Specifications

Features EDGE Modems
Performance EDGE: E-GPRS Class 10,
GPRS: Class 12
Band, Quad-band GSM
Frequency 850/900/1800/1900 MHz
Packet Data EDGE: E-GPRS Up to 240K bps,
coding scheme MCS-9, mobile
station Class B, LLC layer, 4 time
slots
GPRS: Full PBCCH support, coding
scheme 1-4, mobile station Class B
Circuit- Up to 14.4K bps, non-transparent
Switched Data
Short Message Text & PDU, Point-to-Point
Services-SMS (MO/MT), cell broadcast
Fax Class 1 Group 3
Voice Features Half rate (HR), Full rate (FR),
Enhanced full rate (EHR), Adaptive
multi rate (AMR), hands free echo
cancellation, noise reduction
Antenna RF Antenna: 50 ohm SMA (female
Connectors connector)
SIM Connector Standard 3V SIM receptacle
Interface Ethernet Model:
Connectors 10BaseT/100BaseTX, 802.3
Power Ethernet Model:
Connectors screw
Voice Ethernet Model:
Connectors modjack
Voltage 5V to 32 VDC
Power (Max. 950mA at 5V
Current Draw)
Physical Ethernet Model:
Description 2.8" L x 6.4" W x 1.2" H; 11.5 oz.
(7.1 cm x 16.3 cm x 3.0 cm; 326G)
Operating
-30° to +60° C
Temperature
Storage
-40° to +85° C
Temperature
Humidity Relative humidity 20% to 90%
condensing
Certifications CE Mark, R&TTE
EMC: FCC Part 2, 15, 22, 24; EN
55022, EN 55024
Safety: cUL, UL 60950; EN 60950
Network: PTCRB
Miscellaneous AT Command Compatible
Desktop or panel mounting
Carrier approved
Numerous LEDs provide status
Embedded TCP/IP stack
Two year warranty

AT Command Information

AT Commands: AT commands for the GPRS, GPRS-F4-IP, CDMA, and EDGE wireless modem are published
in separate Reference Guides included on the MultiModem CD and posted on the Multi-Tech web site.
Multi-Tech Systems, Inc. MultiModem Wireless Modem with Ethernet Interface (S000375E)
GPRS Modems
GPRS Class 10
Quad-band GSM
850/900/1800/1900 MHz
Up to 85.6K bps, coding schemes
CS1 to CS4
Up to 14.4K bps transparent and
non-transparent
Text & PDU, Point-to-Point, cell
broadcast
GSM Class 1 and Class 2 Group 3
Half rate (HR), Full rate (FR),
Enhanced full rate (EHR), echo
cancellation, noise reduction
(option), telephony and Dual Tone
Multi Frequency (DTMF)
transmission, emergency calls
RF Antenna: 50 ohm SMA (female
connector)
Standard 3V SIM receptacle
RJ-45, Ethernet Model:
10BaseT/100BaseTX, 802.3
2.5mm miniature Ethernet Model:
screw
RJ-9 4-pos NA
5V to 32 VDC
800mA at 5V
Ethernet Model:
2.8" L x 6.4" W x 1.2" H; 11.5 oz.
(7.1 cm x 16.3 cm x 3.0 cm; 326G)
-20° to +55° C
-40° to +85° C
Relative humidity 20% to 90%
condensing
CE Mark, R&TTE
EMC: FCC Part 2, 15, 22, 24; EN
55022, EN 55024
Safety: cUL, UL 60950; EN 60950
Network:
AT Command Compatible
Desktop or panel mounting
Carrier approved
Numerous LEDs provide status
Embedded TCP/IP stack
Two year warranty
Chapter 1 – Introduction and Product Description
CDMA Modems
CDMA2000 1xRTT
Dual-band 800/1900 MHz CDMA;
800 MHz and 800/1900 MHz with
R-UIM support
Up to 153.6K bps forward and
reverse
IS-95A, IS 95B up to 14.4K bps
forward and reverse
Text & UCS-2, Point-to-Point, cell
broadcast
Class 2.0 Group 3
Telephony and Dual Tone Multi
Frequency (DTMF) functionality,
AMPS Voice, QCELP (13K), echo
cancellation
RF Antenna: 50 ohm SMA (female
connector)
RJ-45, Ethernet Model:
10BaseT/100BaseTX, 802.3
2.5mm miniature Ethernet Model:
screw
NA
5V to 32 VDC
840mA at 5V
Ethernet Model:
2.8" L x 6.4" W x 1.2" H; 11.5 oz.
(7.1 cm x 16.3 cm x 3.0 cm; 326G)
-20° to +55° C
-40° to +85° C
Relative humidity 20% to 90%
condensing
EMC:
Safety:
Network:
PTCRB
AT Command Compatible
Desktop or panel mounting
Carrier approved
Numerous LEDs provide status
Over-the-air activation
Embedded TCP/IP stack
Two year warranty
RJ-45,
2.5mm miniature
FCC Part 2, 15, 22, 24; EN
55022, EN 55024
cUL, UL 60950; EN 60950
CDG 1 & 2
