Page 1: Product Specification
Product Specification - LC08 High-Bright Monitor Document Number: 023-0283-00 Revision: C Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Page 1 of 26 Rev C... -
Page 2: Table Of Contents
High Ambient Contrast Display Uniformity Display Chromaticity LCD Panel - Physical Image Characteristics Section 7 Display Cosmetics Black Display Picture Mode White Display Picture Mode Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Page 2 of 26 Rev C... - Page 3 Table 1. Temperature / Humidity Limits Table 2. Video Mode Definitions Table 3. Dot Clock Frequencies Table 4. Measured u’, v’ Color Coordinates Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 24-25 Page 3 of 26 Rev C...
-
Page 4: Section 1 - Introduction
600 lines vertical for the VESA2 modes. VGA border(s) are excluded from the active display area definitions listed in this document. Figure 11 defines the IBM VGA 1 and VESA2 video signal timing requirements. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Page 4 of 26... - Page 5 “fill” the active display area of the Display with the video resolution being presented. Video Mode Definition parameters for video resolution detection by the video board are shown in Section 4.2.2.1. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Page 5 of 26...
-
Page 6: Section 2 - Basic Construction
Connections (Section 5.1) are insulated to insure no accidental contact. Interface Cables No interface cables are provided. Planar can provide suggestions on available cables. LCD Controller Board The LCD Controller Board incorporates components necessary to drive the LCD Panel (Section 6.5). -
Page 7: Signal Ground
A proper adjustment will give continuous shading from black to white. Figure 2. External Adjustments (Rear View) Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Page 7 of 26 Rev C... -
Page 8: Section 3 - Environmental
The packaged Display must comply to ASTM D4169, Shipping Containers and Systems 3.3.1 Vibration (for non-packaged item) The following Sections 3.3.1.1, 3.3.1.2, and 3.3.2 apply. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Shipping and Storage C to 60 C to 60... -
Page 9: 3.3.1.1 Sine Sweep
The Display withstands a 76mm [3in] three axis. Approximately 30G’s of shock are generated. Figure3. Definition of Axes for Shock and Vibration Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Standard Test Method for Random Vibration Testing of... -
Page 10: Section 4 - Video Signal Input Requirements
Display as a chassis mounted connector per definitions listed in 3. The "No Pin" positions of this connector may not be used for any purpose. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Page 10 of 26... -
Page 11: Signal Functions
(Section 2.9) of Red, Green, and Blue analog input signals based on the maximum output level range previously specified. Figure 7. Rise / Fall Time Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Page 11 of 26... -
Page 12: Synchronization
Displayed Video Image Mode Resolution IBM VGA 640x400 IBM VGA 640x480 VESA 800x600 Table 2. Video Mode Definitions Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Scanning Frequency Sync Polarity Horizontal Vertical Horizontal 31.468KHz 70Hz 31.468KHz 60Hz 48.077KHz... -
Page 13: 4.2.2.2 Color Display Detection
The video signal source determines which type of display is connected to it based on the state of the Monitor Sense Lines. The Display will indicate to the source that it is a "color display" when Monitor Sense Line 1 (Pin 11) is physically connected to Signal Ground Reference (Pin 10) as defined by the wiring definitions of 3. -
Page 14: Timing And Frequency
The incoming active video dot clock frequencies for the Display are: Dots Dot Time 20.000-ns 39.722-ns Table 3. Dot Clock Frequencies Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Dot Frequency 50.000 MHz 25.175 MHz Page 14 of 26... -
Page 15: Video Modes
1 .112 Vertical Active Display 12 .711 Vertical Sync Polarity NOTE: VGA border is not included in the Active Display time described above. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 VIDEO MODES IBM VGA 640 x 400 640 x 480 25.175 MHz... -
Page 16: Section 5 - Dc Power Input Requirements
DC Input Current: 3.0-amp maximum current draw (12.4 Vdc applied) steady-state conditions. • Refer to Figure 14 for input current characteristics at “power-up” conditions. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 SIGNAL NAME Most Positive Input Voltage... -
Page 17: Power On-Off Sequences
Power On-Off Sequences The Display shall automatically return to normal operation upon resumption of power after a power loss. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Page 17 of 26 Rev C... -
Page 18: Section 6 - Display Performance
10 LUX [1fC] incident illumination. The measured u′, v′ color coordinates at room temperature for White-light and the Red, Green, and Blue primaries are listed for reference purposes only. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 light... -
Page 19: Lcd Panel - Physical Image Characteristics
• LCD Size: • Active Area: • Pixel Format: • Pixel Pitch: • Pixel Arrangement: • Aspect Ratio: Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 v′ Perceived Color 0.527 Reddish-Orange 0.330 Blue 0.563 Yellowish-Green 0.514 White K color temperature. -
Page 20: Section 7 - Display Cosmetics
The LCD Panel is acceptable if there are 10 or less black dots visible from 35c [14in] with the unaided eye.. • The LCD Panel is acceptable if no more than 3 dots are joined. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Page 20 of 26 Rev C... -
Page 21: Section 8 - Regulatory Agency Requirements
EN 55022 − Limits and measurements of radio interference characteristics of information technology equipment. • IEC 1000 3−2/1995; EN 61000−3−2 • IEC 1000 3−3/1995; EN 61000−3−3 Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 EN 55022:1987 EN 50082:1992 Current Harmonic Tests Voltage Fluctuation and Flicker Tests... -
Page 22: System Transient Disturbance Requirements
10 KHz to 1 GHz. (REF CISPR 22). Labeling IEC 417 − Graphical Symbols for Use on Equipment. Color Coding ISO 3864 − Safety Colors and Safety Signs. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 Page 22 of 26 Rev C... -
Page 23: Section 9 - Reliability
Exposure to environments outside the specified design range. Lack of prescribed preventative maintenance. Failures caused by test equipment used to control cycle and check the operation of Display units on test. Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 50,000 hours 250,000 hours... -
Page 24: Appendix 1 - Glossary Of Terms
− A measure of the ratio of two signals. The dB value is 20 x log dB (Decibel) of a voltage or current ratio or 10 x log of a power ratio. Title: Product Specification – LC08 High-Bright Monitor Page 24 of 26 Document Number: 023-0283-00 Rev C... - Page 25 Shades of Gray a square-root-of-2 difference between successive shades. − A contraction of synchronous or synchronization. Sync − See Tristimulus Value Chromaticity Value Color Data Title: Product Specification – LC08 High-Bright Monitor Page 25 of 26 Document Number: 023-0283-00 Rev C...
-
Page 26: Title: Product Specification - Lc08 High-Bright Monitor
27 Feb. 2003 25 Mar. 2003 27 Mar. 2003 1230 5 May 2003 1535 12 Dec 2003 Title: Product Specification – LC08 High-Bright Monitor Document Number: 023-0283-00 DESCRIPTION OF CHANGE Draft Release Format Cleanup Added detailed button descriptions Removed Power supplies references Removed reference to customer in section 6.4;...
