by the buttons, and press the OK button to enter the Multimedia menu as illustrated below. Input Source AV 1 AV 2 YPbPr 1... - Page 26 Multimedia Operation To access photo, audio, video, or text files from an external drive he right input has to be accessed by pressing the INPUT button to select from a range of choices. 1. Photo To display photos, select files from the folder and press PLAY to view in full screen. The image should appear on screen as illustrated below.
- Page 27 Multimedia Operation Press button to select the option on the table, and press OK button to change. Press button to search for music, and press OK button to select. Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None. Goto Time: Start playing music from your desired time.
- Page 28 Multimedia Operation Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None. Set A-B: Select and play the preferable frame of the program in a loop, by setting A and B at the beginning and end, and there will be a sign on the left of the screen, press OK button again to cancel. Playlist: Display the playlist on the screen.
- Page 29 Multimedia Operation Supported Formats: MOVIE The max bitrate is 6Mbps. The max resolution is 720x576 pixels. (AVI) Mono colour, 16-colour, 256-colour, 16-bit, 24-bit, 32-bit. The max PHOTO resolution is 3000x3000 pixels; min resolution is 100x100 pixels. Sample rate: 8K – 48K, Bitrate: 32K-320K MUSIC Special note: 1.
-
Page 30: Recording Operation
Recording Operation Digital Video Recording (DVR) settings (In DTV Mode only) The DVR function allows this unit to record live digital TV (DTV) programs, allowing for viewing on demand at any time. This function supports DTV program recording, Time shift and playback as described below. - Page 31 Recording Operation Digital Video Recording (DVR) File System Attach a compatible USB device to the back panel of the unit. From the CHANNEL menu, enter the DVR File System to access recording options. NOTE: NOT all USB devices, such as phones, MP3 players, cameras, and the like, are compatible with recording files.
- Page 32 Recording Operation Check DVR File System Press ‘OK’ button to check if your USB device is ready and compatible for DVR functions. If the USB device is formatted and compatible with the unit, it will display a ‘SUCCESS’ message, if the device is not compatible, it will display ‘FAIL’.
- Page 33 Recording Operation 1) Free Record Limit Select recording time from 1 hour to 6 hours. Note 1- This applies only to manual (instant) recording. 2- Recording will stop once it reaches the maximum set time. 2) Manual Recording After the settings are completed on the DVR File System menu, you can start recording by selecting Record Start in the menu and press OK button in DTV mode.
- Page 34 Recording Operation - This unit is able to record while in Standby mode. - Start a recording, then press the power button. - A pop up message as shown above will be displayed. - Select "Turn off the screen, and continue recording . - Or select "Stop recording, and power off .
- Page 35 Recording Operation Scheduled Recording via Electronic Program Guide (EPG) Press the EPG button to display the OSD menu as below: Detailed information on the highlighted program. Curr nt time press </> change time. Select the program to be recorded with the directional buttons, then press the REC button on the remote control.
- Page 36 Recording Operation The Schedule List can be viewed by accessing it through the OSD menu by pressing the MENU button on the remote control. NOTE: To view the Schedule List, press the SCH.LIST button on the remote control. Alternatively, press MENU and select Schedule List under the CHANNEL tab, then press OK.
-
Page 37: Troubleshooting
Troubleshooting Do not use other functions that are not mentioned in this user manual. If a problem occurs with your LCD TV, please take the following steps first. If you still have the problem, turn the power off and contact your dealer or an authorized service center. Action Problem Is the power plugged in? Insert the power plug. -
Page 38: Specifications
Specifications Panel Size LCD Panel Max. Resolution Input Connector VIDEO YPbPr AUDIO (L/R) PC/AUDIO HDMI 3 The HDMI support 1.3, the HDCP support 1.1) Output Connector HEADPHONE COAX 100-240V 50/60Hz Power Source 200W Power Consumption Standby Power Consumption <1W Contrast Ratio 4000:1 500cd/m Brightness... - Page 39 Specifications Supported Formats: MOVIE The max bitrate is 6Mbps. The max resolution is 720x576 pixels. (AVI) Mono colour, 16-colour, 256-colour, 16-bit, 24-bit, 32-bit. The max PHOTO resolution is 3000x3000 pixels; min resolution is 100x100 pixels. Sample rate: 8K – 48K, Bitrate: 32K-320K MUSIC Special note: 1.
- Page 40 TEAC CUSTOMER SUPPORT HOTLINE (TCS) 1300 553 315 Between Monday to Friday – AEST 8.30AM to 6PM...
