Chapter 1 – Introduction and Description
Category
Bus Type:
Connectors:
Cables:
Temperature:
Approvals
Power:
Interrupt Request (IRQ):
Warranty:
Manufactured in Mounds View, MN, U.S.A.
6
ISI9234 models are PCI Express form factor 1x, PCIe 1.0 compatible.
ISI5634 models are UPCI is PCI spec version 2.1 compatible.
one RJ-45 jack (female) on ISI-4; two RJ-45 jacks (female) on ISI-8
The ISI-8 ships with two four-port fan-out cables. Each cable has an RJ-45 plug (male)
at one end and four RJ-11 plugs (male) at the other end.
The ISI-4 ships with one such four-port fan-out cable.
32° to 149° F (0° to 65° C)
CE Mark
R&TTE
EMC: FCC Part 15; EN55022; EN55024
Safety: UL60950-1; IEC60950-1; AS/NZS 60950-1
250 milliamps @ +5vDC (8 ports; ISI5634UPCI-8)
1.75A @3.3v DC (8 ports; ISI5634UPCI-8)
130 milliamps @ +5v DC (4 ports; ISI5634UPCI-4)
885 milliamps @ 3.3v DC (4 ports; ISI5634UPCI-4)
700 milliamps @ 3.3v DC (4 ports; ISI9234PCIE-4)
1.20A @3.3v DC (8 ports; ISI9234PCIE-8)
One IRQ per card (can be shared)
Two years
Description
