QuickSpecs
Configuration
Service Processor (MP)
Service Processor
Service Processor
Service Processor
The service processor (MP) utility hardware is an independent support system for nPartition servers. It
provides a way for you to connect to a server complex and perform administration or monitoring
tasks for the server hardware and its nPartitions. The main features of the service processor include the
Command menu, nPartition consoles, console logs, chassis code viewers, and partition Virtual Front
Panels (live displays of nPartition and cell states).
Access to the MP is restricted by user accounts. Each user account is password protected and provides a
specific level of access to the Superdome complex and service processor commands. Multiple users can
independently interact with the service processor because each service processor login session is private.
Up to 16 users can simultaneously log in to the service processor through its network (customer LAN)
interface and they can independently manage nPartitions or view the server complex hardware states.
Two additional service processor login sessions can be supported by the local and remote serial ports.
These allow for serial port terminal access(through the local RS-232 port) and external modem access
(through the
remote RS-232 port).
In general, the service processor (MP) on Superdome servers is similar to the service processor on other
HP servers, while providing enhanced features necessary for managing a multiple-nPartition server. For
example, the service processor manages the complex profile, which defines nPartition configurations as
well as complex-wide settings for the server. The service processor also controls power, reset, and TOC
capabilities, displays and records system events (chassis codes), and can display detailed information
about the various internal subsystems.
Functional capabilities
Functional capabilities
Functional capabilities
Functional capabilities
DA - 11717
Worldwide — Version 35 — December 6, 2006
HP Integrity Superdome Servers 16- processor, 32-
HP Integrity Superdome Servers 16- processor, 32-
HP Integrity Superdome Servers 16- processor, 32-
HP Integrity Superdome Servers 16- processor, 32-
The primary features available through the service processor are:
The Service Processor Command Menu: provides commands for
system service, status, access configuration, and manufacturing tasks.
Partition Consoles: Each nPartition in a server complex has its own
console. Each nPartition's console provides access to Boot Console
Handler (BCH) interface and the HP-UX console for the nPartition.
Console Logs: Each nPartition has its own console log, which has a
history of the nPartition console's output, including boot output, BCH
activity, and any HP-UX console login activity.
Chassis Logs Viewers (Live and Recorded Chassis Codes): Three types
of chassis code log views are available: activity logs, error logs, and
live chassis code logs.
Virtual Front Panels: Each nPartition's Virtual Front Panel (VFP) displays
real-time status of the nPartition boot status and activity, and details
about all cells assigned to the nPartition. The VFP display
automatically updates as cell and nPartition status changes.
processor, and 64- processor Systems
processor, and 64- processor Systems
processor, and 64- processor Systems
processor, and 64- processor Systems
Page 31
