Mic Input

• Balanced ¼" TRS input (Tip (+), Ring (–), Sleeve (ground)
• Accepts unbalanced ¼" TS (Tip-Sleeve) plugs.
• Mic Engage switch turns the Mic on and off without changing the Mic level.
° Green indicator lights when engaged.
• MIC level control range is Off to +50 dB
• Overload Indicator:
° Lights 3 dB before clipping.
° Monitors the signal level before and after the HI and LOW tone controls.
° If it lights, turn the MIC level down and/or reduce the tone control boost.
• 2-band tone control:
° Maximum boost: 12 dB.
° Maximum cut: -12 dB.
° Center frequency: 1 kHz.
• FlexFX effects loop:
° WET (effect), DRY (no effect) pan control.
° Process mic with any combination of input channels.
° See FlexFX Effects Loop section for details.

AUX Input and Output

• AUX Input:
° Unbalanced RCA jack.
° AUX CUE signal is sent to the cue circuit before the AUX IN level control.
° AUX IN level control range is Off to +10 dB.
° AUX input sums to the Master mix after the Crossfader and FlexFX loop.
• AUX Output:
° Unbalanced RCA jack.
° AUX OUT control range is Off to +0 dB
° Source is the Master mix:
Program 1, 2, 3 (pre- or post-effects)
plus the Mic
plus the AUX Input.
Booth Output
• Balanced ¼" TRS output
• Level control range is Off to +6 dB
• Source is the Master mix:
Program 1, 2, 3 (pre- or post-effects)
plus the Mic
plus the AUX Input.

Main Output

• Balanced XLR output.
• Level control range is Off to +6 dB.
• Source is the Master mix:
Program 1, 2, 3 (pre- or post-effects)
plus the Mic
plus the AUX Input.
