- Page 1 UPER ® SAS933TQ BUZZER_ENB1 BUZZER1 +12V +12V +12V +12V FAN1 FAN3 FAN4 FAN2 SAS 933TQ BACKPLANE USER'S GUIDE Rev. 1.0a...
- Page 2 Please Note: For the most up-to-date version of this manual, please see our web site at www.supermicro.com. Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual at any time and without notice. This product, including software, if any, and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any medium or machine without prior written consent.
-
Page 3: Table Of Contents
Safety Information and Technical Specifi cations Table of Contents Chapter 1 Safety Guidelines ESD Safety Guidelines ................... 1-1 General Safety Guidelines ................1-1 An Important Note to Users ................1-2 Chapter 2 Jumper Settings and Pin Defi nitions Front Connectors and Jumpers ..............2-1 Front Connector and Pin Defi... -
Page 4: Contacting Supermicro
Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML... -
Page 5: Chapter 1 Safety Guidelines
Safety Information and Technical Specifi cations Chapter 1 Safety Guidelines To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. ESD Safety Guidelines Electric Static Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully. -
Page 6: An Important Note To Users
SAS-933TQ Backplane User's Guide An Important Note to Users • All images and layouts shown in this user's guide are based upon the latest PCB Revision available at the time of publishing. The card you have received may or may not look exactly the same as the graphics shown in this manual. -
Page 7: Front Connectors And Jumpers
Safety Information and Technical Specifi cations Chapter 2 Jumper Settings and Pin Defi nitions Front Connectors and Jumpers SAS933TQ BUZZER_ENB1 BUZZER1 +12V +12V +12V +12V FAN1 FAN3 FAN4 FAN2 1. I C Connector#1 JP37 14. ACT_IN# 8 - 15 2. I C Connector#2 JP95 15. -
Page 8: Front Connector And Pin Defi Nitions
SAS-933TQ Backplane User's Guide Front Connector and Pin Defi nitions #1. Activity LED Header SAS Activity LED Header Pin Defi nitions (JP26) The activity LED header, designated JP26 and Pin # Defi nition Pin # Defi nition JP47, is used to indicate the activity status ACT IN#0 ACT IN#4 of each SAS drive. - Page 9 Safety Information and Technical Specifi cations #5 Backplane Main Power Connectors Backplane Main Power The 4-pin connectors, designated JP10, 4-Pin Connector (JP10, JP13, JP46, JP13, JP46, and JP48, provide power to the and JP48) backplane. See the table on the right for pin Pin# Defi...
-
Page 10: Front Jumper Locations And Pin Defi Nitions
SAS-933TQ Backplane User's Guide Front Jumper Locations and Pin Defi nitions JP35 JP50 JP84 JP18 SAS933TQ BUZZER_ENB1 JP97 JP100 JP98 BUZZER1 JP99 JP61 JP64 JP63 JP62 +12V +12V +12V +12V FAN1 FAN3 FAN4 FAN2 Explanation of Jumpers Connector Pins To modify the operation of the backplane, jumpers can be used to choose between optional settings. -
Page 11: Jumper Settings
Safety Information and Technical Specifi cations Jumper Settings Jumper Jumper Settings Note Open: Enabled Buzzer Reset JP18 Closed: Disabled Open: Default MG9072 Chip Reset JP35, JP50 Closed: Reset Fan Jumper Settings This backplane can use up to four fans. To utilize each fan, you must confi gure both jumpers as instructed below. -
Page 12: Sas Port Connections In I C And Sgpio Settings
SAS-933TQ Backplane User's Guide SAS Port Connections in I C and SGPIO Settings Use the following chart when connecting this backplane. If you connect the SAS ports out of order, you will not able to easily identify drives using the LED func- tion. -
Page 13: Front Led Indicators
Safety Information and Technical Specifi cations Front LED Indicators SAS933TQ BUZZER_ENB1 BUZZER1 +12V +12V +12V +12V FAN1 FAN3 FAN4 FAN2 SAS933TQ BUZZER_ENB1 POWER LEDS ALARM LEDS FAN FAILURE LEDS Front Panel LEDs STATE SPECIFICATION Fan #1 Fail Failure in Fan #1 Fan #2 Fail Failure in Fan #2 Fan #3 Fail... -
Page 14: Rear Connectors And Led Indicators
SAS-933TQ Backplane User's Guide Rear Connectors and LED Indicators Rear Connectors Rear SAS/SATA Connectors Rear SAS Drive Rear SAS Drive Connector Number Connector Number SAS #0 SAS/SATA HHD #0 SAS #8 SAS/SATA HHD #8 SAS #1 SAS/SATA HHD #1 SAS #9 SAS/SATA HHD #9 SAS #2 SAS/SATA HHD #2... -
Page 15: Locations Of Rear Connectors And Leds
Safety Information and Technical Specifi cations Locations of Rear Connectors and LEDs Locations of Rear Connectors and LEDs Rear Connector Failure/Activity LED 1. SAS #0 16. D5/D12 2. SAS #1 17. D6/D13 3. SAS #2 18. D7/D14 4. SAS #3 19. - Page 16 SAS-933TQ Backplane User's Guide Notes 2-10...
