INSTALLATION INSTRUCTIONS
MODEL WBI-F7 INTERIOR WINDOW BAR KIT
TOOLS REQUIRED:
Eye Safety Goggles
Power Drill
HARDWARE:
QTY DESCRIPTION
12
#10 x ½" Flat head sheet metal screw
1
Driver Side Window guard
1
Passenger Side Window guard
INSTALLATION:
1. Open door and position the guard to contour the door panel and fit evenly around the window
frame.
2. With guard positioned, mark the vehicles doorframe using the holes in the guard as a guide.
3. Remove window guard and drill the marked holes using an 1/8" drill bit.
4. Re-position the guard and attach to the doorframe using #10 x ½" flat head sheet metal screws.
1996-2007 FORD CROWN VICTORIA
1/8" Drill Bit
Phillips Screw Driver
PART #
GSM33150
WBI-F7-1
WBI-F7-6
WBI-F7-INST-9-06
